Circuit Specialists TC-V2.12k User Manual page 8

Selftest End
Warning: Do not carry out other operations in the calibration process, so as not to
affect the calibration accuracy!
2.5 Detect Zener diode
In the power off state or the detection is completed, put the Zener diode into the Zener diode
test area of test seat, and press the locking handle, short press the multifunction key, the tester
automatically measure, graphical display of measurement results when testing is complete.
Warning: Do not put the component into transistor test area, otherwise it is
impossible to test zener diode!
2017-4-62015-8-8
版权所有，侵权必究 All rights reserved 第 21 页,共 25 页 Page 21 , Total25
多功能测试仪（TC-V2.12k）
Multi-function Tester (TC-V2.12k)
