Luowice R8 Installation Instructions

Hide thumbs Also See for R8:

Camera Installation Instructions

Please refer to the below image and adjust the Antenna till it is at an angle of

90 degrees to the camera. Please avoid the Antenna and the camera to be in a

straight line.

Note：Please screw the antenna on till it is in 90 degree to the camera.

Please avoid screwing the antenna too harsh after it is screwed firmly to the

camera. Otherwise the screw interface will be damaged.

Table of Contents

Do you have a question about the R8 and is the answer not in the manual?

Page 1 Camera Installation Instructions 1. Screw the antenna Please refer to the below image and adjust the Antenna till it is at an angle of 90 degrees to the camera. Please avoid the Antenna and the camera to be in a straight line.
Page 2 2. Assemble the Camera and the Bracket Please avoid adjusting the angles of the camera bracket directly by hand. The angles of camera shall be adjusted via the PTZ function on the mobile APP or PC Client. Adjusting the bracket manually might cause damage to the PTZ function. Please put the wires (5, 6, 7) through the bracket (4) one by one.
Page 3 3. Configure your camera to router Please refer to the user guide or visit the video instruction, and configure your camera to router on a wired/wireless connection via phone app (CamHipro). Access this page to the YouTube Video instruction. www.youtube.com/watch?v=YncokKOK9hE&feature=youtu.be Or scan the QR code below to view the YouTube Video instruction.
Page 4 4.Choose a location and Mount your camera to the wall. Please refer to the below instructions to mount your camera. ①Place the mount in its desired location. ②Using a sharpie, make marks on the wall where each screw should go. ③Drill a hole for each screw using an electric drill ④Hammer in any molding pins.
