- Page 1 User manual Magnetic Stirrer with Heating Magnetic Stirrer 04661- 43 04661- 44 04661- 45 Stir Heat 04661- 46 Timer 04661- 29 04661- 30 Stir Timer 04661- 39 04661- 40 04661- 41 Stir 04661- 42 Heat...
-
Page 3: Table Of Contents
04661- 44 04661- 45 Stir Heat 04661- 46 Timer 04661-29 04661- 30 Stir Timer 04661- 39 04661-43 04661-44 04661-39 04661-40 04661-45 04661-46 04661-41 04661-42 04661- 40 Model: 04661- 41 Stir 04661- 42 Heat ..........User manual ×1 Support rod installation ............. -
Page 4: Safety Instructions
Safety instructions ·When operating the magnetic stirrer, please follow the safety instructions, the accident prevention regulations, and pay attention to your occupational health. · Notice: Effects of magnetic field should be taken into account(e.g.data storage, cardiac pacemakers...) · Risk of burns! The heating plate can reach a high temperature of 280 °C when the stirrer is working. Please exercise caution when touching the outer housing and the heating plate. - Page 5 Safety instructions • Only use medium that will not react dangerously with the energy generated through processing or through other ways e.g. light irradiation. • Safe operation is only guaranteed with the accessories described in the ‘Optional accessories’ section. • Please use the accessories listed on the manual in accordance with the operating instructions. •...
-
Page 6: Maintenance And Cleaning
• Make sure the instrument is clean and free from any materials that may harm people before sending for repair. • Please send the instrument back to Cole-Parmer in its original packaging. If you couldn’t find the original packaging, ensure to use... -
Page 7: Model: 04661-43 04661-44 04661-39 04661-40 04661-45 04661-46
Support rod installation 04661-43 04661-44 04661-39 04661-40 04661-45 04661-46 04661-41 04661-42 Model: If using external temperature sensor to measure temperature of the medium, please install support rod, horizontal head clamp, horizontal holding rod and external temperature sensor. Remove the white protective cap of the tapped hole... -
Page 8: Switching On
Switching on 04661-43 04661-44 04661-39 04661-40 04661-45 04661-46 04661-41 04661-42 Model: Preparation before start up heck that the power voltage is in accordance with the voltage marked on the nameplate and the electric outlet is well grounded. The instrument may be damaged and there may be security problem if someone does not strictly follow the above instruction. The instrument should be operated under appropriate temperature and humidity according to the technical parameters in this manual. -
Page 9: Plate Overview
Plate overview 04661-43 04661-44 04661-39 04661-40 04661-45 04661-46 04661-41 04661-42 Model: How to use the touch wheel Touch wheel Touch and move your finger around the “Touch wheel” clockwise+ / counterclockwise- (follow the direction of LCD display the arrow) to adjust the setting of different configuration Switch with the adjustable increment. -
Page 10: Setting Safety Temperature
Setting safety temperature 04661-45 04661-46 04661-41 04661-42 Model: Notice！ If using an external temperature sensor (Pt1000s) to measure the temperature of the liquid medium, user must connect the external temperature sensor and probe into the liquid medium before activating the heating function. Do not remove the external temperature sensor during the heating, otherwise the internal components will be damaged. -
Page 11: Setting Heating Temperature
Setting heating temperature 04661-43 04661-44 04661-39 04661-40 04661-45 04661-46 04661-41 04661-42 Model: Start heating Press “Switch” key until the “Set” indicator on the temperature setting section flashes and the system will enter into heating temperature setting status; When the heating temperature setting is switched on, then touch and move your finger around the “Touch wheel”... -
Page 12: Setting Stirring Speed
Setting stirring speed 04661-43 04661-44 04661-39 04661-40 04661-45 04661-46 04661-41 04661-42 Model: Start stirring Press “Switch” key until the “Set” Rotation speed range indicator on the stir setting section 04661-45 04661-46 04661-41 04661-42 04661-43 04661-44 04661-39 04661-40 flashes and the system will enter into... -
Page 13: Reverseible / Intermittent Stirring Function
5 second break before every change. Inactivate When the reverse stirring mode is active, press to turn off reverse stirring function, and the Reverse / Intermittent stirring mode indicator will be off. Model: 04661-43 04661-44 04661-45 04661-46 Model: 04661-39 04661-40 04661-41 04661-42... -
