- Page 1 Hydro-Mix HT Mechanical Installation Guide To re-order quote part number: HD0766 Revision: 1.2.0 Revision date: June 2018...
- Page 2 CUSTOMER FEEDBACK Hydronix is continually looking to improve not only its products but also the services that we offer to our customers. If you have any suggestions about how we can do this or if you have any other feedback that would be helpful please complete our short form at www.hydronix.com/contact/hydronix_feedback.php.
- Page 3 +1 888 887 4822 (Toll Free) +1 231 439 5001 European Office Covers Central Europe, Russia and South Africa Tel: +49 2563 4858 Fax: +49 2563 5016 French Office Tel: +33 652 04 89 04 Hydro-Mix HT Mechanical Installation Guide HD0766 Rev 1.2.0 3...
- Page 4 Hydro-Mix HT Mechanical Installation Guide HD0766 Rev 1.2.0...
- Page 5 Revision history Revision No Date Description of Change 1.1.0 March 2017 First Release 1.1.1 April 2017 Minor formatting update 1.2.0 June 2018 Spacer Plate Installation Advice Added Hydro-Mix HT Mechanical Installation Guide HD0766 Rev 1.2.0 5...
- Page 6 Hydro-Mix HT Mechanical Installation Guide HD0766 Rev 1.2.0...
-
Page 7: Table Of Contents
Additional Cooling ........................25 Chapter 3 Corrosion Protection......................27 Corrosion Protection........................27 Chapter 4 Technical Specification ......................29 Technical Specifications ......................29 Appendix A Document Cross Reference ....................31 Document Cross Reference ....................... 31 Hydro-Mix HT Mechanical Installation Guide HD0766 Rev 1.2.0 7... - Page 8 Hydro-Mix HT Mechanical Installation Guide HD0766 Rev 1.2.0...
- Page 9 Figure 12: Hydro-Mix HT Mounting Components ................. 18 Figure 13: Clamp Ring Assembled and Connected to the Fixing Plate ..........19 Figure 14: Clamp Ring and Fixing Plate Attached to a Hydro-Mix HT ..........19 Figure 15: HMHT Spacer Plates ......................19 Figure 16: Clamp Ring with Spacer Plates attached to the Sensor ............
- Page 10 Hydro-Mix HT Mechanical Installation Guide HD0766 Rev 1.2.0...
-
Page 11: Chapter 1 Hydro-Mix Ht Installation
Ethernet Adapter Kit including Power Supply EPK01 Optional Ethernet Power Adapter Kit DSAHTXX Ducting System Angled DSVHTXX Ducting System Vertical Hydro-Com configuration and diagnostics software is available for free to download from www.hydronix.com Hydro-Mix HT Mechanical Installation Guide HD0766 Rev 1.2.0 11... -
Page 12: Introduction
3 General to Mixer Applications A significant benefit of the Hydronix system is that only one sensor is required in the mixer. However, it is important that it is positioned correctly in relation to the mixer type, material and water inlets, and other moving parts such as blades and paddles. -
Page 13: General Mounting Advice
When installing the sensor in a curved surface, ensure that the centre of the ceramic disc is radius of the internal wall flush with the Figure 3: Curved Surface Installation (Fixing Plate and Clamp Ring Not Shown) Hydro-Mix HT Mechanical Installation Guide HD0766 Rev 1.2.0 13... -
Page 14: Organic Material Mixers
Twin Shaft It is recommended that the Hydro-Mix HT should be located in the end wall between the two shafts. The sensor should be located at a level lower than the shafts to maintain complete coverage of the ceramic disc. -
Page 15: Screw Conveyor
Hydronix recommends the use of the Hydronix Ducting System (DSVHT or DSAHT) when installing the Hydro-Mix HT into ducting (Figure 8). The systems are designed for use in vertical (DSVHT) or angled ducting (DSAHT). Contact Hydronix for further details about the available ducting systems. -
Page 16: Figure 9: Hydro-Mix Ht Integrated In A Duct
A material flow rate of minimum 1kg/sec (3.54 ton/hour (long)) is used. Figure 9 shows the Hydro-Mix HT integrated into a duct. The outlet dimensions will need to be adjusted to suit each application to provide a suitable flow rate and a minimum of 100mm of material above the sensor. -
Page 17: Installing The Sensor
Chapter 1 8 Installing the Sensor These instructions refer to installing the Hydro-Mix HT on a flat surface; all other installation locations use the same mounting arrangement. Each sensor is supplied with a Clamp Ring. When attached this allows the sensor to be connected to the Fixing Plate which is welded externally or flush to the floor or wall of the installation location. -
Page 18: Figure 12: Hydro-Mix Ht Mounting Components
