- Page 1 NETGEAR Redundant Power System and Power Bank RPS4000v2 Hardware I nstalla t ion G ui de November 2014 202-11462-01 350 East Plumeria Drive San Jose, CA 95134...
- Page 2 Compliance For regulatory compliance information, visit http://www.netgear.com/about/regulatory. See the regulatory compliance document before connecting the power supply. Trademarks © NETGEAR, Inc. NETGEAR and the NETGEAR Logo are trademarks of NETGEAR, Inc. Any non-NETGEAR trademarks are used for reference purposes only.
-
Page 3: Table Of Contents
Contents Chapter 1 Introduction Front Panel and LEDs ..........5 Rear Panel . -
Page 4: Chapter 1 Introduction
Introduction The NETGEAR Redundant Power System and Power Bank RPS4000 v2 provides state-of-the-art, high-performance, IEEE-compliant network solutions. This guide describes hardware installation and basic troubleshooting for these managed switches. The RPS can be freestanding or rack-mounted in a wiring closet or an equipment room. For additional information, go to the NETGEAR website at http://www.netgear.com. -
Page 5: Front Panel And Leds
Product Name & Model Front Panel and LEDs The following figures show the front panel of the RPS4000 v2. The front panel contains a set of power module LEDs for each power module slot. RPS status LEDs APS power module slots Figure 1. -
Page 6: Rear Panel
Product Name & Model Table 1. LED description (continued) Label Color Activity Description RPS Port Status Green The device is a B type design and the APS1000W in the corresponding RPS port and Power Module slot is supplying power to the device. Blinking The device is a B type design but the APS1000W in the corresponding RPS port and Power Module slot is not... - Page 7 Product Name & Model • If any of the following conditions occur, unplug the product from the electrical outlet and replace the part or contact your trained service provider: The power cable, extension cable, or plug is damaged. An object has fallen into the product. The product has been exposed to water.
- Page 8 Product Name & Model • To help protect your system from sudden, transient increases and decreases in electrical power, use a surge suppressor, line conditioner, or uninterruptible power supply (UPS). • Position system cables and power cables carefully; route cables so that they cannot be stepped on or tripped over.
-
Page 9: Chapter 2 Hardware Installation
Hardware Installation This chapter explains how to install the RPS. This chapter contains the following sections: • Package Contents • Protecting against Electrostatic Discharge • Unpack the Hardware • Installation • Connect Equipment to the RPS4000 v2 • RPS4000 v2 Modes of Operation... -
Page 10: Package Contents
NETGEAR Managed Switch Package Contents The package contains the following items: • RPS4000 v2 • Power cord • Rubber footpads for tabletop installation • Rack-mounting kit • Resource CD: The CD includes these documents or links to access them: RPS4000 v2 Installation Guide... -
Page 11: Installation
10. Note: If any item is found missing or damaged, contact your local NETGEAR reseller for replacement. Inspect the products and accessories for damage. Report any damage immediately. Installation Install the equipment in the sequence presented in this section: ... -
Page 12: Install The Rps
NETGEAR Managed Switch Table 2. Site requirements for RPS location Requirements Operating humidity Install the RPS in a dry area with a maximum relative humidity of 90%, noncondensing. Ventilation Do not restrict airflow by covering or obstructing air inlets on the sides of the RPS. -
Page 13: Check The Installation
NETGEAR Managed Switch Tighten the screws with a No. 1 Phillips screwdriver to secure each bracket. Align the bracket and rack holes. Use two pan-head screws with nylon washers to fasten each bracket to the rack. Tighten the screws with a No. 2 Phillips screwdriver to secure the switch in the rack. -
Page 14: Connect To Power And Check The Leds
Connect one end of the NETGEAR RPS cable to the RPS connector on the switch rear panel. Connect the other end of the NETGEAR RPS cable to the RPS4000 v2 rear panel RPS port connector. Reconnect the AC power cord to the switch or device. -
Page 15: Rps4000 V2 Modes Of Operation
NETGEAR Managed Switch WARNING: Do not remove the RPS cable from the RPS or the powered device when the connected device is on. First power the device off. Second, remove the power cord from the power module. Remove the device RPS power cable. -
Page 16: Mode One
NETGEAR Managed Switch Note: Modes one through six require all four RPS ports to have the same Type/CS setting. Mode One This mode supports Type A RPS devices such as GSM732xxSv1. One APS1000W PSU inside an RPS4000 v2 power bank supports one RPS port delivering power to an individual switch when a connected device is detected. -
Page 17: Mode Three
NETGEAR Managed Switch RPS4000 v2-provided PoE power replaces the switch's internal power supply when the RPS4000 v2 is connected to the switch, and the power supply inside the switch becomes a standby power supply. In this mode, APS1000W can be installed in any slot, but only the slot it is installed in will be used. -
Page 18: Mode Four
Mode Four This mode supports Type B RPS devices such the M5300 series switches. RPS ports deliver power to devices when the RPS4000v2 detects a connected Type B device over the I2C bus. In this mode, the RPS port can output a maximum 1440W of PoE power to devices when 2 power modules are present and work well in the same group. -
Page 19: Mode Five
Mode Five This mode supports Type B RPS devices such the M5300 series switches. RPS ports deliver power to devices when the RPS4000v2 detects a connected Type B device over the I2C bus. In this mode, one APS1000W will provide power to 2 RPS ports in the same group. -
Page 20: Mode Six
Figure 8. Mode Five Diagram Mode Six This mode supports NETGEAR chassis and switches that support the sharing feature, such as the M6100 chassis switch. The RPS will combine power from two adjacent APS units to one switch. -
Page 21: Mode Seven
NETGEAR Managed Switch This mode requires two RPS cables to two RPS ports on the M6100 chassis switch and all RPS4000 slots populated with APS1000W units. Figure 9. Mode Six Diagram Mode Seven In this mode, RPS4000 v2 delivers system power to connected devices when the Type and CS setting for each RPS port are not the same.This mode functions as a fall back... - Page 22 NETGEAR Managed Switch One RPS cable to one switch and one or more APS1000W populated in the RPS4000 v2 slots are required to use this mode. Figure 10. Mode Seven Diagram Note: The RPS will power off in all modes if two APS1000W units in the same group are not operating in the same range (e.g.
-
Page 23: Chapter 3 Troubleshooting
Troubleshooting Troubleshooting Chart The following table lists symptoms, causes, and solutions of possible problems. Table 4. Troubleshooting chart Problem Cause Solution Power LED is off. No power is received. Check the power cord connections for the switch at the switch and the connected device. Make sure that all cables used are correct and comply with Ethernet specifications. -
Page 24: Appendix A Technical Specifications
Technical Specifications Technical Specifications Table 5. Technical specifications Feature Description Environment Operating: • Temperature: 32° to 122°F (0° to 50°C) • Humidity: 90% maximum relative humidity, noncondensing • Altitude: 10,000 ft (3,000 m) maximum Storage: • Temperature: – 4° to 158°F (–20° to 70°C) •...
