SPECIFICATIONS

1 - Phase Line Voltage
Frequency
High Voltage (% of setpoint)
Trip
Reset
Low Voltage (% of setpoint)
Trip
Reset
Trip Delay Time
Low Voltage
High Voltage
Restart Delay Time
After a complete power loss
Output Contact Rating - SPDT
Pilot Duty
General Purpose
Power Consumption
Weight
Enclosure
Terminal
Torque
Wire AWG
Safety Marks
UL
CE
Standards Passed
Electrostatic Discharge (ESD)
Radio Frequency Immunity, Radiated 159 MHz, 10 V/m
Fast Transient Burst
*NOTE: 50 Hz will increase all delay timers by 20%
Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: info@clrwtr.com
190 - 240 (95-120) VAC
50* - 60 Hz
110% ±1%
107% ±1%
90% ±1%
93% ±1%
4 Seconds Fixed
4 Seconds Fixed
1-500 Seconds Adjustable
480 VA @ 240 VAC
10 A @ 240 VAC
6 Watts (maximum)
14 oz
Polycarbonate
6 Inch-Pounds
12 - 20 AWG
UL508 (File # E68520)
IEC 60947-6-2
IEC 1000-4-2, Level 3, 6 kv contact,
8 kv air
IEC 1000-4-4, Level 3, 3.5 kv input
power and controls