Fitting the Clamp Ring to the Sensor (without Spacer Plates) Fixing Plate (welded into position) Clamp Ring (Attached to sensor) M8 Fixing Screws (x4) Clamp Screws (x2) Figure 12: Hydro-Mix HT Mounting Components Hydro-Mix HT Mechanical Installation Guide HD0766 Rev 1.2.0... -
Page 19: Figure 13: Clamp Ring Assembled And Connected To The Fixing Plate
Chapter 1 Figure 13: Clamp Ring Assembled and Connected to the Fixing Plate Figure 14: Clamp Ring and Fixing Plate Attached to a Hydro-Mix HT Fitting the Clamp Ring using the Spacer Plates If the Fixing Plate has been installed flush with the internal wall the Spacer Plates can be added to the Clamp Ring to assist with the installation (Figure 15). -
Page 20: Figure 16: Clamp Ring With Spacer Plates Attached To The Sensor
Figure 16: Clamp Ring with Spacer Plates attached to the Sensor Sensor Flush with Mounting Plate Mounting Plate Clamp Ring Spacer Plate Spacer Plate Fully Inserted Figure 17: Final Assembly with Fixing Plate Attached Hydro-Mix HT Mechanical Installation Guide HD0766 Rev 1.2.0... -
Page 21: Figure 18: Minimum And Maximum Insertion
THE CERAMIC IS VERY HARDWEARING BUT IS BRITTLE AND WILL CRACK IF STRUCK When installing the Hydro-Mix HT it is imperative that the Ceramic Face Plate is flush with the internal wall. The sensor can be adjusted by up to 32mm by adjusting the position of the... -
Page 22: Figure 20: Positioning The Clamp Ring
Fixing Plate Figure 22: Flush Mounted Fixing Plate Attach the Clamp Ring with the Spacer Plates installed to the Hydro-Mix HT Ensure the Spacer Plates are touching the ridge on the sensor (Figure 23). Tighten the Clamp Ring Screws to lock the Clamp Ring into place... -
Page 23: Figure 23: Clamp Ring (Flush Mount)
Clean out compacted material or sealant from around the sensor. Remove the 4 Fixing Plate screws and extract the sensor. Warning: Do not hit the Ceramic Disc to remove the sensor. Hydro-Mix HT Mechanical Installation Guide HD0766 Rev 1.2.0 23... - Page 24 Chapter 1 Hydro-Mix HT Installation Hydro-Mix HT Mechanical Installation Guide HD0766 Rev 1.2.0...
-
Page 25: Chapter 2 Temperature Ratings
Chapter 2 Temperature Ratings The maximum temperature ranges stated in this installation guide are only valid if the Hydro-Mix HT is installed using the supplied mounting system (Fixing Plate and Clamp Ring). 1 Process Temperature Range The Hydro-Mix HT has been designed to operate in applications where the process temperature is between 0-120°C. -
Page 26: Figure 26: Water Cooling
Chapter 2 Temperature Ratings A water cooling system can also be installed using a suitable water pipe coiled around the sensor body (Figure 26). Figure 26: Water Cooling Hydro-Mix HT Mechanical Installation Guide HD0766 Rev 1.2.0... -
Page 27: Chapter 3 Corrosion Protection
See (Figure 27). Installation Side Wall Drip Loop Figure 27: Hydro-Mix HT Installed with a Drip Loop Protection Cover Install a cover over the top of the sensor to deflect the material away from the connector. (See Figure 28). - Page 28 Chapter 3 Corrosion Protection Hydro-Mix HT Mechanical Installation Guide HD0766 Rev 1.2.0...
-
Page 29: Chapter 4 Technical Specification
Measurement Modes Mode F, Mode V and Mode E Brix Measurement Output Digital (Serial) Communications 1.10 Opto-isolated RS485 2 wire port – for serial communications including changing operating parameters and sensor diagnostics. Hydro-Mix HT Mechanical Installation Guide HD0766 Rev 1.2.0 29... - Page 30 In areas of high lightning risk, correct and adequate protection should be used. The sensor cable shield is connected to the sensor body. To prevent earth loops the shield must not be connected at the control panel Hydro-Mix HT Mechanical Installation Guide HD0766 Rev 1.2.0...
-
Page 31: Appendix A Document Cross Reference
This section lists all of the other documents that are referred to in this User Guide. You may find it beneficial to have a copy available when reading to this guide. Document Number Title HD0678 Hydronix Moisture Sensor Electrical Installation Guide HD0679 Hydronix Moisture Sensor Configuration and Calibration Guide Hydro-Mix HT Mechanical Installation Guide HD0766 Rev 1.2.0 31... - Page 32 Appendix A Document Cross Reference Hydro-Mix HT Mechanical Installation Guide HD0766 Rev 1.2.0...
- Page 33 Integration in Ducting ........ 15 Temperature Ratings Electrical Interference ........13 Additional Cooling ........25 Fixing Plate Ambient ............. 25 Cutting Hole ..........18 Process ............. 25 External Mounting ........18 Hydro-Mix HT Mechanical Installation Guide HD0766 Rev 1.2.0 33...
