Digital Guard Dawg 2GO KEYLESS iKEY RS Installation & User Manual page 10

Door Lock & Alarm
Wire
1
Red
Vehicle ON Detect
(+)
2
Green
Door Trigger
Default
(-) Negative
3
Blue
4
Brown
(+) Brake
5
Purple
6
White
OE Alarm
Factory Disarm
output (-)
7
EMPTY
~ Accessory Harness (7-Pin)
Description
This wire is for sensing when the vehicle is ON. It should be
connected to an Ignition wire that has +12 V when the Ignition
Key or Push Button Start is in the and ON (RUN) position.
Special instructions when using Remote Starter: Connect to
different ACC wire if the vehicle has 2nd ACC.
This wire senses when a vehicle "door open status". If you
have a negative-trigger door switch system, you can directly
connect this wire to the door switch signal wire.
If you have a positive–trigger or are not sure, refer to page 13 for
more information on door switch system trigger types. Note:
Default function setting is Negative door switch. Change PKE
modules jumper (JP1) to Positive when vehicles use positive-
switch Dome Light circuit.
If a Data Interface is used, connect to modules "UNLOCK" input
wire.
Connects to Window Rollup Module "Optional"
This wire senses when you step on the Brake. The wire will be
+12V as you depress the brake pedal, and will be ground when
release brake.
This wire provides the data control signal for the 2GO-Keyless™
Push Button – Remote Start Module. Connect this wire to the
(Purple) input signal wire of the Push Button Start module.
If needed, this wire can provides a Ground when Armed or
Disarmed signal that can be used as a "Factory Disarm Wire" for
a OEM Alarm system
10
