- Page 1 USER MANUAL VIA Mobile360 M820 Fanless ultra-compact in-vehicle 360° surround view surveillance & ADAS system 1.00-08282019-181700...
- Page 2 VIA Technologies, Inc. reserves the right the make changes to the products described in this manual at any time without prior notice.
- Page 3 Battery Recycling and Disposal • Only use the appropriate battery specified for this product. • Do not re-use, recharge, or reheat an old battery. • Do not attempt to force open the battery. • Do not discard used batteries with regular trash. •...
- Page 4 VIA Moblie360 M820 User Manual Box Contents • 1 x VIA Moblie360 M820 system • 1 x Phoenix plug to DC jack • 1 x COM cable (for debugging) • 1 x GPS antenna • 2 x Wi-Fi/BT antennas • 1 x Mounting bracket •...
-
Page 5: Table Of Contents
VIA Mobile360 M820 User Manual Table of Contents 1. Product Overview ......................1 Key Features ............................1 1.1.1 High-Performance .......................... 1 1.1.2 Fanless, Compact, Ruggedized Chassis ..................1 1.1.3 Optimized Integration with Multiple I/O Access ................1 1.1.4 Multiple Camera Support ......................1 1.1.5 Support for a Wide Range of Power Sources ................1 1.1.6... - Page 6 VIA Mobile360 M820 User Manual Appendix D. I nstalling FOV Automotive-grade Cameras to the Camera Brackets ....30 D.1. Installing the FOV-190 Automotive-grade Camera to the SVS Camera Bracket ........30 D.2. Installing the FOV-40 Automotive-grade Camera to the BSD Camera Bracket ........32 D.3. Installing the FOV-40 Automotive-grade Camera to the FCW Camera Bracket ........34...
- Page 7 VIA Mobile360 M820 User Manual List of Figures Figure 1: Front panel I/O layout .......................... 5 Figure 2: Back panel I/O layout ........................... 5 Figure 3: Dimensions of the VIA Mobile360 M820 (front view) ................. 6 Figure 4: Dimensions of the VIA Mobile360 M820 (side view) ................6 Figure 5: Dimensions of the VIA Mobile360 M820 (bottom view)..............6 Figure 6: HDMI port diagram ..........................7 Figure 7: USB 3.0 port diagram .......................... 7 Figure 8: Micro USB 2.0 port diagram ......................... 8 Figure 9: Gigabit Ethernet port diagram ......................8 Figure 10: Micro SD card slot diagram ........................
- Page 8 VIA Mobile360 M820 User Manual Figure 56: Attaching the double-sided adhesive tape to the rotate-base plate (FCW camera bracket) ..... 35 Figure 57: Removing the double-sided adhesive tape protective cover (FCW camera bracket) ......36 viii...
- Page 9 VIA Mobile360 M820 User Manual List of Tables Table 1: HDMI port pinouts ..........................7 Table 2: USB 3.0 pinouts ........................... 7 Table 3: Micro USB 2.0 port pinouts ........................8 Table 4: Gigabit Ethernet port pinouts ......................8 Table 5: Gigabit Ethernet port LED color definition ................... 8 Table 6: Micro SD card slot pinouts ........................9 Table 7: SIM card slot pinouts ........................... 9 Table 8: DIO port pinouts ..........................10 Table 9: Headphone and Mic-in port pinouts ....................
