Enerpac Z-Class Instruction Sheet page 6

6.5 E "LO PRESS" Menu (Available only when
Automode is ON - All except pump type 3)
(See Screen 5) This screen allows
the operator to set the low-pressure
limit at which the pump energizes the
motor / electric valve. Make changes
in increments of 50 psi [3.5 bar] by
pressing either Down or Up Arrow
button once. Press and hold either
button to scroll quickly through the
available settings. Default pressure value is OFF (or "0" on some
pump models). Save setting and step forward to the Main menu
(See section 6.5 F) by pressing the Menu button for 3 seconds.
Refer to QRC step #3C.
Note: If the menu button is pressed for less than 3 seconds, the
selected LO PRESS setting will be saved. However, the Motor
menu (See section 6.5 G) will appear instead of the Main menu.
CAUTION: The LO PRESS value should be set at least
400 PSI below the HI PRESS value to prevent excessive
pump cycling. Use appropriate valving in the hydraulic
circuit to ensure that the pump does not cycle on and off more
than three times per minute. For circuits equipped with sequence
valves, the LO PRESS setting should be at least as high as the
fi rst stage sequence valve pressure.
6.5 F Main Menu
(See Screen 6A) When Automode is
fi rst turned on, the screen will display
"AUTO".
(See Screen 6B) During
operation, and after Automode has
taken control of the pump, the text will
change from "AUTO" to "AUTO ON".
All except pump type 3: If a LO
PRESS value has been entered, the
pump backlight will begin to fl ash on
and off. This fl ashing will continue
until system pressure drops to the LO
PRESS value.
Note: Details of Automode operation
will vary, depending on pump type and
model. Refer to sections 4.0 and 4.1
for additional information. Also refer to
the pump model matrix in Table 4 near
the end of this document.
(See Screen 6C) If Automode is OFF, the
screen will display "READY" instead of
"AUTO", and the system pressure will
appear on the numeric display.
Note: For pumps NOT equipped with
a pressure transducer, the screen will
display "READY" and no pressure will
be indicated. The "AUTO" and "AUTO
ON" screens will not be available.
6.5 G "Motor" Menu
(See Screen 7) This screen allows the
operator to read the number of hours
or on/off cycles the motor has been
operated. Toggle between hours and
cycles by pushing either the Down
or Up Arrow button. Step forward by
pressing the Menu button. Refer to
QRC step #5.
Screen 5
LO PRESS
SET
OFF
Screen 6A
AUTO
pump
0 PSI
Screen 6B
AUTO ON
0
PSI
Screen 6C
READY
0 PSI
Screen 7
MOTOR
4.8
HOURS CYCLES
__________________________________________________________
General note for all hour and cycle displays:
HOURS DISPLAYED
- up to 9999.9 the display will show decimal hours.
- between 10,000 - 99,999 whole hours will be
displayed (decimal "." is not displayed).
- over 99,999 hours the meter starts over at 0.0 reading
decimal hours.
CYCLES DISPLAYED
- over 99,999 cycles the meter starts over at 0.
__________________________________________________________
6.5 H "Low Volt" Menu
(See Screen 8) This screen allows the
operator to read the number of hours
the pump has been operated in a low-
voltage condition. Step forward by
pressing the Menu button. Refer to
QRC step #6.
6.5 I "Advance" Menu
(See Screen 9) This screen allows the
operator to read the total number of
hours that the advance valve solenoid
has been operated. It also displays
the total number of advance solenoid
cycles. Toggle between hours and
cycles by pushing either the Down or
Up Arrow buttons. Step forward by
pressing the Menu button. Refer to
QRC step #7.
6.5 J "Retract" Menu
(See Screen 10) This screen allows
the operator to read the total number
of hours that the retract solenoid has
been operated. It also displays the
total number of retract solenoid cycles.
Toggle between hours and cycles by
pushing either the Down or Up Arrow
buttons. Step forward by pressing the
Menu button. Refer to QRC step #8.
6.5 K "Local" Menu
(See Screen 11) This screen allows the
operator to toggle the Local mode ON
or OFF (default is OFF). Local mode
allows operation of the pump if the
pendant or pendant cord is damaged.
With Local mode ON, the shroud
buttons replace the pendant buttons
as the method of operating the pump,
and the pendant buttons become deactivated. Toggle Local
mode ON or OFF by pressing the Down or Up Arrow button.
When Local mode is ON, the text "LOCAL" replaces "READY" on
the "Normal Operation" menu. Save setting and step forward by
pressing the Menu button. Refer to QRC step #9.
6
Screen 8
LOW VOLT
.0
HOURS
Screen 9
ADVANCE
188
HOURS CYCLES
Screen 10
RETRACT
334
HOURS CYCLES
Screen 11
SET LOCAL
OFF
