8.3 Depressurizing the Dryer

CAUTION: Be careful when removing air hose. System is pressurized.
8.3.1 Disconnect air hose from
the quick disconnect
connector located on top of
Outlet Pressure Regulator.
8.3.2 To prevent pressure from building back up, power the Dryer OFF (See
section 8.4 ).
8.3.3 Reconnect air hose.
8.4 Powering the Dryer ON & OFF
CAUTION!
Incoming power to Dryer must be:
8.4.1 POWER Switch - Controls
the main power to the Dryer.
• 15 amp service recommended
• 10 amp slow blow fuse
• 110 - 125 VAC, 50/60 Hz for P550W models
• 208 - 253 VAC, 50/60 Hz,
Page 26 of 99
P550W Series Air Dryers User's Guide
for P552W models
1 Phase
P011658 – Rev. P
