- Page 1 Model No. G7701L3.0 INDUSTRIAL SPRAY GUN CONTAIN: Description Specification and Technical Data Important Safety Instruction Instructions for Operation Maintenance/Storing Troubleshooting/Repairs Parts List...
- Page 2 It is supplied with a 600 cc suction feed Alum. Cup. Specifications And Technical Data 1. Name of Parts 2. Technical Data Item No. G7701L3.0 Air Inlet 1/4" Suction Type of Feed Standard Dia of Nozzle 2.0mm...
- Page 3 Important Safety Instructions 1.For toxic vapors produced by spraying certain materials can create intoxication and serious damage to health. Always wear safety glasses, gloves and respirator to prevent the toxic vapor hazard, solvent and pointing paint coming into contact your eyes or skin. (see fig 1) 2.Never use oxygen, combustible or any other bottle gas as a power source or would cause explosion and serious personal injury.
- Page 4 Adjustment The desired pattern, volume of fluid output and fine atomization can easily be obtained by regulating the Pattern Adjusting Knob, Fluid (PAINT) Adjusting Knob and Air Adjusting Knob. PATTERN ADJUSTMENT: Turning Pattern Adjusting Knob to the right until tight will make spray pattern round, or turning left make spray pattern ellipse.
- Page 5 Maintenance Incomplete cleaning could cause function failures and a degradation of the fan form. 1. Remove any remaining paint by pouring it into another container. 2. Disassemble the spray gun making sure to remove the needle before disassembling the nozzle to avoid damage to the housing of the nozzle closure.
- Page 6 Trouble shooting Symptom Problems Solution Fluttering or 1. Material level tool low. 1. Add material into container. spitting 2. Container tipped too far. 2. Hold more upright. 3. Loose fluid inlet connection. 3. Tighten. 4. Loose or damaged fluid tip/seat. 4.
- Page 7 Parts List Description Description Description Air Adj. Screw Ring Air Adj. Knob Snap Retainer Cup Lid O-ring(3.15*1.8) Pattern Needle Cup Lid Washer Washer Snap Retainer Paint Tube Air Valve Spring Trigger Suction Cup Air Inlet Valve Trigger Level Pin Set Air Inlet Plug Nozzle Gun Body...