-
Page 10: Product Overview
VIA Mobile360 M820 User Manual 1. Product Overview The VIA Mobile360 M820 is a fanless ultra-compact in-vehicle 360° surround view surveillance and ADAS system. It delivers real-time in-vehicle 360° video monitoring and recording for up to nine automotive-grade camera streams, and boost vehicle safety and efficiency with ADAS technology. With its ruggedized design that has been optimized for the most demanding on-road and off-road conditions, the VIA Mobile360 M820 provides a flexible and high-performance solution for a wide variety of applications ranging from Freight Transportation & Delivery, Construction, Industrial, & Mining, and Agriculture & Forestry to Refuse Collection, Armored Cars & Secure Freight Shipping, and Buses and Coaches. The VIA Mobile360 M820 is powered by the Qualcomm® APQ8096SG Embedded Processor, which features two high-performance Kryo™ cores up to 2.342GHz two low-power Kryo cores up to 1.593GHz. It combines advanced computing, graphics and AI processing performance, rich connectivity options, and I/O peripheral integration capabilities in an ultra-compact fanless system. Measuring just 240mm (W) x 53mm (H) x 180mm (D), the system integrates a rich set of I/O features through the front and back panels of its ultra-compact chassis, including an HDMI port, two USB 3.0 ports, Gigabit Ethernet, CAN Bus, nine FAKRA connectors for camera-in, and a Micro SD card slot. Other features include 4GB POP LPDDR4 SDRAM, 16GB eMMC flash memory, a SIM card slot, DIO, COM, and a headphone & mic-in port. The VIA Mobile360 M820 supports high computing power operation with low power consumption, and it has a built-in power management system that protects from power surges – guarding against damage from transient car power. With the power management system, it is capable of handling a wide range of DC power inputs from 9V~36V. -
Page 11: Storage Expansion
VIA Mobile360 M820 User Manual 1.1.6 Storage Expansion The VIA Mobile360 M820 has 16GB eMMC flash storage onboard and features Micro SD card slot support and additional 32GB, and two HDD/SSD bays for 2.5" SATA HDD/SSD. 1.1.7 Networking Support The VIA Mobile360 M820 is equipped with Wi-Fi, GPS and an RJ-45 port that supports high-speed data Gigabit Ethernet. The 4G connectivity can be added through the miniPCIe slot using the optional mobile broadband miniPCIe module. 1.1.8 Mounting Solution The VIA Mobile360 M820 supports multiple methods for mounting the chassis securely. The rugged Mobile360 M820 can be mounted on a side-panel of a car, floor bed, or any flat surface. 1.1.9 Embedded Operating System Ready The VIA Mobile360 M820 features a complete software evaluation image featuring Android 8.0. -
Page 12: Product Specifications
VIA Mobile360 M820 User Manual Product Specifications Processor • Qualcomm APQ8096SG Embedded Processor ® ™ ◦ Two high-performance Kryo cores up to 2.342GHz ◦ Two low power Kryo cores up to 1.593GHz System Memory • 4GB POP LPDDR4 SDRAM Storage • 16GB eMMC flash memory • 2 x M.2 SATA slots • 2 x 2.5 SATA HDD/SSD storage bays Graphics • Qualcomm Adreno 530 GPU ®... - Page 13 VIA Mobile360 M820 User Manual Back Panel I/O • 1 x HDMI port • 1 x DIO port • 1 x COM port • 1 x CAN Bus port • 1 x Gigabit Ethernet port • 9 x FAKRA connectors for camera-in • 1 x Headphone and Mic-in port • 4 x Antenna connectors for Wi-Fi, 4G and GPS • 1 x 4-pole Phoenix 9V~36V DC-in • 1 x 2-pole Phoenix 12V DC-out Power Supply • 9V~36V DC-in with ACC/IGN Operating System • Android 8.0 VIA Smart ETK • RTC Wake-up, Suspend, Watchdog timer, CAN bus, GPIO Operating Temperature •...
-
Page 14: Layout Diagram
VIA Mobile360 M820 User Manual Layout Diagram Figure 1: Front panel I/O layout Figure 2: Back panel I/O layout... -
Page 15: Product Dimensions
VIA Mobile360 M820 User Manual Product Dimensions Figure 3: Dimensions of the VIA Mobile360 M820 (front view) Figure 4: Dimensions of the VIA Mobile360 M820 (side view) Figure 5: Dimensions of the VIA Mobile360 M820 (bottom view) -
Page 16: External I/O Pin Descriptions And Functionality
