Installation & Operations Manual
Infrared/Radiant Compact Broiler
Improper installation, adjustment, alteration, service, or maintenance can cause property damage, injury, or death.
Read installation, operation, and maintenance instructions thoroughly before installing or servicing this equipment.
1100 Old Honeycutt Road, Fuquay-Varina, NC 27526 USA • www.southbendnc.com
M
1186527 R
3 (12/06)
ANUAL
EV
$30.00
P32-NFR / P36-NFR / P48-NFR
P32-RAD / P36-RAD / P48-RAD
WARNING
IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain
this manual for the life of the equipment:
Model #: __________________________
Serial #: __________________________
Date Purchased: ___________________
I
/R
C
NFRARED
ADIANT
OMPACT
M
S
ANUAL
ECTION
B
ROILER
SR
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Southbend P36-NFR
Summary of Contents for Southbend P36-NFR
- Page 1 1100 Old Honeycutt Road, Fuquay-Varina, NC 27526 USA • www.southbendnc.com 1186527 R 3 (12/06) ANUAL $30.00 P32-NFR / P36-NFR / P48-NFR P32-RAD / P36-RAD / P48-RAD WARNING IMPORTANT FOR FUTURE REFERENCE Please complete this information and retain this manual for the life of the equipment:...
-
Page 2: Safety Precautions
Warranty will be void if service work is performed by other than a qualified technician, or if other than genuine Southbend replacement parts are installed. Give this Owner’s Manual and important papers to the proper authority to retain for future reference. Copyright © 2006 by Southbend. All rights reserved. Published in the United States of America. WARNING FIRE HAZARD... - Page 3 Congratulations! You have purchased one of the finest pieces of heavy-duty commercial cooking equipment on the market. You will find that your new equipment, like all Southbend equipment, has been designed and manufactured to meet the toughest standards in the industry. Each piece of Southbend equipment is carefully engineered and designs are verified through laboratory tests and field installations.
-
Page 4: Specifications
1/2 psi (3.45 kPa). Southbend reserves the right to change specifications and product design without notice. Such revisions do not entitle the buyer to corresponding changes, additions, or replacements for previously purchased equipment. - Page 5 & M NFRARED ADIANT OMPACT ROILER LEANING AINTENANCE IMENSIONS Figure 2 & O 1186527 R 3 (12/06) NSTALLATION PERATIONS ANUAL...
-
Page 6: Gas Supply
& M LEANING AINTENANCE ENTILATION Improper ventilation can result in personal injury or death. Ventilation, which fails to properly remove flue products, can cause headaches, drowsiness, nausea, or could result in death. The flue vent, located at the top of the unit, must not be blocked or covered at any time. All gas appliances must be installed in such a manner that the flow of combustion and ventilation air is not obstructed. - Page 7 & M NFRARED ADIANT OMPACT ROILER LEANING AINTENANCE If applicable, the vent line from the gas appliance pressure regulator must be installed to the outdoors in accordance with local codes, or in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1, Natural Gas Installation Code, CAN/CGA-B149.1, or the Propane Installation Code CAN/CGA-B149.2, as applicable.
-
Page 8: Operation
Should ignition fail after 10 seconds, turn off burners, wait 5 minutes, and then try again. Southbend infrared broilers cook food in about half the time of conventional broilers, so adjust cooking times. Southbend infrared broilers are unique in design. They incorporate our exclusive ceramic tile burners, which generate infrared rays that provide better quality products in about one-half the usual broiling time, and with less gas input than ordinary broilers. - Page 9 PERATION OF NFRARED Southbend infrared broilers broil in half the time of ordinary broilers. The burners reach operating temperature in just 90 seconds, and their intense infrared energy quickly heats the food, not the surrounding air. The broiling rack adjusts to five heights, and rolls out for easy access.
- Page 10 & M LEANING AINTENANCE 7. Pull out the rack, place food on the grid, and slide the rack back into the broiler. (It is recommended the rack be in the lowest position for loading food.) 8. Cook the food for the appropriate time, turning it when appropriate. Periodically check the broiler grease drawer and empty it when necessary.
