EUCHNER MGBS Series Assembly Instructions Manual

Multifunctional gate box
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
Assembly Instructions
Safety System
EN
Multifunctional Gate Box MGBS

Advertisement

loading
Need help?

Need help?

Do you have a question about the MGBS Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EUCHNER MGBS Series

Summary of Contents for EUCHNER MGBS Series

  • Page 1 Assembly Instructions Safety System Multifunctional Gate Box MGBS...

  • Page 2: System Overview

    Assembly Instructions Safety System Multifunctional Gate Box MGBS 1. System overview 1.1. MGBS-P-… (escape release optional) Key: 1 Locking module or interlocking module 2 Optionally with escape release 3 Optionally with Extended version NOTICE Ì Depending on the version, additional controls and indicators may be integrated.
  • Page 3 Assembly Instructions Safety System Multifunctional Gate Box MGBS 153,85 4,15 89,4 89,4 109,4 Square drive 11,5 55,5 Profile 62,3 22,2 115,5 114,3 2150944-04-03/19 (translation of the original operating instructions)
  • Page 4 Assembly Instructions Safety System Multifunctional Gate Box MGBS (translation of the original operating instructions) 2150944-04-03/19...
  • Page 5 Assembly Instructions Safety System Multifunctional Gate Box MGBS 2. Changing actuating direction of the locking module NOTICE Ì Please read the operating instructions of the device before use. Ì If a data sheet is included with the product, the information on the data sheet applies. Ì...
  • Page 6 Safety System Multifunctional Gate Box MGBS 3. AE-R-S1 (for versions with escape release) MGBS-H...-L-... AE-R-S1 MGBS-H...-R-... 3.1. Preparing AE-R-S1 Profile width Length required for actuation Which EUCHNER parts are required? Necessary work steps axis Without plates With mounting plates (4 mm each) D+17 30 mm...

  • Page 7: Installation Examples

    Assembly Instructions Safety System Multifunctional Gate Box MGBS 4. Installation 4.1. Installation examples 6 Nm 1 Nm Figure 1: Mounting without escape release and without inner door handle 6 Nm 6 Nm 1 Nm Figure 2: Mounting with escape release and inner door handle 4.2.
  • Page 8 Edition: 2150944-04-03/19 Title: Assembly Instructions Safety System Multifunctional Gate Box MGBS (translation of the original operating instructions) Copyright: © EUCHNER GmbH + Co. KG, 03/2019 Subject to technical modifications; no responsibility is accept- ed for the accuracy of this information.
