Summary of Contents for Jabra Engage 50
- Page 1 Jabra Engage 50 User manual...
- Page 2 3.1 Adjust the microphone 3.2 Position the microphone 4. How to connect ......10 4.1 Connect to computer 4.2 Connect to computer using Jabra Engage Link (optional accessory) 4.3 Connect to mobile devices 4.4 Connect using the extension cable (optional accessory) 5.
- Page 3 1. Welcome Thank you for using the Jabra Engage 50. We hope you will enjoy it! Jabra Engage 50 features • 3-microphone system • Stereo Sound • Superwideband • Status lights on both speakers • Live microphone guidance and call analytics through Jabra software •...
- Page 4 2. Jabra Engage 50 overview 2.1 Stereo variant 2.2 Mono variant...
-
Page 5: Included Accessories
2.3 Included accessories Pouch Clothing clip 2.4 Optional accessories Optional accessories and replacement parts (ear cushions, etc.) can be purchased online at jabra.com/accessories. 120cm USB-C to USB-A extension cable 120cm USB-C to USB-C extension cable... - Page 6 Jabra Engage Link controller (USB-C or USB-A) USB-A USB-C Mute mic (press) Mute mic and Volume speaker (hold) Status light Programmable (Programmable*) button* Answer/end call *requires Jabra Direct. Download at jabra.com/direct.
-
Page 7: How To Wear
3. How to wear Wear the Jabra Engage 50 and adjust the headband for a more comfortable fit. For optimal comfort, the mono headset should be worn with the T-bar high on the side of the head, not on the ear. -
Page 8: Adjust The Microphone
3.1 Adjust the microphone The microphone boom arm can be rotated and shaped to sit close to your mouth. The notches on the boom arm indicate where to bend. Do not bend the tip of the boom arm. - Page 9 3.2 Position the microphone optimal call quality, position microphone close to the mouth (approx. 1/2” or 12mm). 1/2” or 12mm...
-
Page 10: How To Connect
4. How to connect 4.1 Connect to computer Plug the Jabra Engage 50 into a USB-C port on your computer. Ensure the headset is set as the default audio device for the speaker and microphone in your softphone’s audio settings (e.g. Skype for Business). - Page 11 4.2 Connect to computer using Jabra Engage Link (optional accessory) Plug the Jabra Engage 50 into a Jabra Engage Link controller (optional accessory). The Jabra Engage link controller plugs into a USB port on the computer, and offers call control of the Jabra Engage 50 with a large number of computer softphones.
- Page 12 4.3 Connect to mobile devices Plug the Jabra Engage 50 into a USB-C port on your mobile device. Not all USB-C devices or apps support an audio connection to the Jabra Engage 50.
- Page 13 4.4 Connect using the extension cable (optional accessory) Plug the Jabra Engage 50 into the USB-C port on the extension cable, and then plug the extension cable into a USB-A or USB-C port on your computer, depending on which extension cable is used.
-
Page 14: How To Use
The headset itself does not have call controls. When plugged into a computer, calls and music can be controlled using the computer (or by connecting to a Jabra Engage Link controller). 5.1 Status light The Status light on the headset indicates... - Page 15 Sidetone settings can be configured using Jabra Direct. 5.3 Reverse stereo Reverse stereo enables the left and right audio channels to be switched in the stereo headset. Reverse stereo settings can be configured using Jabra Direct.
-
Page 16: Jabra Direct
6. Jabra Direct Jabra Direct is computer software designed to support, manage, enable optimal functionality for your Jabra devices. Download via jabra.com/direct... - Page 17 Jabra Direct will notify you when there is a firmware update available for the headset. During the firmware update process, the LEDs on the Jabra Engage 50 will light up purple. Do not disconnect the Jabra Engage 50 during the firmware update process.
- Page 18 7. Support 7.1 FAQ View the FAQs on Jabra.com/engage50.
- Page 19 ® © 2018 GN Audio A /S. All rights reserved. Jabra is a trademark of GN Audio A/S. MADE IN CHINA MODEL: ENC080 Declaration of Conformity can be found on www.jabra.com/doc...
