1. About this document
1.1 Function
This operating instructions manual provides all the information you
need for the mounting, set-up and commissioning to ensure the safe
operation and disassembly of the safety switchgear The operating
instructions must be available in a legible condition and a complete
version in the vicinity of the device
1.2 Target group: authorised qualified personnel
All operations described in this operating instructions manual must
be carried out by trained specialist personnel, authorised by the plant
operator only
Please make sure that you have read and understood these operat-
ing instructions and that you know all applicable legislations regarding
occupational safety and accident prevention prior to installation and
putting the component into operation
The machine builder must carefully select the harmonised standards
to be complied with as well as other technical specifications for the
selection, mounting and integration of the components
1.3 Explanation of the symbols used
Information, hint, note:
This symbol is used for identifying useful additional information
Caution: Failure to comply with this warning notice could
lead to failures or malfunctions
Warning: Failure to comply with this warning notice could
lead to physical injury and/or damage to the machine
EN
SLG440
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for schmersal SLG440
Summary of Contents for schmersal SLG440
-
Page 1: Table Of Contents
Wiring example 12 Wiring example SLG440 13 Connector coniguration Receiver, Transmitter &... - Page 2 2.1 Destination and use is the responsibility of the manufacturer of a machine or plant to ensure The SLG440 is a non-contact, self-testing safety guard, which is used the correct functionality of the entire machine or plant for the protection of hazardous points, hazardous areas and machine...
- Page 3 OSSD ON, OSSD OFF, restart, signal mechanical stresses, eg presses, punching machines, we recommend reception, blanking, information the MSD4 kit In this way, the availability of the SLG440 is increased Connection: M12 connector plug with metal thread, receiver 8-pole, transmitter 4-pole −25°...
- Page 4 Operating instructions Safety light grids SLG440 Factory setting The command devices (enabling button) must be installed The system features many functions without needing any additional outside of the hazardous area The operator must have devices The following table gives an overview of the possible functions...
- Page 5 An error message is emitted in the form of an error code For the 2-beam SLG440! more information, refer to chapter Fault diagnosis • The blanking of one beam at the most in the SLG440 3-beam version or the SLG440 4-beam version is During operation, the system executes a cyclic self-test Safety-rele-...
- Page 6 2.11 Parameter setting 1 Push button (approx 25 seconds) ➔ - flashes (parameter not active) The parameter setting of the SLG440 enables the individual adjustment 2 Enable button when ➔ A static (parameter active) of the desired functionality to the application 4) Save the new configuration with the parameter Save S.
-
Page 7: Mounting
Operating instructions Safety light grids SLG440 Table Parameter setting 3.2 Protection field and approach The protection field of the SLG consists only of the individual beams No. Parameter Status Note with a distance of 300, 400 or 500 mm Additional protective devices... -
Page 8: 35 Safety Distance 8
(3 segments)is not reached 3.5 Safety distance The safety distance is the minimum distance between the SLG440 and the hazardous point, which must be observed in order to ensure that the hazardous point can only be reached after the hazardous... - Page 9 K = Approach speed 1600 mm/s Access direction C = Safety supplement 850 mm Receiver Example Transmitter Obstacle Reaction time of the SLG440 = 10 ms Stopping time of the machine T = 170 ms optical axis 5° 5° 8° 8°...
-
Page 10: 36 Dimensions Transmitter And Receiver 10
Operating instructions Safety light grids SLG440 3.6 Dimensions transmitter and receiver 3.7 Fixing All measurements in mm Included in delivery Mounting kit MS-1100 The mounting kit consists of 4 steel angles and 8 fixing screws 27,8 Type Beam Mounting Total... - Page 11 The MSD4 vibration damper kit is recommend to be used for damping vibrations and oscillations on the SLG440 For applications with higher mechanical stresses, eg presses, punching machines, we recommend the MSD4 kit In this way, the availability of the SLG440 is increased...
-
Page 12: Electrical Connection
Operating instructions Safety light grids SLG440 4. Electrical connection 4.1 Wiring example Kn 1 Bridge 1 Bridge 2 Kn 2 Erdung Earth connection Restart interlock (manual reset) (bridge 1) K1, K2 Relay for processing the switching outputs By bridging restart 2 (pin 5) and DOUT (pin 6), the restart interlock... -
Page 13: Set-Up And Maintenance
Operating instructions Safety light grids SLG440 Connect COD 1 / COD 2 only when beam coding A is 4.2 Wiring example SLG440 activated! The colour codes are only valid for the cable types mentioned below "optional accessories" For UL evaluated products we do recommend to use the UL style cable 20549. -
Page 14: 53 Regular Check 14
Operating instructions Safety light grids SLG440 5.3 Regular check 5.4 Half-yearly inspection A regular visual inspection and functional test, including the following The following items must be checked every six months or when a ma- steps, is recommended: chine setting is changed... -
Page 15: 62 Fault Diagnostic 15
8. Appendix 7.1 Disassembly 8.1 Contact The safety switchgear must be disassembled in a de-energised Consultancy / Sales K. A. Schmersal GmbH & Co. KG condition only Möddinghofe 30 7.2 Disposal D-42279 Wuppertal The safety switchgear must be disposed of in an appropriate manner... -
Page 16: Eu Declaration Of Conformity
Managing Director Managing Director The currently valid declaration of conformity can be downloaded from the internet at wwwschmersalnet K. A. Schmersal GmbH & Co. KG Möddinghofe 30, D - 42279 Wuppertal Postfach 24 02 63, D - 42232 Wuppertal Phone:...
