Summary of Contents for Teradek CTRL.1
- Page 1 CTRL.1 CONTROLLER KIT Quick Start Guide © 2018 Teradek, LLC. All rights reserved.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Physical Properties ......2 Power and Connect ......3 Pair Controller and Latitude ....3 Camera Run/Stop ........ 4 Lens Mapping Feature ......4 Controller Menu Operation ....5 Wireless Configuration ......6 Standalone Operating Modes ..... 6... -
Page 4: Physical Properties
PHYSICAL PROPERTIES MOTR.X CTRL.1 OLED display Menu buttons (Menu, Up, Down, and Set) Record/Power button Controller Status LED Mini-B USB Wired-mode port Lens ring Control knob Motor class indicators Axis button Data/Power connectors Operating Mode button Receiver Status LED Reset button... -
Page 5: Power And Connect
POWER AND CONNECT Connect power to Latitude’s PWR port (N). Attach the motor(s) to the rods/lens. Connect the motor to Latitude using a 4-pin connector. If connecting two motors, use a Y-cable 4-pin connector to connect both motors. The motor(s) will then begin calibrating. Insert an LP-E6 battery in the controller and hold down the POWER button for two seconds. -
Page 6: Camera Run/Stop
(Redlink Command Protocol) for the unit to operate. LENS MAPPING The Lens Mapping Package can be purchased with the CTRL.1, or as a seperate upgrade. After purchasing the Lens Mapping Package, use the following steps to activate it. Press the MENU button, then use the ▼ button to navigate to the ADV (Advanced) menu. Press the SET button to access the menu. -
Page 7: Controller Menu Operation
CONTROLLER MENU OPERATION Press the MENU button, then use the ▲, ▼ and SET button to navigate through the different menu options. • POWER OFF - Power OFF the controller • SCREEN - Change display settings • LENS - Configure lens mapping function •... -
Page 8: Wireless Configuration
STANDALONE OPERATING MODES LATITUDE M and MB receivers have several different operating modes. To change the receiver’s operating mode, press the recessed operating mode button (K). Standard Mode - GREEN LIGHT This is the default operating mode. LATITUDE will accept controller (wireless) and/or thumbwheel commands, and forward them to the motor(s) and camera. - Page 9 Admin Password PASSWORD Teradek regularly releases new firmware versions to improve performance, add new features, or to fix vulnerabilities. Visit https://www.teradek.com to update your device with the latest firmware. NEED MORE HELP? SUPPORT: http://support.teradek.com → Contains tips, information and all the latest firmware &...
