3. Tightening torques and lubricants

Pos. Designation
5c O-ring
11 O-ring
25 Plug
26 Staybolt, CM 1, 3, 5, stainless steel
28g Screw
31 O-ring, CM 1, 3, 5
64f Rubber seal
67 Locking nut
102 O-ring
103 Seal faces
107 O-ring
152 Screw
155 Bearing cover plate
Gasket, MG 71, MG 80
157a Gasket, MG 90
Gasket, MG 100
158a O-ring
O-ring, MG 71, MG 80
159 O-ring, MG 90, MG 100
O-ring, MG 112, MG 132
159a Seal ring
Screw, MG 71, MG 80
Staybolt, MG 90
181 Staybolt, MG 90L
Staybolt, MG 100
Staybolt, MG 112
THREAD-EZE, product number 00SV9997 (0.5 l).
Rocol Sapphire Aqua-Sil, product number 00RM2924 (0.5 kg).
Castrol LMX grease, product number 00RM4311.
Silicone oil, 350 cSt, food grade 00SV0862 (1 l).
4
Quantity Dimensions
∅37 x 2.62
1
∅18.5 x 2.0
2
2 -
4 M8
4 M6 x 14
∅114.0 x 3.90
1
1
1 M8
∅17.86 x 2.62
1
1 -
∅11.5 x 3.18
1
2 M4 x 8
4 M5 x 12
1 -
∅114.8 / 121.2 x 0.25
1
∅141.2 / 145.5
2
- -
∅35.4 x 1.97
1
∅32 x 2
1
∅52 x 3.0
1
∅62 x 3.0
1
1 -
4 M6 x 16
4 M5 x 220
4 M5 x 260
4 M5 x 270
4 M6 x 288
Torque [Nm] Lubricant
Sapphire Aqua-Sil
- -
10 - 12 -
12 - 14 THREAD-EZE
8 - 10 THREAD-EZE
- Sapphire Aqua-Sil
Sapphire Aqua-Sil
16 - 18 -
- V7140084
Silicone oil, 350 cSt,
-
food grade
- Sapphire Aqua-Sil
2.7 - 3.3 -
3.5 - 4 -
- Sapphire Aqua-Sil
- -
- -
- -
- Sapphire Aqua-Sil
- Sapphire Aqua-Sil
- Castrol LMX grease
5 - 8
THREAD-EZE
4.5 - 6
