F e d e r a l C o m m u n i c a t i o n s C o m m i s s i o n S t a t e m e n t ( C l a s s A)
NOTE- This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by tuning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/television technician for help.
C l a s s A I T E :
Class A ITE is a category of all other ITE which satisfies the class A ITE limits but not the class B ITE limits.
Such equipment should not be restricted in its sale but the following warning shall be included in the
instructions for use:
Warning - This is a class A product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
C E C l a s s A ( E M C )
This product is herewith confirmed to comply with the requirements set out in the Council
Directives on the Approximation of the laws of the Member States relating to Electromagnetic
Compatibility Directive 2004/108/EEC.
Warning - This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures to correct this interference.
D I S C L AI M E R
No warranty or representation, either expressed or implied, is made with respect to the contents of this
documentation, its quality, performance, merchantability, or fitness for a particular purpose. Information
presented in this documentation has been carefully checked for reliability; however, no responsibility is
assumed for inaccuracies. The information contained in this documentation is subject to change without
notice.
In no event will AVer be liable for direct, indirect, special, incidental, or consequential damages arising out of
the use or inability to use this product or documentation, even if advised of the possibility of such damages.
T R AD E M AR K S
AVerVision is registered trademarks of AVer Information Inc. IBM PC is a registered trademark of
International Business Machines Corporation. Macintosh is a registered trademark of Apple Computer, Inc.
Microsoft is a registered trademark and Windows is a trademark of Microsoft Corporation. All other products
or corporate names mentioned in this documentation are for identification and explanation purposes only,
and may be trademarks or registered trademarks of their respective owners.
C O P Y R I G H T
© 2011 by AVer Information Inc. All rights reserved. No part of this publication may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any
language in any form by any means without the written permission of AVer Information Inc.
ENGLISH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M30 and is the answer not in the manual?

Questions and answers

Summary of Contents for AVerVision M30

  • Page 1 T R AD E M AR K S AVerVision is registered trademarks of AVer Information Inc. IBM PC is a registered trademark of International Business Machines Corporation. Macintosh is a registered trademark of Apple Computer, Inc.
  • Page 2 ENGLISH THE MARK OF CROSSED-OUT WHEELED BIN INDICATES THAT THIS PRODUCT MUST NOT BE DISPOSED OF WITH YOUR OTHER HOUSEHOLD WASTE. INSTEAD, YOU NEED TO DISPOSE OF THE WASTE EQUIPMENT BY HANDING IT OVER TO A DESIGNATED COLLECTION POINT FOR THE RECYCLING OF WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT.
  • Page 3: Table Of Contents

    Connecting a Computer via USB Connection......... 8   Installing the Optional Light Box ............. 9   Connecting to a Microscope ..............9   Setting Up AVerVision M30 ............10     Camera Head ..................10 Mechanical Arm ..................10  ...
  • Page 4: Introduction

    ENGLISH Thank you for purchasing the AVerVision M30. This document camera displays any documents, negatives, transparencies and 3D objects onto a TV, LCD or DLP projector making presentations a snap. AVerVision M30 is an ideal presentation tool for business, academic, medical and the scientific community.
  • Page 5: Optional Accessories

    ENGLISH 34mm Microscopic Adapter 28mm Microscopic Adapter Carrying Bag Light Box Microscopic Coupler LED Lamp with Laser Positioning Pointer...
  • Page 6: Avervision M30 Parts

    ENGLISH The illustrations below identify the parts of AVerVision M30 (1) Camera head (2) LED light module (3) Camera lens (4) Control panel (5) Arm (6) Left panel (7) IR sensor (8) Rear panel (9) Right panel (10) Power button...
  • Page 7: Technical Specifications

    ENGLISH Image Sensor 1/2” progress scan CMOS Total Pixels 3.2 mega pixel Frame Rate 24 fps (Max.) White Balance Auto / Manual Exposure Auto / Manual / Flicker / Night View Image Mode Text / Graphics / High Frame Effect Color / B/W / Negative;...
  • Page 8: Making The Connections

    ENGLISH The ports on the back and side panel of the AVerVision M30 enable you to connect the unit to a computer, graphics display monitor or LCD/DLP projector, TV or other device. Illustrated below are the ports that are located at the back and side panel of the AVerVision M30 with their corresponding labels.
  • Page 9: Connecting The Power Adapter

    ENGLISH Connect the power adapter to a standard 100V~240V AC power source. LIGH T DC12 V VGA IN VGA OUT Wall outlet Power adapter Power cord Locate the video, s-video or SCART RGB input port of the TV or Video equipment (i.e., VCR) to record your presentation on a videotape.
  • Page 10: Connecting A Vga, Mac Display Monitor Or Lcd/Dlp Projector

    ENGLISH Locate the RGB (VGA) input port of the display device. If you are not sure, please refer to the user manual of the device. Make sure the TV/RBG switch is set to RGB. LIGH T DC12 V VGA IN VGA OUT RGB (VGA) cable LCD/DLP projector...
  • Page 11: Connecting A Computer Via Usb Connection

