- Page 1 Raffaello 120 Ceiling Hood Installation & User Instructions Please read these instructions carefully before installing and operating this appliance...
-
Page 2: Table Of Contents
Contents 1. Introduction 2. Health and Safety 3. Warranty Information 3.1 After Sales Service Information 3.2 How to Report a Fault 3.3 Technical Assistance 4. Installation 4.1 Assembly Instructions 4.2 Ducting 9-12 4.2.1 Information on Exhaust Air Ducting 4.2.2 Cross Section of the Exhaust Air Ducting 4.2.3 Exhaust Material, Ducting &... -
Page 3: Introduction
regulations in force in your local area, region 1. Introduction and country. • Dear Customer, For the correct use of the appliance and to prevent accidents, the instructions given in this We wish to thank you for choosing this Air Uno booklet must always be followed. -
Page 4: Warranty Information
A field service engineer is available to attend a breakdown occurring during the cooker hoods guarantee period. We offer a 4 year warranty on all Airuno cooker hoods, which will start from the date of delivery. The The cooker hood must be made available for... -
Page 5: How To Report A Fault
Airuno. Step 2 Ø150mm round or 220x90mm rectangular ducting Please note that upon attendance by an Airuno must be used. Ducting with a smaller diameter engineer, a charge will be made where: - The could cause airflow issues and invalidate the engineer finds no fault with the cooker hood. - Page 6 Raffaello 120 without Motor 280.5 280.5 Ø4mm Fig 2 Fig 5 Raffaello 120 with and without motor cut-out dimensions 2. Screw the cap onto the bolt (Fig 6). Fig 3 Fig 6 3. Screw the bolts into the 4 holes leaving 15mm from bulkhead to end of the bolt and cap (Fig 7).
- Page 7 7. Remove the cover from the body (Fig 11). Fig 8 5. Pull down at each side of glass to open (Fig 9). Fig 11 Align the fixings to the holes on the hood and tighten bolts to fix the hood to the bulkhead (Fig 12).
- Page 8 If the Raffaello has a motor attached then this can be rotated to suit ducting installation (Fig 16). To do this just undo the 4 screws rotate the motor and retighten the screws. Fig 16 Ducting can also be taken from the top of the Raffaello.
-
Page 9: Ducting
narrowing in the cross section will also cause the 4.2 Ducting noise level to increase. 4.2.1 Information on Exhaust Air Ducting It is only possible to achieve a high airflow volume and low noise level by using extractor ducting that provides low resistance. -
Page 10: Exhaust Material, Ducting & Shape
4.2.3 Exhaust Material, Ducting & Shape Smooth-walled plastic rigid ducts are the most favourable form of ducting from a technical airflow perspective and are particularly suitable for straight duct routes/runs. These should be used if the structural requirements are met. Flexible aluminium ducting (alu-flux) also achieves reasonably good flow values when elongated. -
Page 11: Length Of The Exhaust Ducting, Curves & Bends
4.2.4 Length of the Exhaust Unfavourable flow: Ducting, Curves & Bends Air swirls are created behind the As the length of the exhaust ducting increases, the sharp interior corners. counter pressure (duct resistance) increases and the airflow rate decreases. Bends and curves are problematic as they present deflection surfaces that dam the air steam and generate turbulence. - Page 12 The following comparison between different duct types and flat channels indicates the extent to which the material used can influence airflow loss. COMPARISON BETWEEN CHANNEL SYSTEMS WITH A SQUARE CROSS SECTION COMPARISON BETWEEN CHANNEL SYSTEMS WITH A ROUND CROSS SECTION...
-
Page 13: Electrical Wiring
4.3 Electrical Wiring The electrical wiring must be performed by a under the conditions of overvoltage category III, in specialised electrician fully respecting current accordance with the rules of installation. The plug or standards and legislation in force. Check that the Omni polar switch must be accessible when the unit power supply... -
Page 14: Controls
4.3.2 Controls Metal plate The Raffaello is controlled by remote control. This LED panel allows the user to control the hoods on/off functions and motor speeds. Metal plate Fig 20 5.2 Cleaning the Metal Filters Fig 19 The metal filters fitted in the hood should be Turns motor on at speed 2 and for turning the washed every 2-3 months, depending on how much motor off. -
Page 15: Long Life Carbon Filters
Do not use aggressive products, chemical solvents or 5.3.2 Long Life Carbon Filters derivatives of oil distillates that could leave oily These can be cleaned and reactivated. The filter traces which could cause oxidation should be cleaned every other month if used polymerisation. -
Page 16: Troubleshooting
7. Troubleshooting Please make sure the below has been checked before logging a service call. NOISY − Check that the hood has correct size ducting (semi or rigid ideally). − Make sure there are no restrictions within the ducting outlet. −... -
Page 17: Dimensions
8. Dimensions 8.1 Raffaello 120cm Without Motor Ø150 8.2 Raffaello 120cm without Motor... - Page 20 CD (UK) Ltd T/A Air Uno Unit L, Wakefield House Thistle Way Gildersome Spur Morley West Yorkshire LS27 7JZ CD (UK) Ltd T/A Air Uno is a company registered in England and Wales Registration No. 2905619 of this vested part not be reproduced of this are accurate at the date of...