-
Page 11: Daily Cleaning And Maintenance
Southbend equipment is sturdily constructed of the best materials and is designed to provide durable service when treated with ordinary care. To provide the best performance, your equipment must be maintained in good condition and cleaned daily. -
Page 12: Stainless Steel Surfaces
& M LEANING AINTENANCE TAINLESS TEEL URFACES To remove normal dirt, grease and product residue from stainless steel surfaces that operate at LOW temperature, use ordinary soap and water (with or without detergent) applied with a sponge or cloth. Dry thoroughly with a clean cloth. -
Page 13: Installation
NFRARED ADIANT OMPACT ROILER NSTALLATION These installation procedures must be followed by qualified personnel or warranty will be void. Local codes regarding installation vary greatly from one area to another. The National Fire Protection Association, Inc. states in its NFPA 96 latest edition that local codes are the “authority having jurisdiction” when it comes to installation requirements for equipment. - Page 14 NSTALLATION OUNT ON The Infrared/Radiant Compact Broiler mounts over a range. A special flue riser is shipped with the broiler and range. Depending on the shipping requirements, the broiler, flue-riser, and range base may already be partially or completely assembled. 1.
- Page 15 NFRARED ADIANT OMPACT ROILER OUNT ON The Infrared/Radiant Compact Broiler is installed by first attaching a mounting bracket to the wall, then attaching the broiler to the bracket. 1. Attach the wall-mount assembly to the wall using the six ¼” x 2” lag screws and six washers provided (see Figure 5).
-
Page 16: Connect Gas Supply
If this equipment is being installed at over 2,000 feet altitude and that information was not specified when ordered, contact the appropriate authorized Southbend Service Representative or the Southbend Service Department. Failure to install with proper orifice sizing will result in poor performance and may void the warranty. - Page 17 NFRARED ADIANT OMPACT ROILER ALL PIPE JOINTS AND CONNECTIONS MUST BE TESTED THOROUGHLY FOR GAS LEAKS. USE ONLY SOAPY WATER FOR TESTING ON ALL GASES. NEVER USE AN OPEN FLAME TO CHECK FOR GAS LEAKS. ALL CONNECTIONS MUST BE CHECKED FOR LEAKS AFTER THE APPLIANCE HAS BEEN PUT INTO OPERATION.
-
Page 18: Step 5: Check The Installation
NSTALLATION 5: C HECK THE NSTALLATION 1. Check that all screws and bolts are tightened. 2. Check that gas connection has been made correctly. 3. Move the broiler into the final position at which it will be operated. 4. Check that the broiler is level. 5. -
Page 19: Troubleshooting
The serial plate is located under the broiler bottom drip pan at the front, toward the left (see Figure 1 on page 3). Replacement parts (including parts not listed in this manual) may be ordered either through a Southbend Authorized Parts Distributor or a Southbend Authorized Service Agency. -
Page 20: Serviceable Parts
CCESS TO ERVICEABLE Some serviceable parts are only accessible by removing body side panels and the front panel. The main front panel is fastened with six sheet-metal screws. To remove the front panel, remove these screws, as well as the burner-control-valve knob and the rack-height-position-lever knob. The main front panel can then be pulled forward and removed. - Page 21 (replacing the plug into the connector on the manifold). ARTS The following table describes the serviceable parts. For parts not listed, contact a Southbend Authorized Parts Distributor or a Southbend Authorized Service Agency. PARTS LIST...
- Page 22 PARTS LIST Part Number DESCRIPTION 1164085 Valve ASM, Pilot 1188253 Nameplate, Southbend 1183121 Tube, Valve Support, 32 1183125 Rack, 32 (Chrome) 1183128 Rack, 32 (CRS) (NAT) Gas Components 1133301 Regulator, WC @ 4” NAT 1176014 Valve, Burner, NAT 1008754 Orifice Hood, Drill #54...
- Page 23 Knob, Cast Aluminum 1060475 Knob, Ball 1183279 Weight, Counter Balance 1183287 Spacer, Bearing 1164085 Valve ASM, Pilot 1188253 Nameplate, Southbend 1183158 Tube, Valve Supply, 48 1183162 Rack, 48 (Chrome) 1183165 Rack, 48 (CRS) (NAT) Gas Components 1133301 Regulator, WC @ 4” NAT...
- Page 24 Flue-Riser Mount, Wall Mount, or Countertop A product with the Southbend name incorporates the best in durability and low maintenance. We all recognize, however, that replacement parts and occasional professional service may be necessary to extend the useful life of this appliance.
