INSTALLATION INSTRUCTIONS
Air Conditioner
This air conditioner uses the refrigerant R410A.
Model No.
Indoor Units
Type Indoor Unit Type
K2
Wall Mounted
ENGLISH
Read through the Installation Instructions before you proceed with the installation.
In particular, you will need to read under the "IMPORTANT!" section at the top of the page.
FRANÇAIS
Lisez les instructions d'installation avant de commencer l'installation.
En particulier, vous devez lire la section «IMPORTANT!» en haut de la plage.
ESPAÑOL
Lea las Instrucciones de instalación antes de proceder con la instalación del equipo.
En concreto, deberá leer detenidamente la sección "¡IMPORTANTE!" situada al principio de la página.
DEUTSCH
Lesen Sie die Einbauanleitung, bevor Sie mit der Installation beginnen.
Insbesondere die Hinweise im Abschnitt "WICHTIG!" oben auf der Seite müssen unbedingt gelesen werden.
ITALIANO
Leggere le Istruzioni di installazione prima di procedere con l'installazione.
Prestare particolare attenzione alla sezione "IMPORTANTE!" all'inizio della pagina.
NEDERLANDS
Lees de installatie-instructies zorgvuldig door voor u begint met de installatie.
U moet vooral het gedeelte waar "BELANGRIJK!" boven staat heel goed lezen.
PORTUGUÊS
Leia cuidadosamente as instruções de instalação antes de prosseguir com a instalação.
Em particular, é necessário ler as informações na secção "IMPORTANTE!" na parte superior da página.
TÜRKÇE
#
$
%
&
'
(
&
)
0
%
1
Rated Capacity
45
56
S-45MK2E5A S-56MK2E5A S-73MK2E5A S-106MK2E5A
73
106
§
¢
£
¦
§
¢
¨
£
¨
"
¥
!
¨
§
¦
§
©
¦
¤
¥
£
¨
¢
¨
©
¢
§
¤
£
¨
¦
¤
¦
£
§
©
¥
¦
©
¨
¢
§
¦
£
¥
ACXF60-16360
¤
£
¢
¡
Advertisement
Table of Contents
Related Manuals for Panasonic K2 Series
Summary of Contents for Panasonic K2 Series
- Page 1 INSTALLATION INSTRUCTIONS § ¢ Air Conditioner £ ¦ This air conditioner uses the refrigerant R410A. § ¢ ¨ £ ¨ Model No. " Indoor Units ¥ Rated Capacity Type Indoor Unit Type ¨ § ¦ Wall Mounted S-45MK2E5A S-56MK2E5A S-73MK2E5A S-106MK2E5A ENGLISH §...
-
Page 2: Important
IMPORTANT! Please Read Before Starting may cause overheating at connection points and a possible fire hazard. This air conditioner must be installed by the sales dealer Provide a power outlet to be used or installer. exclusively for each unit. This information is provided for use only by authorized persons. - Page 3 …In Moist or Uneven Locations § possible. ¢ blocks to provide a solid, level foundation £ ¦ for the outdoor unit. This prevents water tubing. damage and abnormal vibration. …In an Area with High Winds matching surfaces of the flare and union Securely anchor the outdoor unit down tubes before connecting them, then with bolts and a metal frame.
- Page 4 CAUTION installing or testing the refrigeration on contact with fire or heat, can produce dangerously toxic gas. refrigerant gas is leaking. If the gas comes in contact with a burning stove, gas water heater, electric room heater or other heat source, it can cause the generation of toxic gas.
-
Page 5: Table Of Contents
CONTENTS § Page Page ¢ £ IMPORTANT! ........2 7. -
Page 6: General
1. GENERAL This booklet briefly outlines where and how to install the air conditioning system. Please read over the entire set of instructions for the indoor units and make sure all accessory parts listed are with the indoor units before beginning. 1-1. -
Page 7: Selecting The Installation Site
2. SELECTING THE INSTALLATION SITE NOTE Air delivery will be degraded if the distance from the floor to the § ¢ 2-1. Indoor Unit ceiling is greater than 3 m. £ AVOID: ¦ Wall Mounted G areas where leakage of flammable gas may be expected. The air inlet and outlet of the indoor unit must be free of any G locations where sulfurous acid gas or corrosive gas occurs. -
Page 8: How To Install The Indoor Unit
3. HOW TO INSTALL THE INDOOR UNIT 3-1. Starting the Installation (1) Remove the rear panel. NOTE Tubing can be extended in 6 directions as shown below. Select the direction you need providing the shortest run to the outside unit. Tubing direction Left-rear tubing... -
Page 9: Install The Installation Plate On The Wall
(2) Before making the hole, check carefully that no studs or 3-3. Install the Installation Plate on the Wall pipes are directly run behind the spot to be cut. § ¢ If Wooden Wall Avoid areas where electrical wiring is £... - Page 10 3-4-1. Right-rear side, right side, right-bottom side G Pull out the drain hose to remove it. When attaching it, tubing slide the drain hose fully onto the drain pan outlet. (It will be easy to slide when water is added.) After attaching Be sure to insulate the drain hose and refrigerant tubing to run the drain hose, check that it is attached securely.
