A Series Barbecue Cabinet
Product and Assembly Manual
Product numbers 1542, 1543, and 1544
+61 3 9708 2999
dachristie.com
Single and Double Unit
Please read all relevant parts of
this document carefully before
commencing product assembly.
Product and Assembly Manual 6868_00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A Series and is the answer not in the manual?

Questions and answers

Related Manuals for Christie A Series

Summary of Contents for Christie A Series

  • Page 1 A Series Barbecue Cabinet Single and Double Unit Product and Assembly Manual Product numbers 1542, 1543, and 1544 Please read all relevant parts of this document carefully before commencing product assembly. +61 3 9708 2999 dachristie.com Product and Assembly Manual 6868_00...

  • Page 2: Table Of Contents

    Boxed contents and parts identification | Figure 17 Assembly and installation | Figure 18, 19, 20, 21, 22, 23, 24, 25, 26, 27.1, 27.2, 28, 29 WARRANTY A Series Barbecue Cabinet - Single and Double Unit (Product numbers 1542, 1543 and 1544)

  • Page 3: General Information

    General information | Product and Assembly Manual 6868_00...

  • Page 4: Safety Instructions

    “Should’ and “should not” are advisory instructions The following icon is used throughout the manual Warning or Caution icons warn how to prevent personal injury and product damage A Series Barbecue Cabinet - Single and Double Unit (Product numbers 1542, 1543 and 1544)

  • Page 5: Manufacturer Liability

    • The A Series Cabinet is intended for users of all abilities use with a Christie cooktop only • Cabinets are shipped flat-packed to • Christie accepts no responsibility for...

  • Page 6: Disposal

    • To dispose of the Product, remove and deliver the metals to an appropriate recycling facility • Christie products are packaged in non-polluting, recyclable materials. Deliver all packing materials to the appropriate recycling facility A Series Barbecue Cabinet - Single and Double Unit (Product numbers 1542, 1543 and 1544)

  • Page 7: Cleaning And Maintenance

    Cleaning and maintenance | Product and Assembly Manual 6868_00...

  • Page 8: Safety Considerations

    • Follow Material Safety data Sheet (MSDS) and Safe Work Guidelines 2.2 Environmental considerations Your local or national Environmental Protection authority should be contacted for advice on how to safely dispose of fats and oils. A Series Barbecue Cabinet - Single and Double Unit (Product numbers 1542, 1543 and 1544)

  • Page 9: Cleaning The Cabinet And General Maintenance

    Use only non-toxic products with a neutral pH between 6 and 9 To preserve the appearance and integrity of your Christie barbecue cabinet, we recommend the entire structure be cleaned weekly and all components be inspected and serviced at least every 12 months.

  • Page 10: Cleaning The Waste Container | Figure

    A high-pressure cleaner or steam cleaner may also be used. Extra waste containers can be ordered from Christie, to exchange and clean containers thoroughly off site A Series Barbecue Cabinet - Single and Double Unit (Product numbers 1542, 1543 and 1544)
  • Page 11 Christie Barbecue Hood has been fitted to the cooktop. Each bagged waste container is supplied with a starter pack of 25 bags. Replacement bags can be purchased from Christie in lots of 100.

  • Page 12: Installation

    12 | Installation A Series Barbecue Cabinet - Single and Double Unit (Product numbers 1542, 1543 and 1544)

  • Page 13: Siting Guidelines

    Once out of the ground, these services should be routed so as to avoid the drip tray. The GPO should be positioned at least 600 mm above ground. • Christie CC2 Barbecue Cooktop Gas appliances: Gas inlet to the appliance is on the right-hand side •...

  • Page 14: Tools Required

    • Rachet tool, extension piece and sockets to suit M8 and M6 bolts • Spanner to suit M6 nut • Masonry anchors, plus spanner and screwdriver to suit • Hammer drill with bit to suit masonry anchors A Series Barbecue Cabinet - Single and Double Unit (Product numbers 1542, 1543 and 1544)

  • Page 15: Series Single Cabinet Assemby And Installation

    Installation | A SERIES SINGLE CABINET assembly and installation (For A Series Double Cabinet installation, see Section 5) Product and Assembly Manual 6868_00...

  • Page 16: Specifications | Figure

    Weight: Nominal weight 136kg (without cooktop) Cooktop cut-out: 495 mm x 495 mm FIG. 2 (FINISHED DIMENIONS, SINGLE CABINET) 860 mm 1150 mm 1200 mm A Series Barbecue Cabinet - Single and Double Unit (Product numbers 1542, 1543 and 1544)

  • Page 17: Boxed Contents And Parts Identification | Figure

    Single cabinet assembly and installation | 4.2 Boxed contents and parts identification FIG. 3 (BOXED CONTENT, SINGLE CABINET) Top Section M8 x M8 W M6 x Fat Guide Tray M6 N Fat Tray Support Fat Tray Door Frame 2x Support Plate 2x Short Edge Strip Door LockIncluding Latch &...

