Logitech PRO 2 LIGHTSPEED Manual

IN THE BOX

SETUP INSTRUCTIONS

1. A wireless receiver attached to the USB adapter can be found in the accessory box. Plug one end of the cable into your PC, and the other end into the USB adapter and receiver.

   • The receiver can also be used plugged directly into your PC. However, using the cable and adapter when in wireless mode is recommended and allows for better connectivity and easy access to the cable for recharging.
2. Turn mouse on via the switch on the bottom of the mouse.

3. Download Logitech G HUB.
   logitechG.com/support/pro-2-lightspeed
4. To charge, disconnect the cable from the adapter and plug into the front of the mouse. Your mouse will operate in data‑over‑cable mode whenever it is plugged in directly to a PC. Full charge from empty requires around 2 hours plugged in to a PC USB port.


Tips:

• Keep the mouse and receiver 2 m+ away from wireless routers or other 2. 4GHz wireless devices to minimize environmental noise.
• PRO 2 LIGHTSPEED has a wireless range of up to 10 meters. To ensure optimal performance in noisy wireless environments, and to keep the charging cable easily accessible, it is recommended to keep the receiver within 20 cm of the mouse.


BUTTON CONFIGURATIONS

PRO 2 LIGHTSPEED comes with replaceable buttons and button caps, which are held onto the mouse magnetically. These should be stored in box when not in use. These replaceable buttons support conversion to the following configurations:

1. Right handed

2. Left handed

3. No buttons

4. Full buttons


8 FULLY PROGRAMMABLE BUTTONS

1. Left (Button 1)
2. Right (Button 2)
3. Wheel click (Button 3)
4. Back (Button G4)
5. Forward (Button G5)
6. Back (Button G6)
7. Forward (Button G7)
8. DPI cycle (bottom of mouse, Button 8)
9. Receiver storage door + POWERPLAY module enclosure (bottom of mouse)
10. On/Off switch (bottom of mouse, not programmable)

BATTERY LIFE

PRO 2 LIGHTSPEED has a rechargeable 290mAH LiPol battery which provides it with up to 95 hours non‑stop gaming at 1ms report rate with lights off, or 60 hours non‑stop gaming at 1ms report rate with RGB color cycling on. *

• Charge level can be checked when the mouse is powered on or using Logitech G HUB to assign a button to check charge level.
• Charge level is displayed for seven seconds at mouse power‑on using the color and number of bars illuminated on the DPI indicator:
  • 3 green dots = 50–100%
  • 2 green dots = 30–50%
  • 1 green dots = 15–30%
  • 1 flashing red dot = <15%

Tips:

• You can program a button to show charge level using G HUB.
• The bottom dot will flash red when battery is at 15% or less. When this happens, plug in your mouse to charge.
• Charge level, power draw, and estimated remaining battery life can be checked in Logitech G HUB.

* Battery life and capacity may vary with age and use. Rechargeable batteries have a limited number of charge cycles.

CHARGING/DATA OVER CABLE

Plug your mouse in via the provided USB charging cable when the battery is low. PRO 2 LIGHTSPEED is also compatible with the Logitech G POWERPLAY wireless charging system, sold separately.

LOGITECH G HUB SOFTWARE

You can customize the onboard profile settings using Logitech G HUB. These settings include button programming, report rate and tracking behavior. PRO 2 LIGHTSPEED allows up to 5 DPI settings. By default, PRO 2 LIGHTSPEED has the following settings:

• DPI: 400/800/1600/3200/6400
• Report rate: 1ms

Download at logitechG.com/GHUB

DPI/ONBOARD PROFILE

DPI/Onboard profiles are shown using three LEDs under the main buttons. The images to the right show which values are being indicated by the LED panel.

logitechG.com
