Level Best Service Guide
D Auxiliary Dash Light and/or
Air Dump Does Not Work
1. On some coaches the 4 pin rectangular connector will be connected to an electric
air dump valve and / or an auxiliary jack warning light.
2. If the coach is so equipped and the dash light and or air dump control valve is not
functioning check the fuse behind the touchpad.
3. Check the function again.
E

Auto Level Flashing Red / Green alternating

1. The flashing red / green indicates a failure to communicate with the level sensor.
2. Check to see that the auto level harness is plugged in to both ends to the control
and plugged in to the auto level sensor.
3. Check function of the unit. If it still does not function go to step 4.
4. Check that the harness does not have a break in the cable. Check for continuity
between the pins on both ends of the cable. With your meter set on the continuity set-
ting, check that there is continuity between Pin 1 on one end and Pin 1 on the other end.
Check the same for Pin 2, Pin 3, etc. If there is not continuity between the pins, the
cable is bad. Replace the cable.
5. Check function again. If the unit still does not work replace the level sensor module.
6. Check function. If the unit does not function, call Kwikee Customer Service at
800-736-9961.
