CONTROLS AND CONNECTIONS

1. SD card input
2. USB input
3. LCD screen
4. MP3 control
MODE: USB/SD/BT/FM convertor
: Play/Pause
: Repeat one/Repeat all/Random
FOL (FOLDER): Press and hold for 5 seconds to enter the folder option function
mode (press the previous/next songs button to choose the folder)
: Previous song, Press and hold for 2 second to decrease the volume, Press and
hold the volume goes down to zero
: Next song, Press and hold for 2 second to increase the volume, Press and
hold the volume goes up to 25
5. Volume control
6. Bass control for low frequencies
7. Treble control for high frequencies
8. Echo control
9. Mic input level control
10. 6.35 microphone 1 input
11. 6.35 microphone 2 input
12. Mic/Line switch
13. XLR line input
14. RCA Phone (R+L) line input
15. 6.35mm line output
16. Power LED indicator
17. Speaker out 8 ohm
18. MP3/Line switch
19. Fused IEC mains inlet
20. Main power switch
21. 110V/220V switch
www.PyleUSA.com
3
