Puregas P550W Series Installation Manual

Installation Steps cont. Installation Checklist
No shipping damage was detected.
20
• Check for air leaks. Dryer location meets the following
requirements:
CA CAUTION: DO NOT SOAP TEST THE
HUMIDITY SENSOR FITTING. DAMAGE
o Well ventilated
TO THE SENSOR MAY OCCUR.
o Free from abrasive dust or chemicals
With Compressor NOT RUNNING:
o Ambient temperature is between
Listen for 'hissing' sounds which may indicate a
fi tting or hose air leak.
40° F and 85° F (optimal)
With Compressor RUNNING: System Pressure is set to 50 PSI.
Use a 1-inch brush to dab soapy water on all
Static Pressure is set to 17 PSI.
air fi ttings and hose connections.
No air leaks are present in the system.
No alarms are present on the Display Panel.

Registering Your Dryer

If air bubbles appear, this is an indication that Please take a moment to register your PUREGAS
air is leaking.
P550W Series Air Dryer. Registering is necessary
Take steps to seal the leak:
to activate the Limited Warranty on your product.
• Tighten the fi tting
• Re-connect / tighten the hose end
Once you register, you are eligible to receive free
• Replace the fi tting / hose / component
technical support, as well as updates concerning
your PUREGAS products.
21
Register Online at
www.puregas.com/registration
Or by Phone
1-800-521-5351 (option 2)
• Replace and latch the front panel.
Have the following information available:
Model #:
22
• Connect alarm hookups (if applicable). •
Serial #:
P le P Please refer to the P550W Series User's
G Guide section on Operating Your Dryer.
Company Name:
Specifi cally, sub-sections:
Location Name:
Connecting to Common Alarm Terminals
Shipping Address:
Connecting to Power Fail Alarm Terminals
City:
23 Contact Name:
• REGISTER YOUR DRYER.
Phone #: (
Email:
State:
Zip Code:
) - ext.
P550W Series Air Dryer
Installation Guide
This guide covers basic air dryer installation and setup only. Once installation is complete, please
refer to the P550W Series User's Guide for more advanced setup and confi guration options.
Safety & Warning Information

Before You Begin

WARNING! 1. Carefully inspect the unit, including
the shipping box as well as the air dryer,
Internal surfaces may be hot. Use care
for ANY DAMAGE CAUSED BY SHIPPING.
when coming into contact with internal
components as there is a potential for If any shipping damage is detected,
some of these components to become it is important to fi le a claim with the
shipping company prior to continuing the
hot when in operation or standby.
installation procedures.
WARNING!
Extreme care should be exercised to 2. Read the entire Installation Guide to familiarize
avoid contact with live electrical circuits. yourself with the components and procedures
Many procedures performed during
before performing the air dryer installation.
installation of this air dryer require the
equipment to be running, creating a 3. Verify the installation location of the air
situation for potential electrical shock. dryer:
It is highly recommended that you
• Well ventilated and free from abrasive
remove all jewelry before performing
dust or chemicals.
any procedures.
• Ambient temperature is between
WARNING!
40° F and 85° F (optimal).
High Noise. Puregas air dryers are
NOTE: Higher temperatures will
meant to be installed in an unattended
decrease component lifespan.
area and are intended for network
telecommunication facilities (non-
• Meets the following power
customer premises) only.
requirements:
• 110 - 125 VAC for
CAUTION!
This Air Dryer does not contain an
• 208 - 253 VAC, 1 phase for
internal Surge Protection Device (SPD).
If an SPD is required it must be supplied
• All models require 50 / 60 Hz
by the user.
IMPORTANT!
Performing procedures not described
4. Notify the alarm center of the installation
in this User's Guide or installing
and potential for alarms during the process (if
components not supplied by PUREGAS
applicable).
is NOT RECOMMENDED AND MAY VOID
THE WARRANTY.
P550W, P550WH, and P550WLP.
P552W, P552WH, and P552WLP.
with minimum 15 amp service
with a 10 amp slow blow fuse.
P012115 - Rev. A
