BPS80
Congratulations on your
purchase of a
Amplified Subwoofer.
It has been designed, engineered
and manufactured to bring you
the highest level of performance
and quality, and will afford you
years of listening pleasure.
Thank you for making a
your choice for car audio
entertainment!
BPS80 Amplified Subwoofer User's Manual - Page 1
8" Low Profile
Amplified Subwoofer
BPS80
U S E R ' S M A N U A L
page
CONTENTS
2
2
2
3
4
4
Installation precautions
4
Fuses
4
Mounting the subwoofer
5
Connecting the subwoofer
7
Front panel controls and features
8
Rear panel controls and features
9
10
10
11
12
Advertisement
Table of Contents
Related Manuals for Boss Audio Systems BPS80
Summary of Contents for Boss Audio Systems BPS80
-
Page 1: Table Of Contents
Thank you for making a Connecting the subwoofer your choice for car audio entertainment! Front panel controls and features Rear panel controls and features Input wiring Power connections Remote level control connection Troubleshooting Specifications BPS80 Amplified Subwoofer User’s Manual - Page 1... -
Page 2: Introduction
• Adjustable input sensitivity: 0.1V-1V • Variable bass boost • Low pass filter (50 - 100Hz) • Soft delay remote turn-on • Remote sub-woofer control • Thermal, short and overload protection circuit BPS80 Amplified Subwoofer User’s Manual - Page 2... -
Page 3: General Precautions
If the shut down was due to either an input overload or a short circuit, be sure to correct these conditions before attempting to power up the subwoofer again. BPS80 Amplified Subwoofer User’s Manual - Page 3... - Page 4 Using a different type or rating of fuse may result in damage to your amp or vehicle or cause a fire. BPS80 Amplified Subwoofer User’s Manual - Page 4...
- Page 5 8 gauge (or heavier) cable from this fuse to the amplifier location. 4. Check that the fuse holder is empty. Then connect the fuse holder to the “BATT+” connection on the amplifier. BPS80 Amplified Subwoofer User’s Manual - Page 5...
- Page 6 3/4 volume, and adjust the subwoofer’ controls to just below the level of distortion. 10. Further fine tuning of the various controls may be necessary to obtain best results. BPS80 Amplified Subwoofer User’s Manual - Page 6...
- Page 7 This LED is green when power is on and no problems are present. The bass boost feature will increase the sound level in the bass frequencies. BPS80 Amplified Subwoofer User’s Manual - Page 7...
- Page 8 Low level inputs are the or coin. recommended way to introduce the audio signal to the subwoofer if RCA outputs are present on your head unit or other signal source (such as a sound processor). BPS80 Amplified Subwoofer User’s Manual - Page 8...
-
Page 9: Input Wiring
NOTE: Do not connect BOTH the high level and low level inputs from your receiver to your amplifier at the same time! (The extension cable to be purchased separately) BPS80 Amplified Subwoofer User’s Manual - Page 9... -
Page 10: Power Connections
“BATT+” connection on the subwoofer rear panel. Left Panel Remote Level Control Connection Right Panel Install the remote control securely under the dash or in a similar location where using it will not distract the drive. BPS80 Amplified Subwoofer User’s Manual - Page 10... -
Page 11: Troubleshooting
Use only the best quality cables, and route them away (static type) from power cables. Engine noise Check that the RCA grounds are not shorted to the vehicle chassis. (alternator Check that the head unit is properly grounded. whine) BPS80 Amplified Subwoofer User’s Manual - Page 11... -
Page 12: Specifications
Input sensitivity, low level Low pass filter 50Hz -100Hz Bass Boost 0 to +12dB Fuse rating Dimensions 10-1/4” x 14-3/8” x 3” (260 x 365 x 76mm) All specifications subject to change without notice. BPS80 Amplified Subwoofer User’s Manual - Page 12...
