• BLEND: Selects output mixing mode: 100% compression, X=Crossfade, or
MIX: Sets the percentage of compressed signal and input signal sent to the outputs
o
• IN: Toggles to switch gain reduction IN or out
• BYPASS: Toggles to engage the hard-wire bypass
• VU (stereo VU meters): Stereo Left and Right analog VU meters
METER: Selects output or input as the source for the stereo VU meters
o
• GR (gain reduction meters): Stereo Left and Right 10-segment gain reduction meters
50 th Anniversary 2500 Bus Compressor
9
l l=Parallel
