Recommended Components for Hybrid Fixator
Product
Item
Number
294.785
5.0 mm Self-Drilling
Schanz Screw, 175 mm
292.38 –
Spade-Point Reduction Wire
292.41
(or Spade-Point Wire)
390.005
Large Combination Clamp
393.436
Ring-to-Rod Clamp
393.464
Adjustable Wire / Pin Clamp
Notes: Additional components are required for optional
frame configurations.
Additionally available lengths of stainless steel self-drilling
Schanz screws, stainless steel non – self-drilling Schanz screws
and titanium self-drilling Schanz screws may also be used.
Although some components are MR Conditional, the
standard hybrid frame is not safe to be utilized in an
MR environment.
Synthes Hybrid Fixator— Distal Tibia Frame Technique Guide
Quantity
Needed
3
2
3
2
5
