Arizona Shower Door CDFMP-90 Installation Instructions Manual

Advertisement

Quick Links

# 8 x 3 / 8 "

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDFMP-90 and is the answer not in the manual?

Questions and answers

Summary of Contents for Arizona Shower Door CDFMP-90

  • Page 1 # 8 x 3 / 8 ”...
  • Page 2 Arizona Corporate Office Florida Utah Colorado Illinois Oregon 2801 W. Indian School Rd 8100-1 Westside Industrial Dr 2594 S. 3600 West Suite A 3871 Revere Street 2601 Bond St #1 2057 Lars Way Phoenix, AZ 85017 Jacksonville, FL 32219 West Valley City, UT 84119 Denver, CO 80239 University Park, IL 60484 Medford.
  • Page 3             Installation Instructions             Model CDFMP-90         Note:  These instructions will refer to the item #’s in the Exploded View drawing. For example, #1, #2, #3 etc…    Please read through all of the instructions to get an over‐view before you install the shower door.            The  curb  is  pre‐cut  using  the  centerline    measurements  that  were  given  at  the  time  of ...
  • Page 4           2)  Place  a  Wall  Jamb  ZD‐1006  (#3)  against  the    wall and down into the Curb.  Use a level to po‐   sition  the  jamb  plumb,  then  mark  the  installa‐   tion holes with a pen or pencil  . Repeat this    procedure  for  the  other  jamb.  Now  drill  the  6    holes with a 3/16” masonry bit (9/64” for fiber‐  ...
  • Page 5         (the side that is NOT holding the glass). Also, on    the inside, drill through the ZSS‐2101 Curb into    the  90  Post.  Run  the  #6X3/8”  screws  into  the      holes (#16).  . Insert the ZV909 Wedge Vinyl    (#18) into the jambs on both sides of the glass.    A  block  of  wood  will  help  push  the  vinyl  in.    Slightly wet the vinyl with water to ease install.    The  flat  side  goes  against  the  glass.  Notice  the   ...
  • Page 6         Inspect  and  fit  the  magnetic  strip  to  figure    out  the  side  that  will  attract  and  not  repel.  In‐   stall  the  side  that  repels  against  the  high  bond    tape  that  you  will  install.  Attach  the  full  length   ...
  • Page 7     the  stud  heads  of  the  screws.  Tighten  the  set  screws with Allen wrench provided  .       Adjust  ZD2008  Drip  Trough  (#12)  on  door    to slope towards the hinge     Run a bead of silicone on the gap between  the  metal  and  the  shower  surface  inside  and  out  around  the  entire  unit.  Fill  all  joints  and  gaps where metal meets metal and fill with a  ...
