ES manufacturing H830 2.0 HVLP Spray Instruction Manual

Read this Instruction Manual carefully and understand it completely, basic precaution should be strictly

followed to prevent the damage to the tool and injury to the operator. Retain this manual for further reference.

And you should pay more attention to the Technical Data.

Feed Type: Gravity

Standard Dia of Nozzle: φ2.0mm

Optional Dia of Nozzle: φ0.5-1.2mm

Recommended air pressure: 4.5 – 6.0 bar (40-60 PSI)

Material Capacity: 120cc (250cc w/optional alum. cup)

Air Consumption: 3.5-6.0cfm

Model H830 2.0 HVLP Spray

Contents:

Technical Data

Important Safety Instruction

Caution

Parts List

Technical Data

Table of Contents

Do you have a question about the H830 2.0 HVLP Spray and is the answer not in the manual?

Page 1 Model H830 2.0 HVLP Spray Contents: Technical Data Important Safety Instruction Operating Instructions Adjustment Maintenance Caution Troubleshooting Parts List Technical Data Read this Instruction Manual carefully and understand it completely, basic precaution should be strictly followed to prevent the damage to the tool and injury to the operator. Retain this manual for further reference.
Page 2 9. Before spraying, be sure trigger and related parts operate smoothlyl. 10.Never modify this tool for any applications. Only use parts, nozzles and accessories recommended and accessories recommended by ES Manufacturing, Inc. Operating Instructions This tool applies to operate on clean, dry and compressed air at regulated pressure at 4.5-6.0 bar. Too low or too high pressure will adversely affect the gun and the quality of spray.
Page 3 Adjustment The desired pattern, volume of fluid output and fine atomization can easily be obtained by regulating the Pattern Adjusting Knob, Fluid Adjusting Knob and Air Adjusting Knob. Adjusting pattern: Turning Pattern Adjusting Knob to the right until tight will make spray pattern round, or turning it left, will make spray pattern ellipse.
