Changer / Chest (5954) - Assembly and Operation Manual
Congratulations on purchasing an MDB Family product. This product will provide many years of service
if you adhere to the following guidelines for assembly, maintenance and operation. This product is for
residential use only. Any institutional use is strictly prohibited.
Please be sure to follow the instructions for proper assembly. Use a Phillips head screwdriver for
assembling the product in addition to the Allen wrench included in the hardware box. Do not use power
screwdrivers. All of our products are made from natural woods. Please understand that natural woods
have color variations which are the result of nature and not defects in workmanship.
DO NOT SUBSTITUTE PARTS. ALL MODELS HAVE THE SAME QUANTITY OF PARTS AND HARD-
WARE. YOUR MODEL MAY LOOK DIFFERENT FROM THE ONE ILLUSTRATED DUE TO STYLIS-
TIC VARIATIONS.
page 1
revised 26FEB2013
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for MDB Family 5954
Summary of Contents for MDB Family 5954
- Page 1 Changer / Chest (5954) - Assembly and Operation Manual Congratulations on purchasing an MDB Family product. This product will provide many years of service if you adhere to the following guidelines for assembly, maintenance and operation. This product is for residential use only.
- Page 2 PARTS HARDWARE Tools Needed (not included) Phillips screwdriver page 2...
- Page 3 STEP 1: Install Left Panel Glides (H9) on Left Side Panel (A) using Small Wood Screws (H6) STEP 2: Screw three Cam Bolts (H2) into Left Side Panel (A) page 3...
- Page 4 Step 3: Insert Cam Locks (H3) into Support Rails (E,F and G) and into Cupboard Bottom (H) Step 4: Insert five Cam Bolts into Right Side Panel (B) Align dowel holes on F and G with appropriate pre-drilled holes on Right Side Panel (B). Use Cam Locks (H3) to fasten. Step 5: Align holes on Cupboard Bottom (H) with Cam Locks (H3) on Right Side Panel (B).
- Page 5 Step 6: Screw two Cam Bolts (H2) into right side of Middle Panel (C) after installing the Right Panel Glides (H8) onto Middle Panel (C). Align dowels on the bottom of C with pre-drilled holes in the Center of F and G and C (left side up) Cam Bolts (H2) on C with pre-drilled holes on H.
- Page 6 Step 12: Align dowels on Side Panels (A and B) with pre-drilled holes on D. Lower D onto assembled case piece. Use Cam Bolts (H3) to tighten. Place Metal Pegs (H12) into pre-drilled holes on B and C. Lower Cupboard Shelf (P) onto Metal Pegs.
- Page 7 Step 13: Align back panels (J and K) onto back of the assembled chifferobe. Secure back panels with Small Wood Screws (H6). DRAWER ASSEMBLY INSTRUCTIONS page 7...
- Page 8 FURNITURE ANTI-TIPPING KIT INSTALLATION Serious or fatal crushing can occur when furniture tips over on WARNING children. To help prevent tip-over, follow the steps below to install this anti-tipping strap. Serious or fatal crushing injuries can occur from furniture tip-over. To help prevent tip-over: Place heaviest item in the lowest drawers.
- Page 9 Locate a 2” x 4” stud behind the wall, and make a mark. Stubby 2” x 4” wall stud Screwdriver Pencil Phillips screwdriver Install the strap on the wall with long screw and washer. Install the other end of strap on the back of dresser with short screw and washer into the wood framing of the dresser.
- Page 10 Finish KEEP THIS MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE. READ ALL INSTRUCTIONS BEFORE USING THE PRODUCT. KEEP THE INSTRUCTIONS FOR FUTURE USE. page 10...
