- Page 1 Installation Instructions and Owner’s Manual CITY Series Water Softening and Filter System First Sales, LLC 12630 US Highway 33 N Churubusco, IN 46723 Phone (260) 693-1972 Fax (260) 693-0602 CITY Series Instruction Manual 190829.docx...
-
Page 2: Table Of Contents
Page 7 CITY Series Programming Page 8 Specifications Page 10 Component Parts Breakdown & List Page 11 CITY Series Control Valve Breakdown Page 12 CITY Series Control Valve Parts List Page 13 Troubleshooting Page 14 Ten Year Limited Warranty Page 16... -
Page 3: Pre-Installation Instructions
The softener resin exchanges the hardness ions for softer ions. The softened water then returns to the control valve where it is directed into the service lines. The CITY Series water softener/filter is designed to be installed on chlorinated municipal water supplies. - Page 4 Pre-installation Instructions (cont.) Location Considerations The proper location to install the water softener and filter system will ensure optimum performance and satisfactory water quality. The following factors should be considered in selecting the location of the equipment. 1. The water softener and filter system should be installed after the water meter on municipal water.
-
Page 5: Installation Instructions
Installation Instructions STEP 1: If filter media is already in the media tank, proceed to step 3. If media is shipped separately, remove the fill port cap by turning it counter-clockwise with the wrench provided. After fill port cap is removed also remove the filter screen inside the fill port. Add media through the fill port using a funnel. -
Page 6: Brine Tank
Installation Instructions (cont.) Connect one end of the 3/8” brine line to the control valve quick connect fitting. Insert the STEP 8: other end of the brine line through the hole in the brine tank and into the quick connect fitting on the safety brine valve. -
Page 7: Media Replacement
Installation Instructions (cont.) STEP 13: Unplug the softener from the electrical outlet to keep it in the backwash position. Refer to Figure 3 (page 6) for appropriate bypass valve operation. Rotate bypass lever of stainless steel bypass ¼ of the way to “Service” allowing unit to fill slowly. You should hear water trickling into the mineral tank. -
Page 8: City Series Programming
CITY Series Programming Advance Button FIGURE 4: Front of Electronic Meter Timer Assembly SET BUTTON 1. Press and hold “Set Button” for 5 seconds to enter Programming Mode. 2. When valve is in Programming Mode, press “Set Button” to confirm setting and advance to next menu option. - Page 9 CITY Series Programming Enter Programming Mode: Press and Hold the SET Button for 5 seconds. Use Up Button to set current hour Use Up Button to set current minute Use Up Button to set AM/PM Use Up Button to set ADJUSTED Hardness...
-
Page 10: Specifications
Specifications Model Number Description CITY-1-S CITY-1.5-S Volume of media, cu. ft. Granular Activated Carbon Hi Capacity Softener Resin Gravel Underbed, lbs. per tank Operating Flow Rate, gpm Continuous (no duration limit) Peak (10 mins. or less) Regen. Flow Rates, gpm Backwash &... -
Page 11: Component Parts Breakdown & List
Component Parts Breakdown UNIT Description CITY-1-S CITY-1.5-S O-ring, -324 ORG-324 ORG-324 Connector Nut C102 C102 Split Ring Retainer C101 C101 CITY-1 Vlv Assy CITY-1.5 Vlv Assy Elect. Metered Valve w/bypass w/BP w/BP Distributor Head w/Fill Port FP207 FP207 Screen for Fill Port FPS101 FPS101 Distributor... -
Page 12: City Series Control Valve Breakdown
CITY Series Control Valve Breakdown... -
Page 13: City Series Control Valve Parts List
CITY Series Control Valve Parts List Part REF # Description Number NE-PH Powerhead, Metered NE-FC Front Panel and Circuit Board Assembly 60102-NES Piston Assembly 60125 Seal and Spacer Kit 60084- Injector and Drain Housing Assy, 2.4 gpm DLFC, #1 Injector, 1 GPM BLFC... -
Page 14: Troubleshooting
Troubleshooting PROBLEM CAUSE SOLUTION A. Ensure permanent electrical service A. Electrical service to unit has been to unit (switch, circuit breaker, plug, interrupted etc.) 1. Softener fails to regenerate B. Meter cable not inserted into meter B. Insert meter cable into meter C. - Page 15 Troubleshooting PROBLEM CAUSE SOLUTION A. Iron exceeds recommended level A. Test incoming water supply and or is not “Clearwater” iron or iron install OXY Series iron filter prior to bacteria is present softener, as needed 7. Iron in softened water B.
-
Page 16: Ten Year Limited Warranty
TEN YEAR LIMITED WARRANTY WARRANTY – First Sales, LLC. warrants this water conditioner against any defects that are due to faulty material or workmanship during the warranty period. This warranty does not include damage to the product resulting from accident, neglect, misuse, misapplication, alteration, installation or operation contrary to printed instructions, or damage caused by freezing, fire, flood, or Acts of God.
