Schroeder America 950R Installation Instruction, Parts List And Configuration Manual

Recirculating bar dispenser (bar gun)
Hide thumbs

Advertisement

Quick Links

Download this manual
INSTALLATION INSTRUCTION, PARTS LIST
RECIRCULATING BAR DISPENSER
The information contained in this document is subject to change without notice.
SCHROEDER AMERICA MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS MATERIAL, INCLUDING,
BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. SCHROEDER AMERICA shall not be liable for errors contained herein or for incidental consequential
damages in connection with the finishings, performance, or use of this material.
This document contains proprietary information which is protected by copyright. All right reserved.
This manual must be read and understood before the installation and operation of this dispenser.
AND CONFIGURATION GUIDE
FOR THE
(BAR GUN)
Dispenser Model No. 950R
NOTICE:
© Copyright 2015 by Schroeder America, all rights reserved.
THIS DOCUMENT CONTAINS IMPORTANT INFORMATION
Schroeder America
5620 Business Park • San Antonio, TX 78218
210.662.8200 • Fax: 210.667.2600 • www.schroederamerica.com
Toll-Free 877.404.2488
Please refer to the Schroeder America website (www.schroederamerica.com)
for information relating to Schroeder America installation and Service
Manuals, Instruction Sheets, Technical Bulletins, Service Bulletins, etc.
3158001
Rev: 1/17
PN: 805-0006

Advertisement

loading
Need help?

Need help?

Do you have a question about the 950R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Schroeder America 950R

Summary of Contents for Schroeder America 950R

  • Page 1 BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. SCHROEDER AMERICA shall not be liable for errors contained herein or for incidental consequential damages in connection with the finishings, performance, or use of this material.
  • Page 2 1. INSTILLATION IMPORTANT THIS EQUIPMENT TO BE INSTALLED WITH ADEQUATE BACKFLOW PROTECTION. A. Attach the base plate, smooth side out, in the desired location with #8 screws (supplied). The screws are slightly larger than the holes. This helps hold screws in position for mounting. 1.
  • Page 3 This will equal the flow rate. NOTE: The Schroeder America Bar Dispenser is designed to flow 1.25 oz/sec. or 6.25 oz/5 sec. This is the proper setting for 5:1 ratio. B. To adjust flow control assembly remove the red cap to expose the slotted red adjustment screw (Fig 2.1).
  • Page 4 3. RECIRCULATION LOOP ADJUSTMENT A. All bar guns are preset to the minimum flow level at the factory prior to shipment. B. If additional cooling is required, turn the plug adjust “IN or Clockwise” to obtain additional flow on the R “IN” valve assembly. C.
  • Page 5 H. Place new o-ring on the plain end of the tool, lubricate with a small amount of lubricant. I. Install o-ring into hole in the handle, making sure it is firmly seated at the end or bottom of the channel. NOTE: It is important that a food grade lubricant is used.

  • Page 6: Cleaning And Maintenance

    S. Reattach bar gun handle assembly to the FCM module. 7. CLEANING AND MAINTENANCE The Schroeder America Bar Dispenser is shipped from the factory cleaned and sanitized in accordance with NSF guidelines. The bar dispenser must also be cleaned and sanitized after installation is complete.
  • Page 7 IMPORTANT ONLY USE INTERNAL CLEANING SOLUTIONS THAT ARE APPROVED FOR BEVERAGE DISPENSER APPLICATIONS, SUCH AS BevClean™. (NO CAUSTIC CHEMICALS SUCH AS INDUSTRIAL KITCHEN CLEANING CHEMICALS SHOULD EVER BE USED) B. Sanitizing Sanitizing solutions must provide 50 to 100 parts per million (PPM) available chlorine. Any sanitizing solution may be used as long as it is prepared in accordance with the manufacturer’s recommendations.
  • Page 8 NOTE: Alternate turning each separator screw to evenly remove the bar gun manifold from the module. The Shut-off tool (P.N. 316-0005), or a screw driver, can be used to aid in removing the dispenser assembly but is not necessary. The red screws can be turned by hand with no tools. Fig.

