Model Information
EACH MODEL NUMBER CONSISTS OF THE FOLLOWING:
SERIES / SIZE / OPERATION / LAMP & BALLAST / INPUT
SERIES. BS111
SIZE....................................................4 (4 Foot Luminaire)
OPERATION...................HT (AC Only Electronic Ballast)
SA (AC & Emergency Ballast)
LAMP & BALLAST.........(128 = 1 x 28W) T5
(132 = 1 x 32W) T8
(154 = 1 x 54W) T5HO
INPUT VOLTAGE...........120-277VAC or 347VAC 60Hz
Major Components
Fixture Body
Conduit Knockouts
(Both Ends)
Reflector
Lamp Socket / Holder
Contact
Beluce Canada Inc.
3900 14th Avenue
Markham, ON L3R 4R3 Canada
PH: 877 358 9638 PH: 905 948 9500
FX: 905 948 8673
www.beghelli.com
Lens / Diffuser
Lens Clips (8 in Total)
Lamp (Not Supplied)
Installation Instructions
Illumina
®
BS111
Fluorescent Light Fixture
120-277VAC or 347VAC 60Hz Input
T5, T5HO or T8 Lamp
IP65 Weatherproof Rating
High Efficiency Reflector
High Impact Polycarbonate
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Beghelli Illumina BS111
Summary of Contents for Beghelli Illumina BS111
- Page 1 120-277VAC or 347VAC 60Hz Input T5, T5HO or T8 Lamp Contact IP65 Weatherproof Rating High Efficiency Reflector High Impact Polycarbonate Beluce Canada Inc. 3900 14th Avenue Markham, ON L3R 4R3 Canada PH: 877 358 9638 PH: 905 948 9500 FX: 905 948 8673 www.beghelli.com...
- Page 2 Connect AC Supply The use of accessory equipment not recommended CAUTION! Failure to insulate unused by Beghelli Inc, may cause an unsafe condition, wire may result in a shock hazard or and will void the unit’s warranty. unsafe condition as well as equipment...