VIA Mobile360 M820 User Manual 2. External I/O Pin Descriptions and Functionality The VIA Mobile360 M820 has a wide selection of interfaces. It includes a selection of frequently-used ports as part of the external I/O coastline. HDMI Port ® The VIA Mobile360 M820 is equipped with one HDMI port on the back panel which uses an HDMI port Type A receptacle connector to connect High Definition video and digital audio using a single cable. The pinouts of the HDMI port are shown below. Signal Signal CLK- Figure 6: HDMI port diagram DDC_CLK DDC_DATA HDMI_5V PLUG_DET CLK+ Table 1: HDMI port pinouts USB 3.0 Ports The VIA Mobile360 M820 is equipped with two USB 3.0 ports in the front panel. Each USB 3.0 port has a maximum data transfer rate of up to 5Gbps and is compatible with USB 2.0 specifications. The USB ports give complete Plug and Play and hot swap capability for external devices. The pinouts of the USB 3.0 ports are shown below. -
Page 17: Micro Usb 2.0 Port
VIA Mobile360 M820 User Manual Micro USB 2.0 Port The VIA Mobile360 M820 is equipped with one Micro USB 2.0 port located on the front panel. The Micro USB 2.0 port supports OTG (On-The-Go) for debugging. The pinouts of the Micro USB 2.0 port are shown below. Signal VBUS Figure 8: Micro USB 2.0 port diagram Table 3: Micro USB 2.0 port pinouts Gigabit Ethernet Port The VIA Mobile360 M820 comes with one Gigabit Ethernet port on the back panel which uses an 8 Position and 8 Contact (8P8C) receptacle connector commonly known as RJ-45. It is fully compliant with the IEEE 802.3 (10BASE-T), 802.3u (100BASE-TX), and 802.3ab (1000BASE-T) standards. The pinouts of the Gigabit Ethernet port are shown below. Signal TX1+ TX1- TX2+ TX2- TX3+ TX3- TX4+ Figure 9: Gigabit Ethernet port diagram TX4- Table 4: Gigabit Ethernet port pinouts The Gigabit Ethernet port (RJ-45) is equipped with two LED indicators on the front side to show its Active/Link status and Speed status. -
Page 18: Micro Sd Card Slot
VIA Mobile360 M820 User Manual Micro SD Card Slot The VIA Mobile360 M820 comes with a Micro SD card slot located on the front panel with support for a maximum storage capacity of 32GB. The pinouts of the Micro SD card slot are shown below. Signal SD_DAT2 SD_DAT3 SD_CMD SD_CLK Figure 10: Micro SD card slot diagram SD_DAT0 SD_DAT1 SD_CD- Table 6: Micro SD card slot pinouts SIM Card Slot The VIA Mobile360 M820 comes with a SIM card slot located on the front panel that can support a 4G SIM card. Using the SIM card slot on the VIA Mobile360 M820 requires a 4G module to be installed in the miniPCIe slot to enable the 4G function, otherwise the SIM card slot is disabled. The SIM card slot is designed only for a 4G module without a built-in SIM card slot on it. The pinouts of the SIM card slot are show below. Signal VSIM_VCC VSIM_RST VSIM_VCC Figure 11: SIM card slot diagram VSIM_CLK VSIM_DATA Table 7: SIM card slot pinouts... -
Page 19: Dio Port
VIA Mobile360 M820 User Manual DIO Port The VIA Mobile360 M820 is equipped with a DIO port located on the back panel. The DIO port offers a Digital I/O communication interface to support 8-bit GPIO. The pinouts of the DIO port are show below. Signal GPO0 GPO1 GPO2 GPO3 GPI0 GPI1 GPI2 Figure 12: DIO port diagram DIO_GND Table 8: DIO port pinouts Headphone and Mic-in Port The VIA Mobile360 M820 is equipped with a Headphone and Mic-in port located on the back panel. The Headphone and Mic-in port is for connecting external speakers such as a headphone or a microphone. The pinouts of the Headphone and Mic-in port are shown below. Signal MIC1 Jack_det HPH_GND_SENSE_CONN CDC_HPH_R_CONN CDC_HPH_L_CONN Table 9: Headphone and Mic-in port pinouts Figure 13: Headphone and Mic-in port diagram COM Port The VIA Mobile360 M820 is equipped with a COM port located on the back panel which supports TX/RX for debugging. The pinouts of the COM port are shown below. -
Page 20: Can Bus Port
VIA Mobile360 M820 User Manual 2.10 CAN Bus Port The VIA Mobile360 M820 is equipped with a CAN bus port located on the back panel. The CAN bus port supports one CAN bus and one debug COM (TX/RX) for debugging. The CAN bus supports protocol specification Version 2.0 B. The pinouts of the CAN bus port are show below. Signal RS232_TXD CANL Figure 15: CAN bus port diagram CANH RS232_RXD VDD12V_OUT/1A Table 11: CAN bus port pinouts 2.11 FAKRA Connectors The VIA Mobile360 M820 is equipped with nine FAKRA connectors located on the back panel. The FAKRA connectors are for FOV-40 and FOV-190 automotive-grade cameras. The pinouts of the FAKRA connectors are shown below. Signal RIN_P Table 12: FAKRA connector pinouts Figure 16: FAKRA connector diagram... -
Page 21: Power Button
