Instructions for Sectional Door Operator type :
STA
Instructions for Rolling Door Operator type :
CDO100 Compact
Warning : Please read these instructions fully before installation
Door Operator / STA/ LC- 2973 Rev.H
Advertisement
Table of Contents
Related Manuals for Link Controls CDO100 Compact Series
Summary of Contents for Link Controls CDO100 Compact Series
- Page 1 Link Controls Stuart Road, Manor Park, Runcorn, Cheshire, WA7 1TS T: +44 (0)1928 579050 F: +44 (0)1928 579259 www.linkcontrols.co.uk enquiries@linkcontrols.co.uk Instructions for Sectional Door Operator type : Instructions for Rolling Door Operator type : CDO100 Compact Warning : Please read these instructions fully before installation...
-
Page 2: Table Of Contents
Overview of products operating instructions are adhered to. Installation Link Controls is not liable for any personal injury or damage Initial Operation to property that occurs as a result of the warning and safety Emergency operation instructions being disregarded. -
Page 3: Overview Of Products
Overview of products Regulations and bases for testing Various options For connecting, programming and servicing, the following regulations must be observed (the list is not exhaustive). The following package options are available for the STA (CDO 100 Compact) operator: Construction product standards - EN 13241-1 (Products without fire resistance or smoke All options listed below can be supplied with either the control characteristics) -
Page 4: Installation
Installation Preparation STA Sectional Operator Mounting with torque bracket - example Danger! To avoid injury, the following points must be observed: - The operator must be installed free of any tension. - The operator must not move on the shaft. - The design and subsurface of all components must be suitable for the forces encountered. - Page 5 Assembley of the operator 1. Remove the plastic caps (if fitted from hollow shaft of the operator) Information: Link Controls Ltd. constantly strives to improve the quality of its goods and as such reserves the right to replace/modify products without prior notification. Any examples given are inteded for guidance only.
- Page 6 Installation 2. Ensure the keysteel is secured in the keyway and fit 5. Ensure the keysteel is secured in the keyway and fix the drive shaft ensuring that the shaft comes flush with the drive sprocket or gear pinion to the drive shaft hollow shaft on the non-drive side.
- Page 7 Installation CDO100 Compact Operator - Foot Mount 2. Ensure the keysteel is secured in the keyway and fit Handing the operator the drive shaft ensuring that the shaft comes flush with hollow shaft on the non-drive side. The drive shaft is This operator is suitable for left or right hand installation.
- Page 8 Installation Installation of the emergency hand chain (for operators with emergency hand chain) 4. Ensure the keysteel is secured in the keyway and fix the drive sprocket or gear pinion to the drive shaft Information: To ensure that they work correctly, the chain links must not be twisted.
-
Page 9: Initial Operation
Initial Operation Preparation Motor & Limit Switch Connections Open the operator Warning! To avoid damage to the operator, the following points must be observed: - The types of cable and their diameters must be selected according to current regulations. - The nominal currents and the type of connection must correspond to those on the motor type plate. - Page 10 Initial Operation Internal Pre-wired Connections Limit switch connections (microswitches) Motor - “U”, “V” & “W” Thermal Switch - N/C Interlock Switch - N/C Limit Switch Cables Customer Connections Motor Supply Connections “1”, “2” & “3” Limit Switch Connections: “6” - Common “7”...
- Page 11 Initial Operation MOTOR - 3 x 400V star connection (standard) 6.3 Setting Mechanical Limits The motor is factory-wired for connection to a 3 x 400V mains supply control panel. 3ph 400 V ☞ Connect all the cables required MOTOR - 3 x 230V delta connection To connect the operator to a 3 x 230V mains sup- ply, please consult the manufacturer.
- Page 12 Initial Operation 6.4 Digital Limits Wiring allocation, Electronic interface AVE (absolute value encoder) plug The numbers on the plug are also the wire numbers. Safety circuit input (N/C) AVE plug (absolute value encoder plug) RS 485 B AVE plug terminal (absolute value encoder plug terminals.
-
Page 13: Emergency Operation
Emergency Operation Check the system Danger! To avoid injury, the following points must Check the direction of travel be observed: ☞ Drive the door in the CLOSED direction. - Emergency operation may only be The operator must close the door. carried out from a safe standing position. - Page 14 Emergency Operation Operation with emergency hand chain Operation with emergency wheel guide & interlock Release the emergency hand chain from its fixing. Move the door in the OPEN or CLOSE direction by pulling on the emergency hand chain on the side concerned.
-
Page 15: Maintenance
Maintenance Operation with disengage mechanism Warning! To avoid damage to the operator and door, the following points must be observed: Warning! - Maintenance must only be carried out by To avoid injury, the following points must authorized persons. be observed:- - Directive BGR 232 must be complied with. -
Page 16: Eu Declaration Of Conformity