  • Page 18: Assembly And Installation | Figure 4, 5, 6, 7, 8, 9, 10, 11, 12, 13.1, 13.2, 14, 15

    Lay both left (LHS) and right (RHS) Base Mounts on the concrete slab in the desired position, taking into consideration the location of the electrical or gas services. FIG. 4 Base Mount RHS Front of bench Base Mount LHS A Series Barbecue Cabinet - Single and Double Unit (Product numbers 1542, 1543 and 1544)
  • Page 19 Single cabinet assembly and installation | 4.3 Assembly and installation STEP 2 • Remove any protective plastic film from Foot Panel • Place Foot Panel into position and secure onto Base Mounts in 2 (two) places with M8 bolts and washers as shown in Figure 5 FIG.
  • Page 20 Fix both Base Mounts into position with suitable masonry anchors (not included) as shown in Figure 6 FIG. 6 Note: Check diagonal distances are equal to ensure squareness A Series Barbecue Cabinet - Single and Double Unit (Product numbers 1542, 1543 and 1544)
  • Page 21 Single cabinet assembly and installation | 4.3 Assembly and installation STEP 4 • Remove any protective plastic film from both LHS and RHS Side Panels (leave coating on other surfaces until later) • Slide both Side Panels onto Base Mounts and over the 4 Locating Lugs •...
  • Page 22 Secure Knee Panel to the Foot Panel in a further 2 places as shown in Figure 8 FIG. 8 Support Plate Knee Panel Foot Panel A Series Barbecue Cabinet - Single and Double Unit (Product numbers 1542, 1543 and 1544)
  • Page 23 Single cabinet assembly and installation | 4.3 Assembly and installation STEP 6 • Remove Access Door and Lower Door Panel from the Door Frame Assembly and set aside. This will make it easier to access the inside for further assembly •...
  • Page 24 Place the Edge Strip into position in 4 places as shown in Figure 10 Note: There are 2 different lengths of edge strip. FIG. 10 2x Long Edge Strip 2x Short Edge Strip A Series Barbecue Cabinet - Single and Double Unit (Product numbers 1542, 1543 and 1544)
  • Page 25 Single cabinet assembly and installation | 4.3 Assembly and installation STEP 8 • Remove any protective plastic film from the Top Section inside surfaces. Leave any film on the outer surfaces until completely assembled to prevent unnecessary scratching • Carefully lower the Top Section down onto the Side Panels, ensuring that the Locating Pins are engaged in 4 places •...
  • Page 26 Note the correct orientation of the vents and secure into position in 4 places as shown in Figure 12 FIG. 12 Lower Door Panel Vents to the bottom A Series Barbecue Cabinet - Single and Double Unit (Product numbers 1542, 1543 and 1544)
  • Page 27 Single cabinet assembly and installation | 4.3 Assembly and installation STEP 10 • Remove any protective plastic film from Access Door • Assemble the door lock as shown in Figure 13.1 • Position Access Door into the Door Frame, ensuring the hinge pin at the top is properly located and the 5 mm Spacer in correctly positioned between the door and the door frame FIG.
  • Page 28 | Single cabinet assembly and installation 4.3 Assembly and installation STEP 10 (continued) • Secure into position at the bottom as shown in Figure 13.2 FIG. 13.2 A Series Barbecue Cabinet - Single and Double Unit (Product numbers 1542, 1543 and 1544)
  • Page 29 Single cabinet assembly and installation | 4.3 Assembly and installation STEP 11 • Position the Drip Tray Support as shown and fix in 2 places • Fasten the Drip Tray Guide in 2 places as shown in Figure 14 FIG. 14 Waste Guide Tray Waste Tray Support Product and Assembly Manual 6868_00...
  • Page 30 Waste Tray Assembly of your A Series Barbecue Cabinet is now complete. Please consult the relevant installation instructions for any additional items, including barbecue cooktops. A Series Barbecue Cabinet - Single and Double Unit (Product numbers 1542, 1543 and 1544)

  • Page 31: Series Double Cabinet Assemby And Installation

    A SERIES DOUBLE CABINET assembly and installation (For A Series Single Cabinet installation, see Section 4) Product and Assembly Manual 6868_00...

  • Page 32: Specifications | Figure 16

    Weight: Nominal weight 188kg (without cooktop) Cooktop cut-out: 495 mm x 495 mm FIG. 16 (FINISHED DIMENIONS, DOUBLE CABINET) 860 mm 1150 mm 1900 mm A Series Barbecue Cabinet - Single and Double Unit (Product numbers 1542, 1543 and 1544)

  • Page 33: Boxed Contents And Parts Identification | Figure 17

    Double cabinet assembly and installation | 5.2 Boxed contents and parts identification FIG. 17 (BOXED CONTENT, DOUBLE CABINET) Top Section 2 x Fat Guide Tray 2 x Fat Tray 2 x Fat Tray Support 2x Support Plate Door Frame M8 x 25mm Bolt x54 Door LockIncluding Latch 2x Short Edge Strip Top Section...

