PRODUCT DESCRIPTION

III. PRODUCT DESCRIPTION

Basic Principle

Relync R1 is a three-wheeled powered vehicle driven by either one or two batteries, and controlled by
an electronic system. Users can operate the scooter via its own control system.

Dimensions

TURNING
RADIUS
1350
874
1103
25
582
Figure 3. Relync
R1 Dimensions (mm)

Specifications

The Relync R1 mobility scooter is powered by batteries and is controlled by an electronic system.
Model Name
Model No.
Weight Main body:26kg+Backrest:1kg+Each battery:1.3kg
Maximum Speed
Maximum User Weight
Endurance Range
Battery Capacity Output
Charger
Charging Time
Motor Type
Power of Motor
PRODUCT DESCRIPTION
Relync R1
RAA
4 mph(6.4km/h)
18st. (120kg)
1 battery: up to 9 miles (15km);
2 batteries: up to 18 miles (30km )
36V 400Wh Lithium battery
UL and CE approved, 110-240V
1 battery: 4 hours
2 batteries: 6 hours
BLDC (Gear motor)
170w
26
