BARRETT
2019 Automatic Tuning Mobile HF Antenna

Installation Instructions

The Barrett 2019 antenna plugs directly into the "ATU" and "RF" connectors located on
the transceiver using the cables supplied.
The Barrett 2019 antenna can be fitted with an optional internal GPS. This internal unit can
be used to provide GPS data as part of a GPS tracking network without the need to install a
separate GPS thereby simplifying the system installation.
The GPS unit is connected via the integrated coaxial, control and GPS cable supplied with
the Barrett 2019 antenna. The interface cable is supplied with the 3 connectors as standard
even if the GPS unit is not fitted.
Important:-
The transceiver must have the 2019 antenna option set during
programming.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2019 Automatic Tuning Mobile HF Antenna and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Barrett 2019 Automatic Tuning Mobile HF Antenna

  • Page 1: Installation Instructions

    The Barrett 2019 antenna can be fitted with an optional internal GPS. This internal unit can be used to provide GPS data as part of a GPS tracking network without the need to install a separate GPS thereby simplifying the system installation.
  • Page 2 Transceiver Connection Diagram 2019 automatic tuning HF mobile antenna 2050 control head Cable with RJ45 connectors (P/N BCA29995) Microphone Heavy duty fuse & holder (P/N BCA20021) supplied in mobile pack. 6 metre power cable supplied with transceiver 2050 transceiver body Extension speaker supplied with 2050 transceiver Connection for external fan unit Interface cable –...
  • Page 3 Mounting the 2019 Automatic Tuning Mobile HF Antenna The Barrett 2019 antenna should be mounted in positions similar to those illustrated in the diagrams on the following pages. Select a position free from excessive vibration. A bracket, fabricated to withstand the forces and vibration that can be expected during off-road driving, should be used to mount the antenna to the vehicle.
  • Page 4 Do not mount the Barrett 2019 antenna in positions such as these as damage to the antenna may result.
  • Page 5 Antenna Assembly Mounting the Base Spring The base spring should only ever be hand tightened, if a tool is used it may damage the spring base.
  • Page 6 Mounting the Whip Sections To mount the whip section it is recommended that only one section of the whip is screwed onto the antenna at a time. The whip section should be hand tightened fully then a suitable tool (ie: a spanner) can be used to tighten the section a further 10 to 20 degrees clockwise while holding the antenna body with a free hand.
  • Page 7 (not chassis or battery), check the whip fitted is not faulty or incorrect and move the vehicle if the Barrett 2019 antenna is close to any metal fences, buildings etc. If the problem cannot be resolved, contact...
  • Page 8 BARRETT COMMUNICATIONS © Barrett Communications Head Office: Barrett Communications Pty Ltd 47 Discovery Drive, Bibra Lake, WA 6163 Australia Tel: +61 8 9434 1700 Fax: +61 8 9418 6757 Email: information@barrettcommunications.com.au www.barrettcommunications.com.au...
