SITRANS L
Radar transmitters
SITRANS Probe LR with mA/HART
Compact Operating Instructions
7ML5430 (SITRANS Probe LR with mA/HART)
05/2019
A5E46248119-AC
Introduction
Safety notes
Description
Installing/mounting
Connecting
Commissioning
Service and maintenance
Technical data
Certificates and support
1
2
3
4
5
6
7
8
A

Advertisement

Table of Contents
loading

Related Manuals for Siemens SITRANS L Series

Summary of Contents for Siemens SITRANS L Series

  • Page 1 Introduction Safety notes Description SITRANS L Installing/mounting Radar transmitters SITRANS Probe LR with mA/HART Connecting Commissioning Compact Operating Instructions Service and maintenance Technical data Certificates and support 7ML5430 (SITRANS Probe LR with mA/HART) 05/2019 A5E46248119-AC...
  • Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Table Of Contents

    Table of contents Introduction ..............................6 Checking the consignment ....................... 6 Industrial use ..........................6 Security information ........................6 Purpose of this documentation ....................7 Safety notes ............................... 8 Preconditions for use ........................ 8 2.1.1 Safety marking symbols ......................8 Laws and directives ........................
  • Page 4 Table of contents Commissioning ............................23 Basic safety notes ........................23 Local commissioning ......................23 6.2.1 Activating SITRANS Probe LR ....................23 6.2.2 Operating SITRANS Probe LR ....................23 6.2.3 Low temperature effects on RUN/PROGRAM modes ............24 6.2.4 RUN mode ..........................24 6.2.5 PROGRAM mode........................
  • Page 5 Table of contents Certificates ..........................43 Index ................................ 44 SITRANS Probe LR with mA/HART Compact Operating Instructions, 05/2019, A5E46248119-AC...

  • Page 6: Introduction

    In order to protect plants, systems, machines and networks against cyber threats, it is necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial security concept. Siemens’ products and solutions only form one element of such a concept. Customer is responsible to prevent unauthorized access to its plants, systems, machines and networks.

  • Page 7: Purpose Of This Documentation

    Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends you apply product updates as soon as available and always use the latest product versions. Use of product versions that are no longer supported, and failure to apply latest updates may increase customer’s exposure to cyber threats.

  • Page 8: Safety Notes

    2.2.1 Radio Equipment Directive (RED) compliance (Europe) Hereby, Siemens declares that the SITRANS Probe LR is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. The Probe LR complies with EN 302 372 for use in closed storage vessels, when installed according to the installation requirements of EN 302 372, and may be used in all EU countries.

  • Page 9: Industry Canada Conformity

    Safety notes 2.2 Laws and directives 2.2.2 Industry Canada conformity Canada Installations only: Industry Canada (IC) rules NOTICE Use on a "no-interference, no-protection" basis This device shall be installed and operated in a completely enclosed container to prevent RF emission, which otherwise can interfere with aeronautical navigation. Installation shall be done by trained installers, in strict compliance with the manufacturer’s instructions.

  • Page 10: Fcc Conformity

    US Installations only: Federal Communications Commission (FCC) rules WARNING Authority to operate equipment Changes or modifications not expressly approved by Siemens could void the user’s authority to operate the equipment. Note • This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 11: Use In Hazardous Areas

    Safety notes 2.3 Use in hazardous areas Use in hazardous areas 2.3.1 Qualified personnel for hazardous area applications Qualified personnel for hazardous area applications Persons who install, connect, commission, operate, and service the device in a hazardous area must have the following specific qualifications: ●...

  • Page 12: Description

    Description SITRANS Probe LR SITRANS Probe LR is a 2-wire loop-powered, continuous level measuring instrument that utilizes advanced pulse radar technology operating at a frequency of approximately 6 GHz. The instrument consists of an electronic component coupled to the antenna and process connection.

  • Page 13: Ambient/Operating Temperature

    Process temperature and pressure capabilities are dependent upon information on the process device tag. The reference drawing listed on the tag can be downloaded from the Siemens website. Go to the SITRANS Probe LR product page at: SITRANS Probe LR (www.siemens.com\probelr)

  • Page 14: Installing/Mounting

    Installing/mounting Basic safety notes 4.1.1 Incorrect disassembly WARNING Incorrect disassembly The following risks may result from incorrect disassembly: - Injury through electric shock - Risk through emerging media when connected to the process - Risk of explosion in hazardous area In order to disassemble correctly, observe the following: •...

  • Page 15: Mounting Location

    Note Material compatibility Siemens can provide you with support concerning selection of sensor components wetted by process media. However, you are responsible for the selection of components. Siemens accepts no liability for faults or failures resulting from incompatible materials.

  • Page 16: Nozzle Location

    Installing/mounting 4.3 Nozzle location ① Process temperature: –40 to 80 °C (–40 to 176 °F) ② Locking collar over threaded connection; secured by three 2 mm Allen set-screws. When the locking collar is secured, it prevents the enclosure rotating on the threaded connec- tion.