VIA Mobile360 M820 User Manual 2.12 Power Button The VIA Mobile360 M820 comes with a power button. The power button can support two functions: System Suspend/Resume and Power on/off. The diagram of the power button is shown below. Figure 17: Power button diagram Power Button behavior Suspend/Resume System Quickly press the power button once to suspend. While in suspend mode quickly press once to resume. Power On/Off Occurs when the power button is pressed for longer than 3 seconds. Table 13: Power button behavior description 2.13 DC-in Jack The VIA Mobile360 M820 comes with a 4-pole Phoenix DC-in jack that carries a 9V~36V DC external power input. The pinouts of the 4-pole Phoenix DC-in jack are shown below. Signal DC-IN DC-IN Figure 18: DC-in jack diagram Table 14: DC-in jack pinouts 2.14 DC-out Jack... -
Page 22: Antenna Connectors
VIA Mobile360 M820 User Manual 2.15 Antenna Connectors The VIA Mobile360 M820 is equipped with four antenna connectors located on the back panel. Two antenna connectors are for Wi-Fi antennas while the other two antenna connectors are for 4G and GPS antennas. The Wi-Fi, 4G and GPS antenna connectors diagrams are shown below. Figure 20: Wi-Fi antenna connectors diagram Figure 21: 4G and GPS antenna connectors diagram... -
Page 23: Onboard I/O
VIA Mobile360 M820 User Manual 3. Onboard I/O This chapter provides information about the onboard I/O connector on the VIA Mobile360 M820. MiniPCIe Slot The VIA Mobile360 M820 is equipped with a miniPCIe slot for wireless networking options such as a 4G module. Then pinouts of the miniPCIe slot are shown below. Figure 22: MiniPCIe slot diagram Signal Signal Signal Signal Reserved VDD3V3_MPCIE VDD1V5 Reserved Reserved Reserved VDD1V5 Reserved Reserved Reserved USIM_VCC Reserved USIM_DATA MINI_PCIE_USB_DM Reserved USIM_CLK MINI_PCIE_USB_DM Reserved USIM_RST VDD3V3_MPCIE USIM_VPP... -
Page 24: Hardware Installation
VIA Mobile360 M820 User Manual 4. Hardware Installation This chapter provides information about the hardware installation procedures. It is recommended to use a grounded wrist strap before handling computer components. Electrostatic discharge (ESD) can damage some components. Installing the 2.5" SATA HDD/SSD Step 1 Insert the key and turn it in a counter clockwise direction to unlock the SATA HDD/SSD bay. Then unscrew the two thumbscrews. Figure 23: Unlocking the SATA HDD/SSD bay Step 2 Gently pull out the SATA HDD/SSD bays to disengage it from the chassis completely. Figure 24: Removing the SATA HDD/SSD bays... -
Page 25: Figure 25: Installing The 2.5" Sata Hdd/Ssd
VIA Mobile360 M820 User Manual Step 3 Slide in the 2.5" SATA HDD/SSD into the SATA HDD/SSD bay. Then secure it with four screws. Figure 25: Installing the 2.5" SATA HDD/SSD Step 4 Reinstall the SATA HDD/SSD bays. Figure 26: Reinstalling the SATA HDD/SSD bays... -
Page 26: Installing The Wi-Fi Antennas
VIA Mobile360 M820 User Manual Installing the Wi-Fi Antennas Step 1 Locate the two Wi-Fi antenna connectors on the back panel of the VIA Mobile360 M820. Step 2 Install the provided two Wi-Fi antennas to the antenna connectors. Figure 27: Installing the Wi-Fi antennas Installing the GPS Antenna Step 1 Locate the GPS antenna connector on the back panel of the VIA Mobile360 M820. Step 2 Install the provided GPS antenna to the antenna connector. Figure 28: Installing the GPS antenna... -
Page 27: Installing The Fov Cameras And Fakra Cables
VIA Mobile360 M820 User Manual Installing the FOV Cameras and FAKRA Cables Step 1 Align the FOV camera connector on the FAKRA cable's connector. Then insert the camera connector until the locking clips lock the connector into place. Figure 29: Connecting the FOV camera to the FAKRA cable Step 2 Connect the FAKRA cable to the FAKRA connector for camera-in on the Mobile360 M820. Figure 30: Connecting the FAKRA cable to the FAKRA connector... -
Page 28: Unplugging The Fakra Cable
VIA Mobile360 M820 User Manual Unplugging the FAKRA Cable Step 1 Firmly press and hold the locking clip on the FAKRA cable's connector. Step 2 Then pull the FAKRA cable's connector to unplug it. Figure 31: Uplugging the FAKRA cable... -
Page 29: Connecting Via Mobile360 M820 To The Vehicle's Ignition (Ign)
