Warning: Adjust the automatic shutdown time required to open the housing, and use
an electric soldering iron solder the jumpers.
Attention：Please do ESD protection!
Manual shutdown
Long press the multifunction key to force a shutdown in any state, while the measuring
element is included.
2.8 Built-in Li-ion Battery voltage measurement
The built-in Li-ion Battery voltage is measured before detection, when the battery voltage is
less than 3.0V will force shutdown, then please charging.
2.9

Charging the Battery

The tester has a standard Micro USB interface, please use an external 5V power supply or
USB power charging.
Information：Red LED indicates is charging, green LED indicates charging is
complete.
Warning: Charging input voltage up to 6V, do not exceed the top voltage, or it will
damage the tester, and could cause the battery to explode!