Page 14: Setting The Timer
Setting the timer( 3 timing function 04661-43 04661-44 04661-45 04661-46 Model: Enable the timer Notice: The timer can only be enabled when heating or stirring function is activated Press “Switch” key until the “Set” indicator on the timer setting section flashes and the system will enter into timing function setting status;... -
Page 15: Locking Function
Locking function 04661-43 04661-44 04661-39 04661-40 04661-45 04661-46 04661-41 04661-42 Model: Activate Press (Function key) for more than 2 seconds in operation status, as a result, all the keys on the operation panel will be locked, and the “Lock indicator”... -
Page 16: Troubleshooting Guide
Troubleshooting guide 04661-43 04661-44 04661-39 04661-40 04661-45 04661-46 04661-41 04661-42 Model: Before contacting your supplier in case of an issue, please check below for troubleshooting some common issues. Problem Possible causes Solutions Make sure the power line correctly The power line and the power outlet... - Page 17 Troubleshooting guide 04661-43 04661-44 04661-39 04661-40 04661-45 04661-46 04661-41 04661-42 Model: Error Code Error code display on the LCD screen when a malfunction occurs during operation Code Cause Effect Solution Temperature inside E 0.0 Heating function shutdown Turn off the device and wait for it to cool down...
- Page 18 Troubleshooting guide 04661-45 04661-46 04661-41 04661-42 Model: Code Cause Effect Solution Turn off the device -Warning! Only an authorized maintenance and temperature Safety E 8.0 Heating function shutdown repair personnel can carry out an internal checking circuit malfunction on the safety temperature circuit Temperature safety E16.2 sensor malfunction...
- Page 19 Technical data Model 04661-45 04661-46 04661-41 04661-42 04661-43 04661-44 04661-39 04661-40 Maximum stirring quantity(H Motor output Rotation Speed range 1800RPM 1600RPM Stirring function Intermittent mode: 45 seconds Reversible stirring function : 45 seconds Heating power output 600W 300W Heating temperature increases speed(1L H °C/min...
- Page 21 User manual Magnetic Stirrer 04661-29 04661-30 Stirr Timer...
-
Page 22: Switching On
Switching on Preparation before start up heck that the power voltage is in accordance with the voltage marked on the nameplate and the electric outlet is well grounded. The instrument may be damaged and there may be security problem if someone does not strictly follow the above instruction. The instrument should be operated under appropriate temperature and humidity according to the technical parameters in this manual. -
Page 23: Plate Overview
Plate overview How to use the touch wheel Touch wheel Touch and move your finger around the “Touch wheel” clockwise+ / counterclockwise- (follow the direction of LCD display the arrow) to adjust the setting of different configuration Switch with the adjustable increment. The faster the movement of the finger the larger Start / Stop the adjustment of the setting parameter... -
Page 24: Setting Stirring Speed And Reverse Mode
Setting stirring speed and reverse mode Start stirring Press key until the indicator on the stir setting section “Switch” “Set” flashes and the system will enter into stirring speed setting status; When the stirring speed setting is switched on, then touch and move your finger around the “Touch wheel”... -
Page 25: Setting The Timer
Setting the timer Enable the timer Press “Switch” key until the “Set” indicator on the timer setting section flashes and the system will enter into timing function setting status; When in timing function setting status, user can touch and move finger on the “Touch wheel”... -
Page 26: Troubleshooting Guide
Troubleshooting guide Before contacting your supplier in case of issue, please check below for troubleshooting some common issues. Problem Possible causes Solutions Make sure the power line correctly The power line and the power outlet connected with the power socket is disconnected Instruments does not power on The power socket is in poor electrical... -
Page 27: Technical Data
Technical data Model 04661-29 04661-30 Maximum stirring quantity(H Motor output Rotation Speed range 1800RPM Reverse of rotation direction 45 seconds Timer 9 huors Display Stirring bar length range 80mm Heating Plate Material Aluminum alloy ceramic coating Heating Plate Size O 135mm Dimensions (W x D x H) 175 x 270 x 76mm Weight... - Page 28 Toll-Free: 1-800-323-4340 Phone: 1-847-549-7600 Fax: 1-847-247-2929 Coleparmer . com...