  • Page 9: Troubleshooting

    8. REATTACHING THE BAR GUN ASSEMBLY A. Adjust the red screw separators on the outside of the bar gun assembly so the small smooth shank is exposed. B. Slide the bar gun manifold into the FCM module. C. Snap red retainers into the locked position. D.
  • Page 10 ACCESSORIES 1/4 BARB, STAINLESS STEEL FITTING 3/8 BARB, STAINLESS STEEL FITTING P.N. 625-0004 P.N. 625-0005 O-RING P.N. 208-0010 O-RING P.N. 208-0010 3/8 90 DEG BARB, STAINLESS STEEL FITTING 3/8 45 DEG BARB, STAINLESS STEEL FITTING P.N. 625-0011 P.N. 625-0012 O-RING P.N. 208-0010 O-RING P.N.
  • Page 11 ACCESSORIES SHUT-OFF TOOL FLOW CONTROL TOOL P.N. 316-0005 P.N. 316-0006 SEPARATOR O-RING TOOL P.N. 316-0004 P.N. 316-0003 SANITARY HOLSTER & DRAIN SPLITTER ASSEMBLY, WATER P.N. 675-0017 P.N. 631-0049 BLACK HOLSTER KIT, WITH MOUNTING SCREWS O-RING P.N. 208-0010...
  • Page 12 BUTTERFLY PLATE CONFIGURATION 950-02100- 950-03200- 950-04300- 950-05400- 1 Button 2 Button 3 Button 4 Button Butterfly Plate Assy Part Number 634-0001 634-0002 634-0003 = Secondary Water Metering Screw Affects These Positions = Carbonated Positions ® = Requires Soda/Water Button Foot (P.N. 265-0039/265-0040) = Non-Carbonated Positions Extensions Into Bottom Of Button Where Symbol Appears.
  • Page 13 MOUNTING PLATE SCREW PLACEMENT 7 VALVE MOUNTING PLATE 5 MOUNTING SCREWS USE THESE MOUNTING HOLES USE THESE MOUNTING HOLES USE THESE MOUNTING HOLES USE THESE MOUNTING HOLES USE THESE MOUNTING HOLES FOR BEST STABILITY FOR BEST STABILITY FOR BEST STABILITY FOR BEST STABILITY FOR BEST STABILITY PATENTS...

  • Page 14: Handle Assembly

    HANDLE ASSEMBLY...
  • Page 15 HANDLE ASSEMBLY RECIRCULATING BARGUN HANDLE PARTS LIST ITEM SCHROEDER PN DESCRIPTION 645-0112 SUB-ASSY,BARGUN HANDLE,5BRC,RED 645-0198 SUB-ASSY,BARGUN HANDLE,8BRC,RED 210-0006 SEAL,HANDLE 265-0084 BODY,NOZZLE,RED 265-0001 RETAINER,BUTTERFLY 220-0001 SCREW,6-32x.375,100 DEG FHP 220-0010 SCREW,6-32x.500,SL,FHD,SS 265-0224 PLATE,BUTTON,5B,RED 265-0197 PLATE,BUTTON,8B,RED 265-0004 ACTUATOR,WATER/SODA NOT USED 265-0007 ACTUATOR,SINGLE 265-0296 BUTTON,CARB 631-0130 PLATE SUBASSY,PLUNGER,RETAINER,5BRC,RED...

  • Page 16: Manifold Assembly

    MANIFOLD ASSEMBLY...
  • Page 17 MANIFOLD ASSEMBLY RECIRCULATING BARGUN MANIFOLD PARTS LIST ITEM SCHROEDER PN DESCRIPTION 265-0321 BASE,MOUNTING,5BRC,GRAY 265-0074 BASE,MOUNTING,10B,GRAY 265-0323 HOUSING,TUBING,5BRC,GRAY 265-0399 HOUSING,TUBING,8BRC,GRAY 265-0322 COVER,HOUSING,TUBING,5BRC,GRAY 265-0398 COVER,HOUSING,TUBING,8BRC,GRAY 265-0076 SCREW,SEPARATOR 808-0053 LABEL,SERIAL NUMBER,BARGUN 265-0264 FERRULE,FITTING,MANIFOLD 265-0061 FITTING,INLET,GUN 208-0010-429 O-RING,2-010 626-0002 FITTING ASSY,INLET,GUN (W/ O-RINGS) 215-0005 SPRING,PIN,LATCH 248-0003 E-RING,.250...
  • Page 18 FLOW CONTROL MODULE ASSEMBLY...
  • Page 19 FLOW CONTROL MODULE ASSEMBLY RECIRCULATING BARGUN FLOW CONTROL MODULE PARTS LIST ITEM SCHROEDER PN DESCRIPTION 265-0324 HOUSING,VALVES,5BRC,GRAY 224-0002 SCREW,8-16x.375,PLASTITE,PHSL,PHD 808-0053 LABEL,SERIAL NUMBER,BARGUN 637-0002 ASSY,VALVE,BACKBLOCK,GRAY 265-0047 BACKBLOCK,GRAY 208-0110 O-RING,2-110 265-0044 STEM,BODY 625-0009 STEM ASSY,SHUT-OFF (W/ O-RING) 256-0011 RETAINER,STEM 265-0043 WASHER,STEM 208-0010 O-RING,2-010 279-0016 FITTING,.375 O-RING X .250 BARB...
