Puregas P1500W Series Installation Manual

This guide covers basic air dryer installation and setup only. Once installation is complete, please
refer to the P1500W Series User's Guide for more advanced setup and confi guration options.
Safety & Warning Information
WARNING!
Internal surfaces may be hot. Use care
when coming into contact with internal
components as there is a potential for
some of these components to become
hot when in operation or standby.
WARNING!
Extreme care should be exercised to
avoid contact with live electrical circuits.
Many procedures performed during
installation of this air dryer require the
equipment to be running, creating a
situation for potential electrical shock.
It is highly recommended that you
remove all jewelry before performing
any procedures.
WARNING!
High Noise.
meant to be installed in an unattended
area and are intended for network
telecommunication
customer premises) only.
CAUTION!
This Air Dryer does not contain an
internal Surge Protection Device (SPD).
If an SPD is required it must be supplied
by the user.
IMPORTANT!
Performing procedures not described
in this User's Guide or installing
components not supplied by PUREGAS
is NOT RECOMMENDED AND MAY VOID
THE WARRANTY.
Puregas air dryers are
facilities (non-
P1500W Series Air Dryer
Installation Guide

Before You Begin

1. Carefully inspect the unit, including
the shipping box as well as the air dryer,
for ANY DAMAGE CAUSED BY SHIPPING.
If any shipping damage is detected,
it is important to fi le a claim with the
shipping company prior to continuing the
installation procedures.
2. Read the entire Installation Guide to familiarize
yourself with the components and procedures
before performing the air dryer installation.
3. Verify the installation location of the air dryer:
• Well ventilated and free from abrasive
dust or chemicals.
• Ambient temperature is between
40° F and 85° F (optimum).
NOTE: Higher temperatures will
decrease component lifespan.
• Meets the following power
requirements:
• 50 / 60 Hz with minimum 15 amp
service with a 10 amp slow blow
fuse.
• 110 - 125 VAC for P1500W,
P1500WLP & P1500WHP models.
• 208 - 230 VAC, 1 phase for
P1502W, P1502WLP & P1502WHP
models.
4. Notify the alarm center of the installation
and potential for alarms during the process (if
applicable).
P012166 - Rev. E
