Lascal BUGGYBOARD MAXI+ Owner's Manual page 5

THE WHEELS
1.
THE CONNECTORS
2.
3.
2
1
a = max . 20 cm / 8 in.
a
- 5 -
1. Attaching the wheels
Place the platform (80100-80106) upside
down on a sturdy surface. Push the wheels
(80420) firmly into the suspension housing
(80220) until the wheels 'click' into place.
Tip!
Detaching the wheels.
Pull the red wheel locking
clip out 1 cm (1/2 in.) with a
small screwdriver.
2. Positioning the connectors
The connectors (80410) can be attached
facing forward or backwards. The connectors
can be fitted onto different shapes of tubing
with a maximum circumference of 20 cm (8
in.). Position the connectors so that the arms
(80360/80361) will be able to reach the con-
nectors (maximum 35 cm (14 in.) above the
ground). Try to attach the connectors as low
as possible on the stroller. Position the con-
nectors so that they do not interfere with the
stroller's folding mechanism. The arms need
to stay clear of both the braking mechanisms
and the wheels of the stroller.
3. Attaching the connectors
Bend the strap (80400) around the tubing.
Then feed the strap through the slot in the
connector cover (80390) and pull the strap
until tight. Secure the connector by turning
the connector-bolt (80395) clockwise. Check
that the stroller folds properly; if not, you
may need to reposition the connectors.
