14.2 Set Point Limits and Defaults

14.2.1 System Adjustments
Description
System Pressure
Static Pressure
Outlet Pressure
(LP UNITS)
Alarm Delay
Startup Delay
14.2.2 Alarm Set Points
Description
High Flow Alarm
High Outlet Pressure
Alarm (LP UNITS)
Low Outlet Pressure
Alarm (LP UNITS)
High Humidity Alarm
High Compressor Last
Run Time Alarm
High Cabinet
Temperature Alarm
Compressor Total Run
Time Alarm
14.2.3 System Operations
Description
Compressor
Fan
P550W Series Air Dryers User's Guide
Minimum Maximum
Value Value
2.0 15.0
(0.30) (7.50)
OFF ON
0 10
Minimum Maximum
Value Value
0 900
0.6 20.0
(0.31) (7.50)
0.5 19.9
(0.30) (7.49)
3 15
2:00 5:00
ON Value OFF Value
20.0 50.0
90 80
Page 95 of 99
Default Unit of
Value Measurement
50 PSI
17 PSI
PSI
ON
0 Seconds
Default Unit of
Value Measurement
500 SCFD
10.0
PSI
(7.50)
2.0
PSI
(0.30)
10 %
3:00 Minutes
120 Deg F
8000 Hours
Default Unit of
Value Measurement
PSI
Deg F
P011658 – Rev. P
Shutdown
YES
YES
