Leben im Bad
Living bathrooms
X-Large
# XL 013C
Installation instructions
800-1000
45
45
Follow all other installation instructions!
2x
# UV 9917
Instructions for use
The bathroom furniture range complies with the standards and guidelines applicable at the time of delivery and is designed for use in bathrooms.
Direct contact with water should be avoided, for example, when showering.
The console is not suitable for installation from below with semi built-in and built-in washbasins.
Ceramics wider than 600 mm must be fixed to the wall.
We reserve the right to make technical improvements and design modifications to the products illustrated.
MAL_X-Large_XL013C/14.10.2
