9.6 Testing Consistent Heatless Dryer Cycling

WARNING!
Internal surfaces may be hot. Use care when coming into contact
with internal components as there is a potential for some of these
components to become hot when in operation or standby.
With the Compressor running:
9.6.1 Open Panel (see section 8.8 ).
9.6.2 Place a piece of insulating
material over the compressor
for this test (i.e. piece of
cardboard).
9.6.3 Locate the heatless Dryer
purge solenoids inside the air
Dryer