  • Page 17: Nozzle Design

    Installing/mounting 4.4 Nozzle design ① Min. 300 mm (1 ft) per 3 m (10') of vessel height ② Emission cone ③ Beam angle 28° Emission cone ● Keep emission cone free of interference from ladders, pipes, I-beams or filling streams. ●...

  • Page 18: Mounting Instructions

    Installing/mounting 4.5 Mounting instructions Location on a manhole cover ● A manhole cover is typically a covered nozzle with a diameter 610 mm (24”) or greater. ● For optimum signal conditions, locate the antenna off-center, typically 100 mm (4") from the side.

  • Page 19: Connecting

    Connecting Power Note DC terminals DC terminals shall be supplied from an SELV (Safety Extra Low Voltage) source in accordance with IEC-1010-1 Annex H. Note Insulation All field wiring must have insulation suitable for rated voltages. Connecting SITRANS Probe LR Unscrew the two lid screws to access the terminal block.

  • Page 20: Nameplate For Hazardous Area Installations

    Connecting 5.3 Nameplate for hazardous area installations Note • Use shielded, twisted pair cable (wire gauge AWG 14 to 22). • Separate cables and conduits may be required to conform to standard instrumentation wiring practices or electrical codes. • The non-metallic enclosure does not provide a continuous ground path between conduit connections: use grounding type bushings and jumpers.

  • Page 21: Fm And Csa Connection Drawings

    The FM Intrinsically Safe connection drawing (A5E01003040) listed on the device nameplate can be downloaded from our website: Product page (www.siemens.com/SitransProbeLR) Go to Technical Info > Images, graphics, drawings. The CSA Intrinsically Safe connection drawing (A5E01003039) listed on the device nameplate can be downloaded from our website: Product page (www.siemens.com/SitransProbeLR)
  • Page 22 Connecting 5.5 Instructions specific to hazardous area installations (reference European ATEX Directive 2014/34/EU Annex II, 1/0/6) 9. It is the responsibility of the user to ensure that manual override is possible in order to shut down the equipment and protective systems incorporated within automatic processes which deviate from the intended operating conditions, provided that this does not compromise safety.

  • Page 23: Commissioning

    Commissioning Basic safety notes WARNING Loss of type of protection Risk of explosion. Damage to device if the enclosure is open or not properly closed. The type of protection specified on the nameplate or in Approvals (Page 42) is no longer guaranteed.

  • Page 24: Low Temperature Effects On Run/Program Modes

    Commissioning 6.2 Local commissioning 6.2.3 Low temperature effects on RUN/PROGRAM modes If the internal temperature falls to –30 °C (–22 °F) or below, it will affect both RUN and PROGRAM modes. RUN mode will operate normally, with the following exceptions: ●...

  • Page 25: Program Mode

    ● Activate PROGRAM mode at any time, to change parameter values and set operating conditions. ● For local programming, use the Siemens handheld programmer. ● For programming from a distance, use either a PC running SIMATIC PDM, or a HART handheld communicator.

  • Page 26: Handheld Programmer

    Commissioning 6.2 Local commissioning Lithium batteries are primary power sources with high energy content designed to provide the highest possible degree of safety. WARNING Potential hazard Lithium batteries may present a potential hazard if they are abused electrically or mechanically. Observe the following precautions when handling and using lithium batteries: •...

  • Page 27: Handheld Programmer: Function Keys In Program Mode

    Commissioning 6.2 Local commissioning ① Numeric and auxiliary keys ② Function keys 6.2.6.2 Handheld programmer: function keys in PROGRAM mode FUNCTION Values Decimal point Negative value CLEAR value TOGGLE between Units and % on parameter value End PROGRAM session and enable RUN mode Update echo quality parameters Parameter scroll-up Parameter scroll-down...

  • Page 28: Handheld Programmer: Function Keys In Run Mode

    Commissioning 6.2 Local commissioning 6.2.6.3 Handheld programmer: function keys in RUN mode RUN mode mA output value displayed in auxiliary reading field. Internal enclosure temperature displayed in auxiliary reading field. Parameter for auxiliary readings Press to display the auxiliary reading field when in RUN mode. Displays the value representing Echo Confidence (P805).
  • Page 29 Commissioning 6.2 Local commissioning 1. Press PROGRAM then DISPLAY , to activate the PROGRAM mode. ① PROGRAM icon ① Parameter value ② Parameter number 2. Either use the ARROW keys to scroll to a different parameter, or: 3. Press DISPLAY to open the Parameter Number field.

  • Page 30: Security

    Commissioning 6.2 Local commissioning 6.2.7 Security The Lock parameter, P000, secures SITRANS Probe LR against changes via the handheld programmer. To enable programming, set P000 to the Unlocked Value stored in P069. To disable programming, enter a different value. Note Configuration change A remote master can still change configuration, if P799 is set to allow this.

  • Page 31: Using Units Or Percent (%)

    Commissioning 6.2 Local commissioning 3. Key in 999. Press CLEAR then ENTER , to Clear All and initiate reset. The LCD displays C.ALL. 4. Reset complete. (Reset takes several seconds to complete.) 6.2.10 Using units or percent (%) Many parameters can be viewed either as a percentage, or in measurement units (P005). View the parameter, then press MODE to toggle between units and percentage.