    Monitor Adapter (not supplied) Locate the USB port of the computer or laptop. This enables you to use AVerVision M30 as a USB Camera or to transfer the captured images from the built-in memory to your computer. Also see “Transfer Image from AVerVision M30 to PC” and refer to the bundled software user guide in the CD.
  • Page 12: Installing The Optional Light Box

    Connecting an optional light box enables you to view x-rays, transparencies and negative slides. TURN ON Light Box (optional) PLUG IT HERE Connecting the AVerVision M30 to a microscope enables you to examine microscopic objects on a big screen without straining your eyes. Microscope Coupler Microscope Adapter Press the latch to detach...
  • Page 13: Setting Up Avervision M30

    ENGLISH This section provides useful tips on how to adjust the AVerVision M30 to meet your needs. The camera head can be rotated 135 degrees from left to right. You can also manually adjust the focus from here to improve the quality of the pictures.
  • Page 14: Led Light Module

    ENGLISH The LED light module provides white light and it is best use when presenting in low lighting condition. Turn On Turn On Turn Off Turn Off The anti-glare sheet is a special coated film that helps eliminate any glare you may encounter when you are displaying very shiny object or glossy surfaces such as magazines, pictures, etc.
  • Page 15: Using The Infrared Remote Control

    ENGLISH The remote control requires two (2) “AAA” size batteries (supplied), make sure batteries are installed properly before use. You can access all the features of AVerVision M30 with the remote. (23 ) (22 ) (21 ) (20 ) (10 )
  • Page 16 ENGLISH Name Function SLIDE SHOW Start/Stop automatically showing the captured picture one-by-one. EFFECT Convert and display the image in BW, Negative or Color in Camera and Playback mode only. (10) CAPTURE Capture still image in Camera mode. In continuous capture mode, press this button again to stop.
  • Page 17: Touch Button Control Panel

    ENGLISH The touch button control panel located on the top side of the AVerVision M30 provides quick access to commonly used functions. (10 ) Function Description Switch between Camera and computer mode. CAMERA / PC - Camera mode displays the video signal from the built-in camera.
  • Page 18: Led Panel

    ENGLISH The LED on the front panel of AVerVision M30 indicates the status of the unit. Color Description Green The unit is operated with VGA output. Orange The unit is operated with TV output The unit is in standby mode.
  • Page 19: Setting Menu

    ENGLISH SETTING MENU The MENU functions of AVERVISION M30 enhance fine-tuning your screen display, set the timer, select OSD language and more. Press the MENU button to call up and exit from the main menu or sub-menu display. Use ◄or► to select between IMAGE and SETTING menu list.
  • Page 20 ENGLISH OSD Menu Description IMAGE > EFFECT EFFECT COLOR B / W Use ▲or▼ to select and display the image in Camera mode NEGATIVE into positive (true color), monochrome (black and white) or negative. Then press ENTER to make a selection. IMAGE >...
  • Page 21 If you are presenting in a low-light condition, Night View enables the image of the object to appear as though under normal lighting conditions. AVERVISION M30 can automatically adjust the exposure to compensate for the adverse condition, but the captured image will appear to be in slow motion.
  • Page 22 ENGLISH OSD Menu Description SETTING > LANGUAGE LANGUAGE ENGLISH Use ▲or▼ to select from different supported languages then FRANÇAIS ESPAÑOL press ENTER to make the selection. PORTUGUÊS 日本語 繁體中文 SETTING > USB CONNECTION USB CONNECTION USB CAMERA Use ▲or▼ buttons to select the function of USB between USB IMG DOWNLOAD CAMERA and IMG DOWNLOAD.
  • Page 23: Transferring The Captured Image To Pc

    USB cable. 3. Upon connecting the USB cable, the system automatically detects the new removable disk. You may now transfer the captured image(s) from the AVERVISION M30 built-in memory to PC hard disk. AVerVision M30 can be controlled using a PC through RS-232 connection.
  • Page 24: Rs-232C Transmission Spec

    ENGLISH :1 bit Star bit Data bit :8 bit Stop bit :1 bit Parity bit :None X parameter :None Baud rate(Communication speed) :9600bps Start Code(1 Byte) : 0xFF Type Code(1 Byte) : 0x70 DataLength Code(1 Byte) : 0x01 Data Code(1 Byte) : See the Command Table for reference.
  • Page 25: Troubleshooting

    I cannot get a picture on the preferred presentation screen. 1. Once the power is connected, the LED light turns RED in standby mode. Simply switch the AVerVision M30 “ON" by pressing the on/off switch until the LED light is blinking and turns GREEN.
  • Page 26: Limited Warranty

    4. After you follow these steps, you should be able to see the same desktop image on your PC or Notebook as well as on the presentation screen. How do I transfer the images from AVERVISION M30 to a computer? Is it normal that AVERVISION M30 will reset to camera mode after I download images and disconnect the USB cable? Choose "IMG DOWNLOAD"...
  • Page 27 ENGLISH Limitations of Warranty AVer makes no warranties to any third party. You are responsible for all claims, damages, settlements, expenses, and attorneys’ fees with respect to claims made against You as a result of Your use or misuse of the Product. This warranty applies only if the Product is installed, operated, maintained, and used in accordance with AVer specifications.
