MANDIBULA SEATPOST
INSTRUCTION BOOK
THMMANDIBULA
thm.bike

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MANDIBULA SEATPOST and is the answer not in the manual?

Questions and answers

Summary of Contents for THM MANDIBULA SEATPOST

  • Page 1 MANDIBULA SEATPOST INSTRUCTION BOOK THMMANDIBULA thm.bike...
  • Page 2 PREFACE This manual is an integral part of your THM component and it provides you with information regarding the safe operation of your THM- Mandibula seatpost. Carefully read this manual prior to assembling your NOTICE THM components.
  • Page 3: Intended Use

    For the time being we limit the service life of your THM seatpost to 100,000 km or 10 years. It is imperative you contact us before continuing...
  • Page 4: Transport And Storage

    Do not store your THM components at an ambient temperature • Do not exceed the maximum rider weight for which your THM component below -15°C (5°F) or above 55°C (131°F). have been approved. See Dimensions with “INTENDED USE” on page 5.
  • Page 5: Technical Specifications

    Seatpost Lower half shell with small slots (Table 2) (green label) Technical specifications, dimensions and weights are to be understood with the corresponding tolerances and can differ slightly from your THM Upper half shell Ø7 mm with medium round components.
  • Page 6 8 (71) then onto your bicycle. (Table 3) Recommended torques in this instruction book are specific for the THM Mandibula seatpost. Please check the manual of the mating component (frame, seat clamp) for the recommended torque. Always use the lower...
  • Page 7 MANDIBULA SEATPOST INSTRUCTION BOOK 5 mm (Figure 3) Turn the screw (8) contraclockwise with a T20 Torx Fig. 3 until WORKBENCH between the D6 clamping bolt (6) and the washer appears a gap of (Figure 5) Mandibula rear view 5 mm.
  • Page 8 On both sides should be the same distance “a”. • In the case that you want to install a Di2 batterie into the seatpost THM If this is not the case you have to hold with one hand the saddle and recommends to use a adaptor from PRO (part number: FAPRAC0094).
  • Page 9: Adjusting The Saddle Angle

    8 N•m (71 Ibf•in)T INSERTING THE SEATPOST WITH SADDLE WARNING The minimum insert depth is 100 mm for the THM Mandibula seatpost. Loosen the seat clamp (10) screw fully. Slide the assembled group (Figure 10) side view (seatpost and saddle) into the seat tube (11) at your roughly desired height.
  • Page 10: Adjusting The Saddle Height

    Ride and contact your dealer or THM. ADJUSTING THE SADDLE HEIGHT CAUTION To adjust your saddle height to your preference. THM recommends to sit on the bike with your cycling shoes and bib shorts on. Now put • After mounting and adjusting your THM Mandibula seatpost check...
  • Page 11: Important Maintenance Information

    Never use caustic solvents (such as paint thinners, acetone, nitro compounds, etc.) as they can attack the surface of your THM Improperly performed assembly and maintenance work could also components.
  • Page 12: Before Every Journey

    (e.g. recycling). The following maintenance measures should be conducted more Only if you are citizen of the EU please sent us the defective THM frequently if the bicycle is used in extreme conditions (rain, dirt, long component back and we will take care of the professional waste disposal.
  • Page 13: Warranty

    Liability does not extend to any kind of damage caused by accidents, modifcations, negligence or improper handling and use. Liability shall expire if repair work or any other work on the THM product has been conducted by unauthorised persons.
  • Page 14 THM component as replacement. The relevant claim must be forwarded directly to THM Faserverbund- Technologie GmbH. The irreparable product shall then remain our property. The company THM Faserverbund-Technologie GmbH is constantly striving to improve product designs as technical developments continue.
  • Page 15 MANDIBULA SEATPOST INSTRUCTION BOOK THM Faserverbund-Technologie GmbH Am Sportplatz 3 D-24791 Alt Duvenstedt info@thm.bike www.thm.bike thm.bike...
