Summary of Contents for Botron OMNIGND B92700
- Page 1 Operation Manual...
-
Page 2: Table Of Contents
Table of Contents The Botron B92700 OMNIGND is a Multi-Ground Continuous Description: Monitoring Automation System. Overview Pg. 2 Directory: Features Pg. 3 Quick Setup Guide Pg. 3 Settings Configuration Pg. 5 Display Screens Pg. 15 Functionality Pg. 18 Technical Specifications Pg. -
Page 3: Overview
OMNIGND Features OMNIGND Overview: Intuitive Tri-color LCD screen display 8 monitored ports for real-time measurement and recording events 2 Relays for TTL equipped devices Network communication through built-in Ethernet connection USB connection Measures Ground resistance of 1 ohm—20M VTR Technology (Variable Test Resistance Technology) for each port Web Server TCP communication Ports are transistor-transistor logic (TTL) Ports accept Analog in Resistance and Digital IN and OUT... - Page 4 Grounding: Mounting: (eg: the B92500 GroundHog from Botron) to either ring terminal or banana find an optimal place to mount the device in an area where it can be easily jack of the Ground Hub located on the bottom of the OMNIGND. This will accessed and/or viewed.
- Page 5 Configuring Your Settings Online Continued: Configuring Your Settings Online Continued: The Port Name page is where you can change the name of the Unit and Port Name Tab its description, along with the name of each individual port and their corresponding descriptions.
- Page 6 Configuring Your Settings Online Continued: Configuring Your Settings Online Continued: This is one of the many VTR Technology customization pages featured in The Delay page is where you can customize the delay settings for the TTL Hardware Tab Delay Tab OMNIManager.
- Page 7 Configuring Your Settings Online Continued: Configuring Your Settings Online Continued: The Auto Alert Tab is where you can enter email recipients information for Auto Alert Tab event alerts. • Under the Auto Alert Page the following settings may be changed: SMTP Server The SMTP Server name may be 32 characters or less.
- Page 8 Configuring Your Settings Online Continued: Configuring Your Settings Online Continued: The Network Page displays the network information for the OMNIGND Unit: Network Tab • The MAC Address and Host name are non-changeable The MAC Address is a way of identifying the Unit. The Host Name may be used in an internet browser connected to º...
-
Page 9: Display Screens
Display Screens: Configuring Your Settings Online Continued: The Tri-color LCD screen gives color coded back lighting indicating the status Understanding Screen Modes of the OMNIGND. Blue: Passive Mode (not recording data) Green: Logging Mode • Red: Ground Failure • • The Status Screen displays 3 columns;... - Page 10 Display Screens Continued: Display Screens Continued: • Column Three: The third column lists the current state that each Port is in: • The Auto-Logging Screen is used to turn Auto-Logging on and off. Auto-Logging Screen A PASS state means the current resistance value is in between Auto-Logging means the unit will record all monitored ground º...
-
Page 11: Functionality
Technical Specifications: Functionality: • Size and weight An audible alert that sounds on ground failure. 5.5″ x 4″ x 1.38″ (w/Stand 2.24″) Buzzer Alert • The Buzzer alert for each individual port may be changed using the 13.97cm x 10.16cm x 3.51 (w/Stand 5.69cm) OMNIManager. -
Page 12: Relay Warnings
Botron Contact Information: Relay Information: 21601 N. 21st Avenue • The relay only acts as an off or on switch. Botron Company Inc. Relay Warnings Phoenix, AZ 85027 • The relays do not provide any power or current. (623)582-6700 •...