-
Page 11: To Mount And Unmount Indoor Unit
(4) Connect the drain hose. Do not enforce the base of the drain hose when making a connection. § G Insert securely the drain hose into the PVC pipe. ¢ G When installing the drain hose extension, connect with an optional drain hose. £... -
Page 12: Wiring Instructions
3-6. Wiring Instructions <Power supply, Inter-unit control wiring, Remote control <Optional parts setting and wiring> wiring> (1) Open the front panel and remove the screw (×1). Then close the panel. (1) Open the front panel and remove the screw (×1). Front panel Front panel Screw (4×16) - Page 13 Wiring sample (4) Make wiring. Refer to the instructions manual of optional parts as well. § ¢ <When Connecting with 3WAY VRF Outdoor Unit> £ Indoor control PCB ¦ G Install the solenoid valve controller (optional parts) on the wall. Important: Set up the controller so that the maintenance can be carried out easily.
-
Page 14: Electrical Wiring
4. ELECTRICAL WIRING 4-2. Recommended Wire Length and Wire Diameter for Power Supply System 4-1. General Precautions on Wiring Indoor unit (1) Before wiring, confirm the rated voltage of the unit as (B) Power supply shown on its nameplate, then carry out the wiring closely Time delay fuse or Type circuit capacity... -
Page 15: Wiring System Diagrams
4-3. Wiring System Diagrams Indoor unit § ¢ (No. 1) ex.) Type ME2 (for Europe) £ Power supply Outdoor unit ¦ 220-230-240V ~ 50-60Hz INV unit Power supply Ground Remote 380-400-415V, 3 N~, 50Hz controller Ground Indoor unit (No. 2) Inter-outdoor-unit control wiring Power supply 220-230-240V ~ 50-60Hz... - Page 16 CAUTION (1) When linking the outdoor units in a network, disconnect the terminal extended from the short plug from all outdoor units except any one of the outdoor units. (When shipping: In shorted condition.) For a system without link (no wiring connection between outdoor units), do not remove the short plug. (2) Do not install the inter-unit control wiring in a way that forms a loop.
-
Page 17: For Stranded Wiring
How to connect wiring to the terminal I For stranded wiring I Examples of shield wires (1) Cut the wire end with cutting pliers, then strip the insulation (1) Remove cable coat not to scratch braided shield. to expose the stranded wiring about 10 mm and tightly twist the wire ends. -
Page 18: How To Process Tubing
5. HOW TO PROCESS TUBING Caution Before Connecting Tubes Tightly (1) Apply a sealing cap or water-proof tape to prevent dust or 5-1. Connecting the Refrigerant Tubing water from entering the tubes before they are used. (2) Be sure to apply refrigerant lubricant (ether oil) to the inside of the flare nut before making piping connections. -
Page 19: Insulating The Refrigerant Tubing
For the flare nuts at tubing connections, be sure to use the NOTE flare nuts that were supplied with the unit, or else flare nuts Gas Leakage Detector for R410A (type 2). The refrigerant tubing that is used must Note that the gas leakage detector should be capable of be of the correct wall thickness as shown in the table below. -
Page 20: Finishing The Installation
8. PRECAUTIONS ON TEST RUN 5-5. Finishing the Installation After finishing insulating and taping over the tubing, use sealing Request that the customer be present when the test run is putty to seal off the hole in the wall to prevent rain and draft performed. - Page 21 9. CHECKLIST AFTER INSTALLATION WORK Work List Content Check Possibility of Failure & Checkpoint Are the indoor units installed following the There is a possibility of light injure or loss of Installation content of the section “2. SELECTING property. THE INSTALLATION SITE”? Is the earth leakage circuit breaker (all-pole switching function provided) installed?
- Page 22 – NOTE –...
