Welcome!
Give professional presentations
with your Logitech
®
Cordless
™
Presenter
without the hassle
of cords or the limitation of
line-of-sight operation with
your notebook computer or PC.
This cordless device uses
™
Bluetooth
Technology to
transmit data up to 30 feet
(10 meters). With its technical
simplicity and comfortable
shape, it lets you focus on
your delivery. Conveniently
placed Forward and Back
buttons help you page through
slides effortlessly, and a built-in
laser pointer gives you
the option of highlighting key
concepts on-screen with
the touch of a button.
Change modes with a single
switch to use your Logitech
Cordless Presenter
™
on
a tabletop as a two-button
optical mouse with scroll
buttons. And while in Mouse Mode, you can assign special operations, such as double-click, to one of the mouse
buttons using Logitech's MouseWare
Battery status LED
Scroll up button
Connection
status LED
Forward button
Scroll down button
Back button
®
®
software.
Top View
®
Logitech
Cordless Presenter
Light for laser
pointer exits
here
Connect button
Mode switch
Laser pointer
button
Battery
compartment
door
Bottom View
™
English
1
Advertisement
Table of Contents
Related Manuals for Logitech Cordless Presenter
Summary of Contents for Logitech Cordless Presenter
- Page 1 Battery laser pointer gives you compartment the option of highlighting key door concepts on-screen with the touch of a button. Change modes with a single switch to use your Logitech ® Top View Bottom View Cordless Presenter ™ ® ™...
- Page 2 15 minutes until a radio Mini-receiver frequency connection is made with the presentation device. You make this connection by pressing the Connect button on the Logitech ® ™ Cordless Presenter If this connection is not made within Extension cable...
-
Page 3: Install The Batteries
Install the Batteries The Logitech ® Cordless Presenter ™ uses two AA alkaline batteries. Install the batteries before installing the software. 1. Remove the battery door (picture 1). Place your thumb on the indentation at the top of the battery door. Gently press down and carefully slide the door off. -
Page 4: Install The Software
Install the Software If your batteries leak, use normal precaution and follow the battery manufacturer's recommendations. ® To use all the features of the Logitech When replacing batteries, use alkalines. You may use ™ Cordless Presenter , make sure to install the software. - Page 5 Using the Presentation Device The Logitech ® Cordless Presenter ™ has two modes: Presentation Mode and Mouse Mode. Use the Mode switch on the bottom of the presentation device to turn on the device and to switch between these two modes.
- Page 6 Presentation Mode Mouse Mode Mode Switch Mode Switch In Presentation Mode, In Mouse Mode, the the Forward (left) button Forward (left) button displays the next screen performs a “click/select” (or page). The Back function. The Back (right) (right) button displays button performs the previous screen a “context/alt select”...
- Page 7 Rated as a commercial product for operations Carrying Case at: 0° C - 40° C (32° F - 104° F) ® Please use the carrying case to protect the Logitech This product has been tested to comply with Cordless Presenter ™...
- Page 8 . However, you cannot modify the scrolling buttons. ® To launch MouseWare , select Start/Programs/Logitech MouseWare/Mouse Properties, or click the mouse icon on the Taskbar. To change button assignments, click the Button’s Tab. Refer to the online help for more information about making button assignments.
-
Page 9: Troubleshooting
Your product comes with a limited five-year warranty. For more information, refer to the Product Warranty section of the User’s Guide located on the Logitech ® software CD. * For troubleshooting information, also refer to the User’s Guide on the Logitech ® software CD, which was copied to your computer’s hard drive. English...
