14. Wall Control Operating Instructions
Pairing
If you need to re-pair your fan or you want to pair a second wall
control:
1. Power cycle your fan by turning off the power at the
circuit breaker.
2. Press and hold and
10-15 seconds.
3. The LED will blink green then remain solid green.
4. The green LED along with audible beeps will indicate
that pairing is successful.
5. Test wall control for functionality.
FIG.18
Line/Hot
20
buttons on wall control for
Line/Hot
or Bare)
Ground (Green
Neutral/White
Neutral/White
(cont.)
Unpairing
NOTE: Purging must be completed within 3 minutes of turning the
power on to the fan receiver.
1. When you re-engage power to the fans you want to purge,
press and hold the
2. The LED will alternate red/green, blink green, and the receiver
will beep to indicate that purging is successful.
Multi Location Wiring
1. Install the wall control using the wiring diagram below.
2. Individually pair each of the wall controls with the fan receiver
using the pairing instructions in the previous section.
NOTE: Pairing must be completed within 3 minutes of turning the
power on to the fan/receiver.
Red
Fan
or Bare)
Ground (Green
If Applicable
and buttons for 4 seconds.
Red
Fan
If Applicable