  • Page 34: Assembly And Installation | Figure 18, 19, 20, 21, 22, 23, 24, 25, 26, 27.1, 27.2, 28, 29

    FIG. 18 Base Mount RHS Base Mount LHS Front of bench Back of bench A Series Barbecue Cabinet - Single and Double Unit (Product numbers 1542, 1543 and 1544)
  • Page 35 Double cabinet assembly and installation | 5.3 Assembly and installation STEP 2 • Remove any protective plastic film from Foot Panel • Place Foot Panel into position and secure onto Base Mounts in 2 (two) places with M8 bolts and washers as shown in Figure 19 FIG.
  • Page 36 Fix both Base Mounts into position with suitable masonry anchors (not included) as shown in Figure 20 FIG. 20 Note: Check diagonal distances are equal to ensure squareness A Series Barbecue Cabinet - Single and Double Unit (Product numbers 1542, 1543 and 1544)
  • Page 37 Double cabinet assembly and installation | 5.3 Assembly and installation STEP 4 • Remove any protective plastic film from both LHS and RHS Side Panels (leave coating on other surfaces until later) • Slide both Side Panels onto Base Mounts and over the 4 Locating Lugs •...
  • Page 38 Secure Knee Panel to the Foot Panel in a further 2 places as shown in Figure 22 FIG. 22 Support Plate Knee Panel Foot Panel A Series Barbecue Cabinet - Single and Double Unit (Product numbers 1542, 1543 and 1544)
  • Page 39 Double cabinet assembly and installation | 5.3 Assembly and installation STEP 6 • Remove Access Door and Lower Door Panel from the Door Frame Assembly and set aside (this will make it easier to access the inside for further assembly) •...
  • Page 40 Place the Edge Strip into position in 4 places as shown in Figure 24 Note: There are 2 different lengths of edge strip. FIG. 24 2x Long Edge Strip 2x Short Edge Strip A Series Barbecue Cabinet - Single and Double Unit (Product numbers 1542, 1543 and 1544)
  • Page 41 Double cabinet assembly and installation | 5.3 Assembly and installation STEP 8 • Remove any protective plastic film from the Top Section inside surfaces. Leave any film on the outer surfaces until completely assembled to prevent unnecessary scratching • Carefully lower the Top Section down onto the Side Panels, ensuring that the Locating Pins are engaged in 4 places •...
  • Page 42 Note the correct orientation of the vents and secure into position in 4 places as shown in Figure 26 FIG. 26 Lower Door Panel Vents to the bottom A Series Barbecue Cabinet - Single and Double Unit (Product numbers 1542, 1543 and 1544)
  • Page 43 Double cabinet assembly and installation | 5.3 Assembly and installation STEP 10 • Remove any protective plastic film from Access Door • Assemble the door lock as shown in Figure 27.1 • Position Access Door into the Door Frame, ensuring the hinge pin at the top is properly located and the 5 mm Spacer in correctly positioned between the door and the door frame FIG.
  • Page 44 | Double cabinet assembly and installation 5.3 Assembly and installation STEP 10 (continued) • Secure into position at the bottom as shown in Figure 27.2 FIG. 27.2 A Series Barbecue Cabinet - Single and Double Unit (Product numbers 1542, 1543 and 1544)
  • Page 45 Double cabinet assembly and installation | 5.3 Assembly and installation STEP 11 • Position the Drip Tray Support as shown and fix in 2 places • Fasten the Drip Tray Guide in 2 places as shown in Figure 28 FIG. 28 Waste Guide Tray Waste Tray Support Product and Assembly Manual 6868_00...
  • Page 46 Waste Tray Assembly of your A Series Barbecue Cabinet is now complete. Please consult the relevant installation instructions for any additional items, including barbecue cooktops. A Series Barbecue Cabinet - Single and Double Unit (Product numbers 1542, 1543 and 1544)

  • Page 47: Warranty

    Warranty | WARRANTY Product and Assembly Manual 6868_00...

  • Page 48: A Series Barbecue Cabinet - Single And Double Unit (Product Numbers 1542, 1543 And

    Company to do so including, but not restricted to, products tampered with, altered, modified, repaired, not cleaned, or not installed in accordance with the Company’s instructions. A Series Barbecue Cabinet - Single and Double Unit (Product numbers 1542, 1543 and 1544)
  • Page 49 Warranty | This warranty is in addition to and not in substitution for any warranty given by Law. WARRANTY CLAIM PROCEDURE Warranty service may be obtained by contacting the Company Any claim for warranty must be accompanied by appropriate documentation that provides proof of purchase, details of the alleged defect and serial number The freight to the Company will be at the purchaser’s expense but return freight will be at the Company’s expense...
  • Page 50 +61 3 9708 2999 dachristie.com Installation Manual 6838_03...