  • Page 32: P010: Language

    Commissioning 6.2 Local commissioning 6.2.11.2 P010: Language The parameter title appears in the language selected, for parameters P000 to P010. If a language is selected, parameter titles for the Quick Start parameters are displayed in the auxiliary reading field. Parameter Value Description Numeric/None...

  • Page 33: P003: Measurement Response

    Commissioning 6.2 Local commissioning ① ④ Reference point Empty ② ⑤ Span Space ③ ⑥ Level Distance Note • Setting P001 resets Span (P007), unless Span has previously been set to a different value. Span is set to Empty distance minus 110% of Blanking, unless Operation is set to distance measurement (P001=3).

  • Page 34: P005: Units

    Commissioning 6.2 Local commissioning 6.2.11.5 P005: Units Select the measurement units required (P005: Units) Parameter Value Description meters centimeters P005 millimeters feet inches 6.2.11.6 P006: Empty Set process empty level (P006: Empty) Value Range 0.0000 to 20.00 Default 20.00 m (maximum range) Enter the distance from the antenna reference point to process empty level (Empty), using units set in P005.

  • Page 35: P007: Span

    Commissioning 6.2 Local commissioning 6.2.11.7 P007: Span Set the range to be measured (P007: Span) Value Range 0.0000 to 20.00 Default 19.56 (see note below) Enter the distance between Empty (process empty level) and Span (process full level), in the units set in P005.

  • Page 36: Additional Settings

    ● You will need the full Operating Instructions to acquire the list of applicable parameters. The full Operating Instructions are available here: Product support (https://support.industry.siemens.com/cs/products?dtp=Manual&mfn=ps&pnid=17564&lc =en-WW). ● The HART Electronic Device Description (EDD) may be obtained from the HART Communication Foundation at https://fieldcommgroup.org/ (https://fieldcommgroup.org/).

  • Page 37: Service And Maintenance

    Service and maintenance WARNING Impermissible repair and maintenance of the device • Repair and maintenance must be carried out by Siemens authorized personnel only. Cleaning Cleaning the enclosure ● Clean the outside of the enclosure with the inscriptions and the display window using a cloth moistened with water or a mild detergent.

  • Page 38: Disposal

    Observe the specific regulations valid in your country. Further information about devices containing batteries can be found at: Information about battery/product return (WEEE) (https://support.industry.siemens.com/cs/document/109479891/) SITRANS Probe LR with mA/HART Compact Operating Instructions, 05/2019, A5E46248119-AC...

  • Page 39: Technical Data

    Technical data Note Device specifications Siemens makes every attempt to ensure the accuracy of these specifications but reserves the right to change them at any time. Note Operating temperature Check the ambient and operating temperatures under Construction (Page 40) and Approvals (Page 42).

  • Page 40: Performance

    Technical data 8.2 Performance Performance Performance Reference operating conditions according to IEC 60770-1 Ambient temperature +15 to +25 °C (+59 to +77 °F) Humidity 45% to 75% relative humidity Ambient pressure 860 to 1060 mbar g (86000 to 106000 N/m Measurement Accuracy (measured in accordance with IEC 60770-1) From end of antenna to 600mm 40mm (1.57")

  • Page 41: Operating Conditions

    Technical data 8.4 Operating conditions Note • Check the ambient and operating temperatures under Enclosure (below) and Approvals (Page 42) for the specific configuration you are about to use or install. • Approved dust-tight and water-tight conduit seals are required for outdoor Type 4X, Type 6, IP67, IP68 locations.

  • Page 42: Approvals

    Technical data 8.6 Approvals Approvals Note Conduit glands The use of approved watertight conduit hubs/glands is required for Type 4X, Type 6, IP67, IP68 (outdoor applications). General , CE, RCM Radio Europe (RED), FCC, Industry Canada Hazardous Intrinsic safety Europe ATEX II 1 G Ex ia IIC T4 Ga 06ATEX2354X International...

  • Page 43: Certificates And Support

    In addition to our documentation, Siemens provides a comprehensive support solution at: ● Services & Support (http://www.siemens.com/automation/service&support) Personal contact If you have additional questions about the device, please contact your Siemens personal contact at: ● Partner (http://www.automation.siemens.com/partner) To find the personal contact for your product, go to "All Products and Branches" and select "Products &...
  • Page 44 Index Approvals Installation specifications, 42 beam angle, 16 Auto false-echo suppression vessel shape notes, 16 application, 35 Instructions and manuals, 43 Auxiliary reading parameter function key, 28 PROGRAM mode, 25 Lithium batteries Safety, 26 Beam angle, 16 Beam angle spread, 16 Manuals, 43 Master reset, 30 mounting...
  • Page 45 Index Service & Support, 43 Internet, 43 Support, 43 Support request, 43 Technical data, 39 Technical support, 43 Partner, 43 Personal contact, 43 Temperature specification ambient/operating, 15 Vessel shape installation notes, 16 Wire gauge, 20 Wiring cables, 20 SITRANS Probe LR with mA/HART Compact Operating Instructions, 05/2019, A5E46248119-AC...
