Z-Saw UNIVERSAL S-265 Instruction Sheet Manual

※ Read the instruction prior to use, and keep it for future reference.
② ANGLE BRACKET
⑨ KNOB
① BASE PLATE
⑥
SPACER
④
INNER GUIDE PLATE
Caution
○ Over tighten hex screws may damage the screws and hex wrench.
○ Being used with saws other than Z-saw Universal S-265 may damage both saw blade and guide.
○ Bumping saw handle against guide plates amid the strokes may cause inaccurate sawing result.
○ Do not drop the guide on the ground, as doing so may cause distortions on it.
○ Wear safety goggles.
Notice
○ Specification may change without notice to improve quality.
○ Copyright © Okada Hardware Manufacturing Company Limited.
Saw Guide Instruction sheet
Saw Guide kit
part # ①, ②, ③ and ⑨ are adjusted at the factory for 90°cutting.
⑩ SCREWS
③ SAW GUIDE
HOLDER
⑤
GUIDE PLATE
You may think sawing straight is very difficult
and that only professionals can do it. But,
using the Saw Guide, you can make precise
cuts just like professional carpenters do. It ' s
ideal for users who always need to cut precise
90° straight cuts, both right and left 45° angle
cuts or inclined 45° angle cuts. From picture
frames to practical and useful household and
garden furniture of your own, the Guide will
definitely be an indispensable tool for your
D.I.Y. activities.
⑫ HEX KEY WRENCH
- 1 -
Part # Description
① BASE PLATE
ANGLE BRACKET
②
③ SAW GUIDE HOLDER
④ INNER GUIDE PLATE
⑤ GUIDE PLATE
⑥ SPACER
※ ⑦ POSITIONING HOLDER
※ ⑧ PARALLEL SLIDING HOLDER
KNOB
⑨
⑩ SCREWS (8mm length)
⑪ SPARE SCREWS
(5mm & 8mm length)
HEX KEY WRENCH
※ ⑫
※ marked parts are packed in a paper
envelope.
Quantity
1
1
1
1
1
1
1
1
1
3
2
1