VIA Mobile360 M820 User Manual Connecting VIA Mobile360 M820 to the Vehicle's Ignition (IGN) Step 1 Locate the pin no. 8 on the GPIO port located on the back panel I/O. Figure 32: GPIO port's pin 8 Step 2 Connect a wire on the pin no. 8 on GPIO port. Then connect the other end of the wire into the Ignition (IGN) signal on the vehicle. For details where to find the IGN on your vehicle, please refer to your car dealers. Figure 33: VIA Mobile360 M820 and IGN connection method diagram... -
Page 30: Installing The Phoenix Plug To Dc Jack
VIA Mobile360 M820 User Manual Installing the Phoenix Plug to DC Jack Step 1 Install four wires to the Phoenix plug to DC jack from the vehicle's battery. To install the wire, loosen first the respective screws on the Phoenix plug to DC jack before inserting each wire. Figure 34: Connecting the battery cables onto the Phoenix plug to DC jack Step 2 Connect the Phoenix plug to DC jack into the DC-in jack on the VIA Mobile360 M820, and then secure it with its two screws. Figure 35: Connecting the Phoenix plug to DC jack... -
Page 31: Software And Technical Support
VIA Mobile360 M820 User Manual 5. Software and Technical Support Android Support The VIA Mobile360 M820 features a complete software evaluation image featuring the Android 8.0 operating system. Technical Support and Assistance • For technical support and additional assistance, always contact your local sales representative or https://www.viatech.com/en/support/driver-support-fag/technical-support/ board distributor, or go to technical support. • For OEM clients and system integrators developing a product for long term production, other code and resources may also be made available. Please visit our website at https://www.viatech.com/en/... -
Page 32: Appendix A. Installing Wireless Accessories
VIA Mobile360 M820 User Manual Appendix A. Installing Wireless Accessories This chapter provides information on how to install the mobile broadband miniPCIe module in the VIA Mobile360 M820. A.1. Installing the Mobile Broadband MiniPCIe Module Step 1 First, remove the two SATA HDD bays. Refer to steps 1 and 2 of section 4.1 for complete instructions. Step 2 Remove the two screws on the front and back panel. Then remove the nineteen screws on the bottom plate cover as shown in the figure below. Figure 36: Unscrewing the bottom plate cover... -
Page 33: Figure 37: Removing The Bottom Plate Cover
VIA Mobile360 M820 User Manual Step 3 Remove the bottom plate cover. Figure 37: Removing the bottom plate cover Step 4 Align the notch on the mobile broadband module (4G module) with the counterpart on the miniPCIe slot, then insert the module at a 30° angle. Push down the module until the screw holes align with the mounting hole on the standoff and then secure the module with a two screws. Figure 38: Installing the mobile broadband module... -
Page 34: Figure 39: Connecting The 4G Antenna Cable To The Micro-Rf Connector On The Module
VIA Mobile360 M820 User Manual Step 5 Gently connect the 4G antenna cable to the micro-RF connector labeled "MAIN" on the mobile broadband module. Then, reinstall the bottom plate cover. Figure 39: Connecting the 4G antenna cable to the micro-RF connector on the module Step 6 Install the 4G antenna on the 4G antenna connector. Figure 40: Installing the 4G antenna... -
Page 35: Appendix B. Installing Mounting Bracket
VIA Mobile360 M820 User Manual Appendix B. Installing Mounting Bracket This chapter provides information on how to install the mounting bracket for mounting the VIA Mobile360 M820. B.1. Installing the Mounting Bracket Step 1 Align each rubber dapmers on the mounting holes on the bottom plate of the chassis as shown in the figure below. Figure 41: Installing the rubber dampers... -
Page 36: Figure 42: Installing The Mounting Bracket
VIA Mobile360 M820 User Manual Step 2 Align the mounting holes of the mounting bracket onto the rubber damper's holes. Figure 42: Installing the mounting bracket... -
Page 37: Figure 43: Securing The Mounting Bracket
VIA Mobile360 M820 User Manual Step 3 Install the washers into the mounting screws, and then secure the mounting bracket and the rubber dampers. Figure 43: Securing the mounting bracket Caution: Do not use any other types of screws for the mounting bracket because they might cause damage to the internal of the VIA Mobile360 M820. Please use the screws which are provided in the package. -
Page 38: Appendix C. Installing Via Mobile360 M820
