CONTROLS AND CONNECTIONS

1. LED Screen
2. Mp3 control
3. SD Card Slot
4. USB PORT
5. Bass Control
6. Treble Control
7. ECHO EFFECT FOR MICROPHONE
8. Mic Level: It is used to adjust the
signal level from the microphone input
9. Master Volume: It is used to adjust
the signal level from the Mp3/Line input
10. Mp3 Level: It is used to adjust the
signal level from the Mp3
11. Guitar Level: It is used to adjust the
signal level from the Guitar input
12. Mic input: 6.35mm Jack for a
microphone input
13. RCA Line input
14. Microphone Select: Press it to power
ON/OFF the wire microphone
15. 3.5mm AUX input
16. RCA line output
17. 6.35mm Guitar input
18. B-VOL: It is used to adjust the signal
level of B wireless microphone
19. Wireless Mic power LED
20. Chanel B wireless Mic power LED
21. A-VOL: It is used to adjust the
signal level of A wireless microhpne
www.PyleUSA.com
22. Chanel A wireless Mic power LED
23. Wireless microphone antenna
24. Wireless microphone select:
Press it to power ON/OFF the
wireless microphone
25. ON/OFF Power switch
26. Battery charge switch
27. External Power DC 12V Input
28. AC Power: Connect the
incorporated AC power cord
29. Batterry Electric quantity
Instructions Change – Low
electronic- full electronic