VIA Mobile360 M820 User Manual Appendix C. Installing VIA Mobile360 M820 Using the mounting bracket, the VIA Mobile360 M820 can be installed on the side panel of a car, floor bed, or any flat surface suitable for mounting. C.1. Mounting the VIA Mobile360 M820 Step 1 Find a suitable surface to mount the VIA Mobile360 M820. Drill four holes and make sure the distance between the holes are perfectly matched with the mounting bracket's holes. Step 2 Install the VIA Mobile360 M820 and secure it with four M4 screws. Figure 44: Mounting the VIA Mobile360 M820... -
Page 39: Appendix D. Installing Fov Automotive-Grade Cameras To The Camera Brackets
VIA Mobile360 M820 User Manual Appendix D. Installing FOV Automotive-grade Cameras to the Camera Brackets This chapter provides information on how to install the FOV-190 automotive-grade camera for the SVS camera bracket, and FOV-40 automotive-grade camera for the BSD and FCW camera brackets. D.1. Installing the FOV-190 Automotive-grade Camera to the SVS Camera Bracket Step 1 Attach the FOV-190 camera to the internal bracket, and then secure it with the two screws (M3x8) provided. Figure 45: Installing the FOV-190 automotive-grade camera on the internal bracket (SVS camera bracket) Step 2 Attach the internal bracket to the external bracket, and then secure it with the two screws (M3x5) provided. Figure 46: Attaching the internal bracket to the external bracket (SVS camera bracket) -
Page 40: Figure 47: Installing The Double-Sided Adhesive Tape On The External Bracket (Svs Camera Bracket)
VIA Mobile360 M820 User Manual Step 3 Attach the double-sided adhesive tape to the external bracket. Figure 47: Installing the double-sided adhesive tape on the external bracket (SVS camera bracket) Step 4 Remove the protective cover of the double-sided adhesive tape before installing the SVS camera bracket to the dashboard of your vehicle. Figure 48: Removing the double-sided adhesive tape protective cover (SVS camera bracket) -
Page 41: Installing The Fov-40 Automotive-Grade Camera To The Bsd Camera Bracket
VIA Mobile360 M820 User Manual D.2. Installing the FOV-40 Automotive-grade Camera to the BSD Camera Bracket Step 1 Attach the FOV-40 camera to the internal bracket, and then secure it with the two screws provided (M3x8). Figure 49: Installing the FOV-40 automotive-grade camera on the internal bracket (BSD camera bracket) Step 2 Attach the internal bracket to the external bracket, and then secure it with the two screws (M3x5) provided. Figure 50: Attaching the internal bracket to the external bracket (BSD camera bracket) -
Page 42: Figure 51: Installing The Double-Sided Adhesive Tape On The External Bracket (Bsd Camera Bracket)
VIA Mobile360 M820 User Manual Step 3 Attach the double-sided adhesive tape on the external bracket. Figure 51: Installing the double-sided adhesive tape on the external bracket (BSD camera bracket) Step 4 Remove the protective cover of the double-sided adhesive tape before installing the BSD camera bracket on the side mirror of your vehicle. Figure 52: Removing the double-sided adhesive tape protective cover (BSD camera bracket) -
Page 43: Installing The Fov-40 Automotive-Grade Camera To The Fcw Camera Bracket
VIA Mobile360 M820 User Manual D.3. Installing the FOV-40 Automotive-grade Camera to the FCW Camera Bracket Step 1 Attach the FOV-40 camera to the internal bracket of the FCW camera bracket, and then secure it with the two screws (M3x8) provided. Figure 53: Installing the FOV-40 automotive-grade camera on the internal bracket (FCW camera bracket) Step 2 Attach the internal bracket to the external bracket, and then secure it with the two screws (M3x5) provided. Figure 54: Attaching the internal bracket to the external bracket (FCW camera bracket) -
Page 44: Figure 55: Attaching The Rotate-Base Plate To The External Bracket (Fcw Camera Bracket)
VIA Mobile360 M820 User Manual Step 3 Attach the rotate-base plate to the external bracket, and then secure it with the three screws (M3x8) provided. Figure 55: Attaching the rotate-base plate to the external bracket (FCW camera bracket) Step 4 Attach the double-sided adhesive tape to the rotate-base plate. Figure 56: Attaching the double-sided adhesive tape to the rotate-base plate (FCW camera bracket) - Page 45 VIA Mobile360 M820 User Manual Step 5 Remove the protective cover of the double-sided adhesive tape before installing the FCW camera bracket to the windshield of your vehicle. Figure 57: Removing the double-sided adhesive tape protective cover (FCW camera bracket)
